4.4.2

Chipset

The Chipset configuration menu allows you to change advanced chipset settings.
Select an item then press <Enter> to display the submenu.
Advanced
Advanced Chipset Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
Audio Controller
Front Panel Support Type
Marvell Storage Controller
Marvell Storage Boot ROM
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
Audio Controller [Enabled]
Allows you to enabled or disable the audio controller.
Configuration options: [Disabled] [Enabled]
Front Panel Support Type [AC97]
Allows you to set the front panel audio connector (AAFP) mode to AC97 or Azalia.
Configuration options: [AC97] [Azalia]
Marvell Storage Controller [Legacy Mode]
Allows you to disable the controller or select the controller operating mode. Set to
[Legacy Mode] when you want to use the Serial ATA hard disk drives as Parallel
ATA physical storage devices. Set to [RAID Mode] when you want to create a RAID
configuration from the SATA hard disk drives.
Configuration options: [Legacy Mode] [RAID Mode] [Disabled]
Marvell Storage Boot ROM [Disabled]
This item appears only when you set the previous item to [Legacy Mode] or
RAID Mode], and allows you to enable or disable the storage controller Boot
ROM. Configuration options: [Disabled] [Enabled]
ASUS Hummingbird
BIOS SETUP UTILITY
[Enabled]
[AC97]
[Legacy Mode]
[Disabled]
Options
Enabled
Disabled
Select Screen
←→
Select Item
↑↓
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
4-17
