LED TV
Installation manual
imagine the possibilities
Thank you for purchasing this Samsung
product. To receive more complete service,
please register your product at
www.samsung.com/register
Model
Serial No.

Advertisement

   Also See for Samsung HG46NB890XF

   Related Manuals for Samsung HG46NB890XF

   Summary of Contents for Samsung HG46NB890XF

  • Page 1 LED TV Installation manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Model Serial No.
  • Page 2: Introduction

    ONLINE mode which gives full control of the TV to the SBB/STB. When the TV is in ONLINE mode, it stops accepting IR (Samsung remote) commands and acts according to the interface protocol. Stand-Alone: If you are not using an SBB/STB and the TV cannot or does not identify an SBB/STB, you should switch the TV to STAND-ALONE mode with restricted operation.
  • Page 3: Table Of Contents

    Contents y Introduction ................................2 y Operational Modes ..............................2 y Still image warning ..............................2 y Ensuring Proper Ventilation ............................2 y Additional Information ............................... 2 y Accessories ................................4 y Installing the LED TV Stand ............................5 y Using the TV's Controller ............................6 y The Connection Panel ...............................
  • Page 4: Accessories

    Accessories ✎ Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer. ✎ The items’ color and shape may vary, depending on the model. ✎ The parts for the stand are listed under Stand Components on the following page. y Remote Control (AA59-00817A) &...
  • Page 5: Installing The Led Tv Stand

    Installing the LED TV Stand Components When installing the stand, use the provided components and parts. x8 (M4 X L12) 1 EA 2 EA y Stand (depending on the model) y Guide Stand y Screws x4 (M4 X L12) ✎ Lay the TV on a soft surface, screen side down.
  • Page 6: Using The Tv's Controller

    Using the TV's Controller ✎ The color and shape of the TV Controller may vary depending on the model. ✎ The TV's Controller, a small joy stick like button on the bottom right side of the TV, lets you control the TV without the remote control.
  • Page 7: The Connection Panel

    The Connection Panel VARIABLE AUDIO OUT VOL-CTRL (HDD 5V 1A) AUDIO AUDIO IN HDMI IN 3 HDMI IN 1 (ARC) EX-LINK DATA AIR/CABLE ✎ Whenever you connect an external device to your TV, make sure that power on the TV and the device is turned off. ✎...
  • Page 8 3: Connects to the HDMI jack of a device with an HDMI output. HDMI IN 1 (ARC), 2 (DVI), ✎ No sound connection is needed for an HDMI to HDMI connection. HDMI connections carry both audio and video. ✎ Use the HDMI IN 2(DVI) jack for a DVI connection to an external device.
  • Page 9: The Remote Control

    The Remote Control Remote Control (AA59-00817A) ✎ This remote control has Braille points on the Power, Channel, and Volume buttons and can be used by visually impaired customers. Display and select the available video Turns the TV on and off. sources.
  • Page 10 Installing batteries (Battery size: AAA) Match the polarity of the batteries to the symbols in the battery compartment. After you have installed the batteries, use a screwdriver to screw in the screw that holds the battery cover closed. NOTE ✎ •...
  • Page 11: Using The Smart Touch Control

    Using the Smart Touch Control Smart Touch Control (AA59-00830A) ✎ This remote control has Braille points on the Power, Channel, and Volume buttons and can be used by visually impaired customers. Use Voice Recognition function with the microphone embedded in remote Not Available control.
  • Page 12: Connecting To The Tv

    In order to operate the TV using a Smart Touch Control, you must fi rst pair it to the TV via Bluetooth. However, the Smart Touch Control is only available for the paired Samsung TV. 1. To turn on the TV, point the Smart Touch Control at the remote control receiver of the TV and press the button.
  • Page 13 Reconnecting the Smart Touch Control If you need to rees tablish the connection between the TV and the Smart Touch Control, press the pairing button at the Touch Control, pointing at the remote control sensor of the TV. back of the Smart <The Smart Touch Control's pairing button>...
  • Page 14: Using The Touch Pad

