Connecting Internal Headers

Before connecting cables to the internal headers, observe the precautions in "Before You Begin" on
page 23. Figure 20 shows the location of the internal headers.
1
Port1L
Port1R 3
F
5
Port2R
Sense_Send
7
Port2L
9
a
1394
TPA1+ 1 2 TPA1-
Ground
3
Ground 4
E
TPA2-
TPA2+ 5 6
+12 V +12 V
7 8
Key
Ground
10
(no pin)
USB A
USB B
1 2 Power (+5V)
Power (+5V)
D-
D- 3
4
D
5
D+ 6 D+
Ground
7 8
Ground
Key (no pin)
10 N/C
9
No Connection
8
7
Reset
6 5
C
4 3
Power LED HD LED
2 1
3
B
1
Item Description
A Chassis intrusion
B Alternate power LED
C Front panel
D USB 2.0 (two)
E IEEE-1394a (two)
F Front panel audio
Figure 20. Internal Headers
