Intel Desktop Board D945PVS Product Guide
Table 2.

Desktop Board D945PVS Components

Label Description
A Auxiliary rear chassis fan header 1 (4-pin, fan speed control)
B PCI Express x1 connectors
C Front panel audio header
D PCI Express x16 connector
E 12 V processor core voltage connector (2x2)
F Rear chassis fan header 1 (3-pin, fan speed control)
G Processor socket (LGA775)
H Processor fan header (4-pin, fan speed control)
I Main power connector (2x12)
J Diskette drive connector
K IDE connector
L Front chassis fan header (3-pin, fan speed control)
M BIOS configuration jumper block
N Chassis intrusion header
O Serial ATA connectors
P Front panel header
Q Alternate power LED header
R Hi-speed USB 2.0 headers
S IEEE1394a headers
T PCI bus add-in card connectors
Related Links:
Go to the following links for more information about:
•
Desktop board D945PVS
•
Supported processors
•
Audio software and utilities
•
LAN software and drivers
12