    Using the touch pad Use the touch pad to implement various commands. Navigate to Tutorial (System > Device Manager > Smart Touch Control Settings > Tutorial) to view an on-screen guide to using the Smart Touch Control. Dragging HOME HOME HOME HOME HOME...
  • Page 15: Using The Number Panel

    Using the Virtual Remote Panel Press the MORE button to display the virtual remote panel on the TV screen. The virtual remote panel consists of the number panel, a playback control panel, and the quick access panel. Use the touch pad to highlight and select icons, numbers, and buttons on the panels.
  • Page 16: Connecting To The Network

    Your TV is compatible with the following security protocols: y Authentication Mode: OPEN, SHARED, WPAPSK, WPA2PSK y Encryption Type: WEP, TKIP, AES In compliance with the newest Wi-Fi certification specifications, Samsung TVs do not support WEP or TKIP security encryption in networks running in the 802.11n mode. English...
  • Page 17 Network Connection - Wired There are three main ways to connect your TV to your network using cable, depending on your network setup. They are illustrated below: External Modem The Modem Port on the Wall TV Rear Panel (ADSL / VDSL / Cable TV) Modem Cable (Not Supplied) LAN Cable (Not Supplied) The Modem Port on the Wall...
  • Page 18: Connecting The Tv To An Sbb Or Stb

    Connecting the TV to an SBB or STB ETH MODEM Data Cable TV Rear Panel DATA DATA DATA 1. Connect the DATA jack of the TV to the [ETH MODEM] jack of the STB (SBB) with the Data cable. ✎ Use data communication.
  • Page 19 List of Vendors and Compatible Data Cables Supplied with the TV ¦ y Confirm that you are using the correct data cable for your vendor. Refer to the code label on the data cables. English...
  • Page 20: Connecting The Bathroom Speakers

    Connecting the Bathroom Speakers You can connect the Bathroom Speakers using the following method. Connecting through the Variable Output (available without an external amplifier) ¦ TV Rear Panel VARIABLE VARIABLE VARIABLE Speaker AUDIO OUT AUDIO OUT AUDIO OUT VOL-CTRL VOL-CTRL VOL-CTRL (HDD 5V 1A) (HDD 5V 1A)
  • Page 21: Connecting The Mediahub Hd

    Connecting the MediaHub HD Output to any external source connected to MediaHub HD on the hotel desk. MediaHub HD Rear TV Rear Panel HDMI RS/232 VARIABLE VARIABLE AUDIO OUT AUDIO OUT VOL-CTRL VOL-CTRL 2 HDMI cable (HDD 5V 1A) (HDD 5V 1A) AUDIO AUDIO AUDIO IN...
  • Page 22: Connecting The Rjp (remote Jack Pack)

    TV and the HDMI port of the RJP. 3. Connect the EX-LINK port of the TV and the RS/232 port of the RJP. ✎ The RJP (Remote Jack Pack) compatible with this Samsung TV is TeleAdapt TA-7610, TA-7650 (HD) and TA-7660 (HD Plus). English...
  • Page 23 y RJP (Remote Jack Pack): RJP stands for Remote Jack Pack. The RJP is a hardware module that has different Audio Video inputs (A/V, Audio, PC and HDMI) and corresponding outputs. The corresponding outputs are connected from the RJP to the TV. The RJP communicates with the TV via RS232. A Hot Plug & Play function allows hotel guests to connect an external source to the RJP.
  • Page 24: Setting The Hotel Option Data

    1. Highlight the Hospitality Mode menu item in the top left corner of the menu. 2. Press the left or right arrow button on the Samsung remote. Only the Hospitality Mode menu item is displayed. 3. Press the left or right arrow button to change the Hospitality Mode item from Standalone to Interactive or from Interactive to Standalone.
  • Page 25: Menu Items

