D-Link DSA-3100 - Airspot - Gateway User Manual page 42

DSA-3100 Airspot Public/Private Gateway User Manual
Figure 4-33b
Note: To let the functions take effect, you need to click Apply, and then Save All after
Enable is selected.
•
Friendly logout: It relates to the pop up windows that will appear when user login success. If
you enable it, while you close the pop up window, it will ask you "do you want to logout? ",
otherwise it doesn't ask you "do you want to logout?"
• enable user to choose from activating https (encryption), or http
User Logon SSL:
(non encryption) as login page.
• WAN Fail Function: Provide a definable URL link for detection Internet connection. When
Internet connection fail is detected, then an error page will display unit the abnormal status is
recovered.
•
Authentication Server¡ G Support multiple user Public LAN methods including Local, POP3
Server, RADIUS Server, LDAP Server and External Web Server.
Note: To let the functions take effect, you need to click Apply, and then Save All after
Management Type is selected.
1.) Local:
User accounts are stored in the embedded database on DSA-3100.
Figure 4-34
MAC ACL Control
Local Configuration
35
