HVFM122ABL(USA HAC)

Wine Cooler

Service
Manual
HVFM122ABL
Features
●Optimized for Preservation of Wine Flavors.
●Temperature adjustable,
control .
mechanical
●Temperature range:A-3~A+3℃(A=7~15).
●Interior lights.
●wine rack.
Haier Group
Manual No.:HVFM122ABL(USA HAC)
Edition:20031120
1
PDF created with pdfFactory trial version
www.pdffactory.com

Advertisement

loading

  Also See for Haier HVFM122ABL

  Related Manuals for Haier HVFM122ABL

  Summary of Contents for Haier HVFM122ABL

  • Page 1: Wine Cooler

    HVFM122ABL(USA HAC) Wine Cooler Service Manual HVFM122ABL Features ● ●Optimized for Preservation of Wine Flavors. ●Temperature adjustable, control . mechanical ●Temperature range:A-3~A+3℃(A=7~15). ●Interior lights. ●wine rack. Haier Group Manual No.:HVFM122ABL(USA HAC) Edition:20031120 PDF created with pdfFactory trial version www.pdffactory.com...
  • Page 2: Table Of Contents

    CONTENTS Contents 1. Contents…………………………………………………… ………….……. 1 2. Product Code illustration and Series Introduction…………………… . …2 3. Features ……………………………………………………………………...3 4. Specifications…………………………………………………………………4 …...6 5. Safety Precautions(including Warning and Cautions)…………… … 6. Net Dimension……………………………………………………..………...8 7. Installation and Accessory Parts…………………… ……………..…….…9 8. Parts and Functions………………………………… ………….….………11 9.
  • Page 3: Product Code Illustration And Series Introduction

    PRODUCT CODE ILLUMINNATION AND SERIES INTRODUCTION Product Code illustration and Series Introduction J C-□ G □ A B C D E A: The first letter of “wine” in Chinese spelling. B: Abbreviation of Cooler or Cellar. C: Capacity .( Unit: Liter ). D:G stands for “Freon free”.
  • Page 4: Features

    nitial Setup l Your wine cooler has temperature control knob on the top of the unit. There are 6 settings: 1 being the warmest and 7 being the coolest. You an set the temperature of your wine cooler at any setting you desire. The wine cooler will maintain a temperature range between 4℃...
  • Page 5: Specifications

    (w / b / g / s) Inside door/-drawers (w=white t=transpar.) www.pdffactory.com SPECIFICATIONS kg/24 h kWh/year V/Hz °C °C °C Drawer(soft freezer) kWh/year kWh/24 h HVFM122ABL Haier Wine cooler 343.1 R134a CP-IP 115 V~/60 4-~-18 121.70 0.33 black Silver gray - / -...
  • Page 6 Shelves: Drawers: Crisper: Salad crisper(s) Food baskets: Equipment & Accessories Control Panel: Interior light Adjustable feet Castors Wall spacer grid /-distance holder / Flush back Product dimensions Unit dimensions Depth with open door Net weight Packing dimensions & loadability Packing dimensions Gross weight 40 ' Container load 40 ' HC Container load...
  • Page 7: Safety Precautions(Including Warning And Cautions)

    Read all of the instructions before using this appliance. When using this appliance ,always exercise basic safety precautions, including the following: 1. Use this appliance only for its intended purpose as described in this use and care guide. 2. This wine cooler must be properly installed in accordance with the installation section.
  • Page 8 9. Do not store foods in wine cooler as interior temperature may not be cool enough to prevent spoilage. PDF created with pdfFactory trial version www.pdffactory.com...
  • Page 9: Net Dimension

    Net Dimension Model HVFM122ABL Unit Dimersion(W*D*H) 595*640*1850 Dimersion 595*640*1170 (Opening door:135 PDF created with pdfFactory trial version www.pdffactory.com...
  • Page 10: Installation And Accessory Parts

    Unpacking Your Wine Cooler 1.Remove all packaging material, This includes the foam base and all adhesive tape holding the wine cooler accessories inside and outside ,compressor from shipping damage due to vibration and shock. 2.Inspect and remove any remains of packing ,tape or printed materials before powering on the wine cooler.
  • Page 11 Electrical Requirement l Make sure there is a suitable power Outlet(115V)with proper grounding to power the wine cooler. l Avoid the use of three plug adapters or cutting off the third grounding in order to accommodate a two plug outlet ,This is a dangerous practice since it provides no effective grounding for the wine cooler and may result in shock hazard.
  • Page 12: Parts And Functions

    Model ● HVFM122ABL PDF created with pdfFactory trial version ● ● ● ● ● www.pdffactory.com Parts and Functions ● ● ●...
  • Page 13: System Flow Chart

    Schematic Diagram of Refrigerating Principle Brief Description of Refrigerating Principle The refrigerating system of direct cooling single-system freezer belongs to the category of single-temperature and single-control refrigerating system with only one evaporator and is controlled by a single temperature control.
  • Page 14: Function Schedule

    Function Schedule Function Schedule Function Description Green lamp Work indicator light Thermostat Adjust Thermostat knob light Press the light switch The illustration of the function in the subject of “Features”. PDF created with pdfFactory trial version www.pdffactory.com...
  • Page 15: Circuit Diagram

    Circuit Diagram PDF created with pdfFactory trial version www.pdffactory.com...
  • Page 16: Maintenance Service And Trouble Shooting

    Trouble Shooting Maintenance Service and Trouble Shooting Cleaning and Maintenance Warning: To avoid electric shock always unplug your wine cooler before cleaning, Lgnoring this warning may result in death or injury. Caution: Before using cleaning products, always read and follow manufacture’s instructions and warnings to avoid personal injury or product damage.
  • Page 17: Trouble Shooting

    MAINTENANCE SERVICE AND TROUBLE SHOOTING Maintenance Service and Trouble Shooting causes, Remove the power cord from AC outlet when a power outage occurs, When power has been restored ,replug power cord to AC outlet. Vacation and Moving Care l For ling vacations or absences ,unplug the wine cooler and clean the wine cooler and door gaskets according to “General cleaning “...
  • Page 18 MAINTENANCE SERVICE AND TROUBLE SHOOTING Maintenance Service and Trouble Shooting Wine cooler runs too frequently l This may be normal to maintain constant temperature during high temperature and humid days. l Doors may have been opened frequently or for an extended period of time . l Clean condenser coils, l Check gasket for proper seal.
  • Page 19: Exploded View

    Exploded View PDF created with pdfFactory trial version www.pdffactory.com...
  • Page 20: List Of Parts

    Compressor External 0075020155 wile clip Compressor 0075020293 protector 0075020292 Starter 0075020160 Protect cover 0072040090 Water box 0074160001 Evaporator link tube HVFM122ABL 0070201801 Soft water tube 0074180002 Filer drier 0074000027 Ballast 0074090529 Lamp starter 0074000075 Lamp starter holder Protect-cover 0071210088 compartment...
  • Page 21: Exlpoded View

    The customer needs not stock in the spare-part warehouse, should be marked 5,Above should be improved accord with the reply of the market half a year per time. 6.The spare parts price on net is FOB Qingdao term. PDF created with pdfFactory trial version HVFM122ABL 0.50% HVFM122ABL 0.01% HVFM122ABL 0.50%...
  • Page 22 PDF created with pdfFactory trial version www.pdffactory.com...
