WINE CELLAR INSTALLATIONS

INSTALLATION LImITATIONS

• Do not install your wine cellar in any location not properly insulated or heated e.g. garage etc.
Your wine cellar was not designed to operate in temperature settings below 60˚ F or above 90˚ F.
• Select a suitable location for the wine cellar on a hard even surface away from direct sunlight or
heat source e.g. radiators, baseboard heaters, cooking appliances etc. Any floor unevenness should
be corrected with the leveling legs located on the front and rear bottom corners of the wine cellar.

DImENSIONS

• Built-in wine cellars need to be ventilated from the front. This feature allows the unit to be built in an
enclosed area. The bottom front grille should be clear of all obstructions. This is absolutely
necessary for the air to circulate and for the unit to operate efficiently. The dimensions for
installation are as follows. (W x D x H)
Unit Dimensions: 23-7/16" x 24-1/2" x 33-11/16"

CHOICES

• As the doors of the built-in wine cellars are reversible, 2 wine cellars could be placed side by side
with the doors opening from the middle. This would not only allow you more storage space but also
better placement of your wine collection. The red wines could be separate from the white wines.
Before installing make sure there is enough space for installation and that both the units are plugged
into separate power receptacles.
33-11/16"
24-1/2"
(picture for reference only)
HSVCE24ABH
23-7/16"