    Standalone mode: TV works alone, without an SI STB or SBB Mode Interactive mode: TV works with an SI STB or SBB Interactive mode : Samsung / OCC / MTI / Nstreams / Enseo / Cardinal / Guestek / SeaChange / BDC / Innvne SI Vendor...
  • Page 26 Menu Item initial Value Description Allows music output from an mp3/audio player connected to an AV Input Source on the TV. When on, you can hear sound from the player through the TV whether there is Music Mode AV a video signal or not. Also mutes the video so the TV does not display a picture when a guest is playing music.
  • Page 27 Hospitality Logo BMP or AVI files only. Max file size : BMP - 960 X 540. AVI - 50MB. The file can only be named samsung.bmp or samsung.avi. Logo Display Time Hospitality Logo Display Time (3/5/7 seconds). Clone TV to USB Clone the current TV option values to a USB memory device.
  • Page 28 Pro:Idiom encryption. If your broadcasting system does not have a problem, contact Samsung Service. If STB SI Vendor Setting appears to have failed and communication with the SI STB or SBB has failed, first check your SI STB or SBB.
  • Page 29 Welcome Message ¦ The Welcome Message feature displays a custom message on the TV every time it is turned on. – Welcome message settings are in the Hotel Option Menu. – Set Welcome Message to ON to display the message when the TV is powered on. Welcome Message Edit Welcome Message Hospitality Logo...
  • Page 30 Logo File Format – The TV supports only BMP and AVI format. – The file name must be samsung.bmp or samsung.avi. – The maximum resolution of the BMP format is 1280 x 720. – The maximum file size for AVI format is 50MB.
  • Page 31 USB Cloning ¦ The USB Cloning function lets you download user-configured settings (Picture, Sound, Input, Channel, Setup, and Hotel Setup) from one TV to a USB device, and then upload these settings from the USB device to other TV sets. This lets you create a standard array of settings and distribute that standard array to all the TVs in your facility.
  • Page 32 y Settings Cloned in the Hotel Menu Menu Item Cloning Support Applicable Region Hospitality Mode SI Vendor All except Brazil Power On Channel EN Power On Channel Channel Type Power On Volume EN Power On Volume Min Volume Max Volume Power On Source Power On Option Channel Setup...
  • Page 33 Menu Item Cloning Support Applicable Region Hospitality Logo Hospitality Logo DL Logo Display Time Clone TV to USB Clone USB to TV Setting Auto Initialize REACH Server update Time All except Brazil/ASIA_READY All except Brazil/ASIA_READY REACH Update Immediate All except Brazil/ASIA_READY Manual SIRCH REACH Server Channel All except Brazil/ASIA_READY...
  • Page 34 Multi Code Remocon ¦ A Multi Code Remocon is a special remote which is designed to control multiple TV. This is useful where there is more than one TV in a location. You can control up to 10 TVs, each with a different ID code, with one remote. ID numbers are displayed on each TV's OSD. The Initial ID code for each TV is “0”.
  • Page 35 Setting Auto Initialize ¦ When you clone settings from one TV to another, you clone both the guest side menu and hotel side menu settings: Picture, Sound, Input, Channel, Setup, and Hotel Setup. This lets you set nearly all of the menu values on your hospitality TVs to the same, standard settings.
  • Page 36 Hotel Plug & Play ¦ The Hotel Plug & Play function, which automatically performs the Hotel mode selection, Country Setup, Clock Setup, and Picture Mode Setup, runs once, when power is fi rst turned ON. Setup also runs automatically after you have executed a Service Reset.
  • Page 37 ¦ Samsung may offer upgrades to the TV’s software (SW) in the future. Please contact the Samsung Hospitality Hotline at 1-866- 894-0524 to receive information about downloading upgrades and using a USB drive to update the SW by connecting the USB drive containing the upgrade to the USB port located on the TV.
  • Page 38 Samsung Sound-Bars and Hospitality TVs in 2013 – Samsung Sound-Bars and hospitality TVs support the ARC feature in HDMI 1.4. If you connect a compatible Samsung Sound-Bar to a compatible Samsung hospitality TV using a single HDMI cable, guests can listen to the TV's sound through the Sound-Bar.
  • Page 39 Channel Bank Editor (Smoovie TV Only) ¦ The Channel Bank Editor in conjunction with the SMOOVIE remote lets you control the channels guests have access to. The Channel Bank Editor provides three Banks of channels and lets you select which channels will be available from each bank. SMOOVIE remotes have installable Bank Cards which correspond to the channel banks in the Channel Bank Editor.
  • Page 40 Smoovie Set Up Sequence Smoovie TV Setup (Air/ Cable ) Only Air or Cable used Step Only Air or Cable used If the TV starts with Hotel Plug&Play If Hotel Plug&Play already done Do a complete P&P (including Air or Cable auto tune) Enter the Hotel menu Select the channel type After P&P, the TV displays the Hotel menu...
  • Page 41 The picture below shows a sample Channel Editor screen. y a Indicates an analog channel. y Channels without an a are digital channels. y The guide at the bottom of the Channel Editor menu displays the remote buttons you need to press to apply Channel Editor functions.
  • Page 42 When you press the button, the following menu is available. TOOLS Edit Channel Number Use Edit Channel Number to change the channel number of a channel you select. To change a channel number, follow these steps: 1. Select a channel on the Channel Edit screen. Channel 2.
  • Page 43: Installing The Wall Mount

