Summary of Contents for Barco MFCD 1219
- Page 1 B4100528 / 03 November2005 MFCD 1219 - MFCD 1219 TS Installation & User Manual...
-
Page 2: Safety Instructions
Operation of this equipment serious injury to a child or cords plugs in a residential area is likely adult, and serious damage receptacles. cause harmful to the equipment. interference in which case © 2005 BARCO nv. Allrights reserved. -
Page 3: Table Of Contents
Main menu ....................13 Color Menu ....................14 Clock Menu ....................15 4. Maintenance ....................16 Panel ......................16 Cabinet ....................16 Touch panel ..................... 16 Appendix A: Possible resolutions ..............17 Appendix B: Technical specifications ............. 18 MFCD 1219 (TS) User's Guide... -
Page 4: Overview
1. OVERVIEW 1.1 Introduction The MFCD 1219 (TS), BARCO’s full color 19” LCD display, guarantees perfect image quality in medical imaging applications. The display combines a TFT (thin film transistor) liquid crystal display panel structure and a built-in backlight with inverter for a better picture quality. -
Page 5: Touch Panel
Hsync or Vsync signals. This feature is compliant with VESA DPMS. Touch panel The MFCD 1219 TS is equipped with a touch panel. Instructions on how to install and use the touch panel driver and controls can be found in the "TouchKit, Barco TouchScreen controller... -
Page 6: Controls And Connectors
The LED is off when the display is off. The LED is green when the display is on. The LED is orange when the display is in power-saving mode (stand-by) Power key (10) Push-button to release the panel from the foot MFCD 1219 (TS) User's Guide... -
Page 7: Installation
Step 1: Remove the panel from the foot Position one hand under the panel at the front side. Position the other hand at the rear, under the push-button with BARCO logo (9). Firmly press down the push-button (9) with one hand while carefully lifting the panel up with the other hand. -
Page 8: Step 3: Place The Panel On The Mounting Plate
Place the panel on the mounting plate (C). If you want to secure the panel to the mounting plate, place the panel in the frontmost notches. Please make sure that the four shafts are securely placed in the notches of the mounting plate. MFCD 1219 (TS) User's Guide... -
Page 9: Connecting The Signals
AC input of the 12V DC adapter. Connect the 12V supply of the 12V DC adapter to the DC input (1) of the monitor. Connect the other end of the power cord to a grounded power outlet. MFCD 1219 (TS) User's Guide... -
Page 10: Install The Software
CD-ROM starts automatically. Please follow the instructions on the screen. The CD-ROM contains user instructions about the usage of the NioWatch. Touch panel software: Please refer to the TouchKit installation & user manual on CD-ROM. MFCD 1219 (TS) User's Guide... -
Page 11: On-Screen Display (Osd) Menus
Color > Clock > RED indicates the function is Languages > selected and ready to be Input Type > adjusted. Lock Controls Blinking RED indicates OSD is in Cancel Save & Exit parameter adjusting mode. MFCD 1219 (TS) User's Guide... -
Page 12: Description Of The Menu Items
When the system is changed to this mode again later on, the system will not repeat the Auto Adjust function. This function is only valid when the mode concerned is selected for the first time. MFCD 1219 (TS) User's Guide... -
Page 13: Color Menu
To adjust the level of color Red. Main Menu > To adjust the level of color Green. 1024 x 768 - 60.1 48.4k To adjust the level of color Blue. Main Menu To return to Main Menu. MFCD 1219 (TS) User's Guide... -
Page 14: Clock Menu
Right-click on the NioWatch systray icon. Select Test Patterns from the pop-up menu. Select the SMPTE test pattern. Now perform the function Autobalance from the MFCD 1219 (TS) control panel. When finished, click on the test pattern to close it. Clock Menu Function... -
Page 15: Maintenance
Repeat this with water only and wipe dry with a dry cloth. Touch panel (Only for MFCD 1219 TS) Use a clean and soft clothe with neutral detergent or with ethanol for cleaning. Do not use any chemical solvent, acidic or alkali solution. -
Page 16: Appendix A: Possible Resolutions
832 x 624 57.29 49.80 74.6 1024 x 768 65.00 48.36 VESA 75.00 56.50 VESA 78.80 60.02 VESA/CRUS 60.24 94.50 68.70 VESA 1152 x 864 67.50 VESA 1280 x 1024 63.98 VESA VESA 157.5 91.146 VESA MFCD 1219 (TS) User's Guide... -
Page 17: Appendix B: Technical Specifications
RGB Sync types: Separate sync, interface composite sync, sync on Green Touch panel (MFCD 1219 TS only) Digital: Hor. 31.47 to 64 kHz Resistive technology Vert. 60 to 70 Hz Interface: USB 1.1 Input mode: stylus or finger Touch active force (stylus ∅... - Page 18 450 mm x 461.8 mm x 213.9 mm CONTAINED HEREIN; NOR FOR INCIDENTAL OR CONSEQUENTIAL Net weight DAMAGES WHATSOEVER 7.7 kg RESULTING FROM FURNISHING, MFCD 1219 TS: 8.3 kg PERFORMANCE OR USE OF THIS MATERIAL. Operating Temperature 0°C to 40°C Storage Temperature -20°C to 60°C...
