D-Link DSA-3100 Quick Installation Manual

Wireless service gateway.
Hide thumbs

Advertisement

This product can be set up using
any current web browser, i.e.,
Internet Explorer 5x, and
Netscape Navigator 4x or above.
Before You Begin
This Quick Installation Guide (QIG) provides instruction for installing the DSA-3100 and Ethernet configuration for
other PCs. The former part is going to show how to connect DSA-3100 with other Network equipments and Network
configuration of DSA-3100. The latter part is a description for configuring Network setting of other PCs on Ethernet
to make sure the normal function of whole Network.
Check Your Package Contents
♦ DSA-3100 Wireless Service Gateway
Balancer
♦ CD-ROM (Containing Manual and Warranty)
♦ DSA-3100 Quick Installation Guide
♦ Ethernet (CAT5 UTP/Straight-Through) cablex2
♦ Ethernet (CAT5 UTP/Cross over) cablex1
♦ Console Cable
♦ 5V DC, 3A Power Adapter
DSA-3100
Wireless Service Gateway
Using a power
supply with a
different voltage
rating will damage and void
the warranty for this product.

Advertisement

   Related Manuals for D-Link DSA-3100

   Summary of Contents for D-Link DSA-3100

  • Page 1: Before You Begin

    This Quick Installation Guide (QIG) provides instruction for installing the DSA-3100 and Ethernet configuration for other PCs. The former part is going to show how to connect DSA-3100 with other Network equipments and Network configuration of DSA-3100. The latter part is a description for configuring Network setting of other PCs on Ethernet to make sure the normal function of whole Network.

  • Page 2

    Use the Ethernet (CAT 5 UTP/Straight-Through) cable to connect the DSA-3100’s Local Network Port and the internal Switch (or Hub) in the Trusted network. If you want directly connect to the DSA-3100’s Authentication Port (or Local Network Port) to the PC or the wireless AP, you have to use the Ethernet (CAT5 UTP/Crossover) cable as connection.

  • Page 3

    DSA-3100’s Authentication port with your internal Switch or Hub in the Managed Network, then you have to connect DSA-3100’s Local Network port with your internal Switch or Hub in the Trusted Network. If you need to connect DSA-3100 with administrator's PC directly, you have to use Cross Line as a connection.

  • Page 4

    Configure PC on Your Ethernet After DSA-3100 installation, for each PC, the following items may need to be configured: TCP/IP Network Setting Internet Access Configuration A、TCP/IP Network Setting If administrator's PC uses the default Windows 95/98/ME/2000/XP setting, no changes need to be made. Please restart or reboot the PC.

  • Page 5

    B、Internet Access Configuration If you hope any PC on Ethernet can link up Internet through DSA-3100, Please make configurations according to different environment by following steps. For Windows 9x/2000 Select Star Menu - Setting - Control Panel - Internet Option.

  • Page 6: For Windows Xp

    For Windows XP Select Star Menu - Control Panel - Network and Internet Connection. Select Set up or change your Internet Connection. When Internet Properties Dialogue Box pops up, click "Setup" button and click "Next" on the "New Connection Wizard" screen. Select "Connect to the Internet"...

  • Page 7

    When entering the URL, you'll find the following dialogue box on screen. Please enter "admin" in the "Username" column and enter “admin: in the “Password” column. C、Network Configuration When management interface DSA-3100 pops please refer DSA-3100 User Manual in Product Package for further network configurations.

  • Page 8

    Appendix - Windows TCP/IP Setup Before ensure your TCP/IP settings correct, please check DSA-3100's IP Address with your network administrator, and ask your ISP for DNS Address or Address before making the following changes. A、Checking TCP/IP Settings - Windows 9x/ME Select "Control Panel"...

  • Page 9

    DNS server addresses, and enter the DNS address or addresses provided by your ISP, then click On the Gateway tab, enter the DSA-3100's IP address in the New Gateway field and click Add. (Your LAN administrator can advise you of the IP Address they...

  • Page 10

    DNS address or addresses provided by your ISP, then click OK. On the Gateway tab, enter the DSA-3100's IP address in the New Gateway field and click Add. (Your LAN administrator can advise you of the IP Address they assigned to the DSA-3100.)

  • Page 11: Technical Support

    Technical Support You can find the most recent software and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States for the duration of the warranty period on this product. U.S. customers can contact D-Link technical support through our web site or by phone.