    For detailed information on installing the wall mount, see the instructions provided with the wall mount. Contact a technician for assistance when installing the wall mount bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you select to install the TV on your own.
  • Page 44 Do not fasten the screws too firmly. This may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.
  • Page 45 Assembling the Cable clip Assembling the Screw Cover Assembling the Power inlet Cover English...
  • Page 46 Securing the TV to the Wall Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do not hang on or destabilize the TV. Doing so may cause the TV to tip over, causing serious injuries or death.
  • Page 47: Important Information

    4. Fasten the Holder to the cabinet using a wood screw. ✎ Using an M5 x L35 or a larger screw. 5. Fasten the Holder with a screw the same way used when attaching it to a cabinet. Make sure to stretch the Holder cord tight.
  • Page 48: Anti-theft Kensington Lock

    Refer to the manual provided with the Kensington Lock for additional information on proper use. The Kensington Lock is not supplied by Samsung. ✎ Please find the “K” icon on the rear of the TV. A Kensington slot is <Optional>...
  • Page 49: Specifications

    Specifications Display Resolution 1920 x 1080 Environmental Considerations Operating Temperature 50°F to 104°F (10°C to 40°C) Operating Humidity 10% to 80%, non-condensing Storage Temperature -4°F to 113°F (-20°C to 45°C) Storage Humidity 5% to 95%, non-condensing Stand Swivel (Left / Right) 0˚...
  • Page 50: Dimensions

    Dimensions HG46NB890 / HG55NB890 / HG65NB890 ▪ Front view / Side view (unit: Inches) 40.6 23.6 24.9 10.1 HG46NB890 48.1 27.8 29.2 12.2 HG55NB890 56.98 32.98 34.49 1.51 13.00 HG65NB890 ▪ Jack panel detail / Rear view VARIABLE AUDIO OUT VOL-CTRL (HDD 5V 1A) AUDIO...
  • Page 51 SAMSUNG will additionally provide Warranty Repair Service in the United States on SAMSUNG products purchased in Canada, and in Canada on SAMSUNG products purchased in the United States, for the warranty period originally specified, and to the Original Purchaser only.
  • Page 52 Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Samsung Hospitality Hotline: 866-894-0524 Web site: http://www.samsung.com/us/business HG890-ZA-00...
