Dual Configuration Example 3 - Intel D945PVS Product Manual

Three DIMMs
Install a matched pair of DIMMs equal in speed and size in DIMM 0 (blue) and DIMM 1 (black) of
channel A. Install a DIMM equal in speed and total size of the DIMMs installed in channel A in
either DIMM 0 or DIMM 1 of channel B (see Figure 15).
NOTE
All other memory configurations will result in single channel memory operation.
Installing and Replacing Desktop Board Components
256 MB, 533 MHz
256 MB, 533 MHz
512 MB, 533 MHz
Figure 15. Dual Configuration Example 3
Channel A
DIMM 0
DIMM 1
Channel B
DIMM 0
DIMM 1
33
