Quatech DS-100 User Manual

Two channel rs-232 asynchronous serial adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Two Channel RS-232 Asynchronous
INTERFACE CARDS FOR IBM PC/AT AND PS/2
QUATECH, INC.
5675 Hudson Industrial Parkway
Hudson, Ohio 44236
DS-100
Serial Adapter
for ISA compatible machines
User's Manual
TEL: (330) 655-9000
FAX: (330) 655-9010
http://www.quatech.com

Advertisement

Table of Contents
loading

Related Manuals for Quatech DS-100

Summary of Contents for Quatech DS-100

  • Page 1 DS-100 Two Channel RS-232 Asynchronous Serial Adapter for ISA compatible machines INTERFACE CARDS FOR IBM PC/AT AND PS/2 User's Manual QUATECH, INC. TEL: (330) 655-9000 5675 Hudson Industrial Parkway FAX: (330) 655-9010 Hudson, Ohio 44236 http://www.quatech.com...

  • Page 2: Warranty Information

    No representation is made regarding the suitability of this product for any particular purpose. Quatech Inc. reserves the right to edit or append to this document or the product(s) to which it refers at any time and without notice.
  • Page 3 The authors have taken due care in the preparation of this document and every attempt has been made to ensure its accuracy and completeness. In no event will Quatech, Inc. be liable for damages of any kind, incidental or consequential, in regard to or arising out of the performance or form of the materials presented in this document or any software programs that might accompany this document.

  • Page 4: Declaration Of Conformity

    Declaration of Conformity Manufacturer's Name: Quatech Inc. Manufacturer's Address: 5675 Hudson Industrial Parkway Hudson, Ohio 44236 (USA) Application of Council Directive: 89/336/EEC Standards to which Conformity is Declared: * EN50082-1 EN61000-4-2, EN61000-4-3, EN61000-4-4 * CISPR 22 (EN55022) Type of Equipment:...

  • Page 5: Table Of Contents

    ........... . Quatech Inc.

  • Page 6: General Information

    0008 hex intervals. Available interrupt levels include IRQ2 to IRQ7, IRQ10 to IRQ12, IRQ14, or IRQ15. Both ports on the DS-100 can share one interrupt level or an interrupt level can be shared with another Quatech adapter that supports interrupt sharing. The shared interrupt feature minimizes the system resources consumed by the adapter.
  • Page 7 (This Page Intentionally Left Blank) Quatech Inc.

  • Page 8: Installation

    Figure 1 --- Default address and IRQ settings for DS-100 The output of the DS-100 is two 9-pin D-connectors labeled CN1 (serial 0) and CN2 (serial 1). 1. If the default settings are correct, skip to step 2, otherwise refer to sections 4 and 5 of this document for detailed information on how to set the address and IRQ level.
  • Page 9 IRQ15 IRQ14 IRQ12 IRQ11 IRQ10 IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 IRQ2 Figure 2 --- Diagram of DS-100 Quatech Inc.

  • Page 10: Windows 2000 Configuration

    IRQ levels, and DMA channels. The “Add New Hardware Wizard” utility in Windows is designed to add new hardware and update this registry. Windows 2000 will not automatically configure the DS-100. The user is required to manually configure Windows 2000 to match the resources set on the card.
  • Page 11 2. Double click on the “Add New Hardware” icon. Quatech Inc.
  • Page 12 3. The next window will be the “Welcome to the Hardware Wizard”, click “Next”. 4. Next choose the “Add/Troublshoot a device” radio button, click “Next”. Quatech Inc.
  • Page 13 Quatech Inc.
  • Page 14 Quatech Inc.
  • Page 15 Quatech Inc.
  • Page 16 7. Next select “Ports (COM & LPT)”, click “Next”. Quatech Inc.
  • Page 17 8. In the next window under manufacture select “(Standard port types), and under Models select “Communications Port. Because Windows will not detect plug and play you will have to manually enter the settings. Click “OK”. Quatech Inc.
  • Page 18 9. Next you will have to change the “Input/Output Range” to a setting that is not in use “No conflicts” by choosing a different “Basic Configuration”. Quatech Inc.
  • Page 19 10. The “Input Request” (IRQ) must be set to corresponds with the jumpers setting on the DS-100 board. 3-10 Quatech Inc.
  • Page 20 Once you have chosen the IRQ that corresponds with the setting on the Quatech DS-100 card the window will display “no conflicts” and the red circle with a slash of the “Input/Output Range” will not be present. 3-11 Quatech Inc.
  • Page 21 11. Next Windows will begin the install the hardware, click “Next”. 3-12 Quatech Inc.
  • Page 22 12. Next the “Completing the Add/Remove Hardware Wizard” will appear, click “Finish”. 3-13 Quatech Inc.
  • Page 23 13. Next Windows will prompt you to restart the computer so the changes will take effect and show the new ports. Select “No” to install the second port. Repeat the same process to install the second channel. Finally, in order for the changes to take effect you will have to restart the computer. 3-14 Quatech Inc.

