Camera Control Command

Overview

The XCL-U1000C/U1000 can be controlled externally
from a host device via a serial communication using
such communication softwares as "HyperTerminal" or
"Tera Term."
Serial Communication
Specifications
The serial communication system for the XCL-
U1000C/U1000 is an asynchronous method compliant
with RS-232C. The following table shows the
transmission control specifications.
Command inputs are echoed back.
57600/38400/19200/9600/4800 [bps]
Baud rate
Default setting: 38400 [bps]
Data bits
8
Parity
None
Stop bit
1
Flow control
None
XCL-U1000C/U1000 RS-232C connection
6PIN
TXD
1
RXD
2
GND
3
NC
4
NC
5
NC
6

Command System

The following table shows the command system.
Command category
Camera control commands
Setting value control command
D-SUB 9PIN
1
-
2
RXD
3
TXD
4
-
5
GND
6
-
7
-
8
-
9
-
Description
Controls the camera.
Controls setting data saved in the
camera.
Camera Control Command

Command Format

To input (send) a command, delimit a command name
and parameters with spaces, and press the Enter
(Carriage Return) key.
The following show the input format and an example:
<Input format>
command param1 param2 param3 [Enter]
<Input example> PARTIAL 1 0 15 <CR>
Notes
• A command name and parameters that follow cannot
be omitted (except for the last parameter) .
• Input characters are non case sensitive.
• Input decimal numbers for parameters.

Command Input and Response

The camera returns an echo back to valid inputs;
alphabets, numbers, "-", spaces, backspaces and
[ENTER] (Carrige Return). Input of letters and
symbols other than these are all ignored.
• When command execution is completed normally, the
screen displays "OK."
<Input>
<Output on screen> OK <CR>
• If command execution is terminated abnormally, the
screen displays "ERROR STATUS." Alternatively,
the result is shown in details. (To be described by
category.)
PARTIAL 1 0 15 <CR>
16
