Amigopod and ArubaOS Integration

Enable Captive Portal on Initial Role of Captive Portal Profile

In the previous step, the initial role for this captive portal authentication configuration is configured as
guest-logon. This role must be modified to enable the newly created Amigopod captive portal profile.
If you forget this step, the captive portal is not triggered when a new guest connects to the guest Wi-Fi
SSID. Also, the amigopod policy must be added to the initial role to ensure that traffic from the
unauthenticated guest users can be redirected successfully to the Amigopod web login page.
If these policies are not in place, the controller attempts to redirect the browser session to the
Amigopod web login URL defined in your captive portal profile. This attempt fails because the default
captiveportal policy is matched for http traffic. The session will consequently be redirected a second,
third, and fourth time, in an endless loop. The result is a "too many redirects" error message or a
browser that keeps flicking between the controller and Amigopod web login URL.
The amigopod policy must be placed in position 1 of the access list to ensure
that it is processed first.
N O T E
Captive Portal Logon Role Configuration
user-role "guest-logon"
access-list session "amigopod" position 1
access-list session "captiveportal" position 2
access-list session "guest-logon-access" position 3
access-list session "block-internal-access" position 4
access-list session "v6-logon-control" position 5
access-list session "captiveportal6" position 6
captive-portal "guestnet"
Aruba Networks, Inc.
Figure 15 Captive portal logon role configuration
Application Note
ArubaOS Configuration | 25