  • Page 24: Windows 95 Configuration

    Windows 95 environment . Also, a custom Windows 95 serial device driver is included with the DS-100 to support the use of the FIFOs on the 16550 UARTs. Windows 95 uses the “INF” file to determine the system resources required by the DS-100, searches for available resources to fill the requirements of the board, and then updates the hardware registry with an entry that allocates these resources.
  • Page 25 6. An Install From Disk dialog box should pop up. Insert the diskette with the Quatech INF files on it, select the correct drive letter, and click the “OK” button. Windows 95 automatically browses the root directory for an INF file that defines configurations for Multi-function Adapters.

  • Page 26: Viewing And Changing Resources With Device Manager

    3. Double click the device group “Multi-function Adapters”. The DS-100 model name should appear in the list of Multi-function adapters. Figure 3--- Windows 95 Device Manager 4. Double click the DS-100 model name and a properties box should open for the hardware adapter. 3-17...
  • Page 27 Click “OK” to save your changes, or “Cancel” to abort. 7. The DS-100 serial ports are also listed under the group Ports (Com and LPT). Windows 95 does not assign COM1 - COM4 to ports addressed at nonstandard locations. The DS-100 ports will be enumerated starting with COM5 (or higher) even if lower logical numbers are available.
  • Page 28 10. Use the Logical COM Ports numbers to access the serial ports on your DS-100 through your software applications. Note: The Logical COM Port name is assigned to your ports by Windows 95. This name is required by a Windows 95 application when accessing a particular port.
  • Page 29 (This Page Intentionally Left Blank) 3-20 Quatech Inc.

  • Page 30: Addressing Ports

    5. Addressing Ports 5.1 Setting the address The base address of each port of the DS-100 is set using two DIP switch packs. When setting the address selection switches, a switch in the "ON" position specifies that the corresponding address line must be a logic 0 for the port to be selected. Similarly, a switch in the "OFF"...
  • Page 31 Factory default setting for Serial 1 --- 03F8 hex (COM1) enable/disable Factory default setting for Serial 2 --- 02F8 hex (COM2) enable/disable enable/disable Example: 03E8 hex (typical for COM3) enable/disable Example: 02E8 hex (typical for COM4) Figure 6 --- Serial Port base I/O address selection switches Quatech Inc.

  • Page 32: Enabling Or Disabling Ports

    Figure 7 --- Recommended addresses for serial ports 5.2 Enabling or disabling ports Each port of the DS-100 may be individually enabled or disabled. To enable a port, move the appropriate switch to the "ON" position. To disable a port, move the switch to the "OFF"...

  • Page 33: Interrupt Level (Irq)

    6. Interrupt Level (IRQ) The DS-100 allows the use of any interrupt level in the range IRQ2 to IRQ7, IRQ10 to IRQ12, IRQ14, or IRQ15, selected using jumper block J3 (for Serial 0) or J4 (for Serial 1). In Figure 9, the factory default settings for Serial 0 and Serial 1 are shown.

  • Page 34: Interrupt Sharing

    6.1 Interrupt Sharing Both ports on the DS-100 can share the same interrupt level or they can share their interrupt with another Quatech adapter supporting sharable interrupts. Jumper J2 can be used to connect the UART generated interrupt directly to the selected IRQ or to enable the interrupt sharing circuit.

  • Page 35: External Connections

    DTE-type devices. A typical null modem cable is also shown in Figure 12. (20) (20) (20) (20) (20) (22) (22) (22) (22) (22) (22) Typical DTE-to-DCE cable Typical DTE-to-DTE null modem cable Figure 12 --- Cabling requirements for EIA/TIA-232-E devices (cables using 25-pin connectors shown) DS-100 User’s Manual...
  • Page 36 To simplify connections to other devices, each port on the DS-100 is equipped with a jumper block that allows the port to be configured as either a DTE- or DCE-type device. This allows the DS-100 to communicate with either DTE- or DCE-type devices without using a null modem cable.
  • Page 37 The DS-100 connects to peripheral equipment through male D-9 connectors. Adapters are available to convert these connectors into standard D-25 male connectors. The standard serial port connections are listed in Figure 14. RS-232 Signal DTE Connection DCE Connection Description D-25...
  • Page 38 (This Page Intentionally Left Blank) DS-100 User’s Manual...

  • Page 39: Specifications

    BASE ADDRESS RANGE: 0000 hex to FFF8 hex INTERRUPT OPTIONS: 2-7, 10-12, 14-15 CONNECTORS: Two DB-9 male connectors SLOT REQUIREMENTS: One 16-bit ISA slot DIMENSIONS: 7.050” x 3.900” POWER REQUIREMENTS: +5 volts 908 mA max +12 volts 66 mA max Quatech Inc.
  • Page 40 60 mA max TEMPERATURE: Operating 0° to 70° Storage -50° to 80° HUMIDITY: 10% to 90% APPROVALS AND CERTIFICATIONS: FCC, CE, Windows 95, Windows NT OS SUPPORT:Windows 2000, Windows 95, Windows 3.1, Windows NT 4.0, OS/2 2.0, DOS 6.22, UNIX Quatech Inc.
  • Page 41 Any unauthorized repairs or modifications will void the DS-100's warranty. Computer will not boot up. 1. Is the DS-100 properly inserted? Remove the card and try again. Perhaps try a different expansion slot. 2. Is the base address correctly set? Check for address conflicts with other devices in the system.
  • Page 42 DS-100 User's Manual Revision 4.21 March 2004 P/N: 940-0048-421...
