Motion Computing J3400 User Manual page 56

To replace the SIM
1. With the tablet turned off and the battery or battery bay cartridge removed from the
right battery bay, lift the plastic film covering the SIM slot and slide the SIM into the slot
with the metal contacts facing downward and the notched corner positioned as shown
in the illustration.
1
Notched corner
of SIM
2. Replace the battery or battery bay cartridge in the right battery bay by placing the two
tabs of the battery or battery bay cartridge into the two slots in the battery bay, and then
press the other end of the battery into the battery bay until you hear a click or feel the
battery lock into place.
50 Chapter 3
S I M
2
Using your Tablet PC
S I M
SIM slot
Slide SIM
under tabs.
