Shoulder strap attach point
Air vent
4 Chapter 1
Right Side
Battery status
Fingerprint
reader
light
Windows Security
button
Shoulder strap Attach point for the shoulder strap.
attach point
Air vent Dissipates heat from the tablet.
Battery status light Indicates amount of remaining battery power.
Windows Security Use to log on to or lock your tablet. Equivalent to
button Ctrl+Alt+Del on a keyboard.
Fingerprint reader Scan your fingerprints for added security. You can also
use the fingerprint reader as a navigation device.
power button Turns the Tablet PC on and off.
Card slots cover Covers the smart card and Express card slots.
Smart card slot Attach a smart card.
Express card slot Attach an Express card.
Pen and pen bay Store the pen when not in use.
Pen tether attach Attach point for the pen tether.
point
Getting Started
Power button Card slots cover
removed
Express card
Smart card
slot (optional)
slot (optional)
Pen tether
attach point
Pen
