B410024 / 02
November 2002
© 2002 BARCO NV. All rights reserved
MFGD 3220 D
BarcoView
Theodoor Sevenslaan 106
8500 Kortrijk, Belgium
Phone: +32(0)56 23 32 44
Fax: +32(0)56 23 33 74
E-mail: sales.medical@barco.com
http://www.barcoview.com
BarcoView Inc
3059 Premiere Parkway
Duluth, Georgia, 30097,USA
Phone: +1 678 475 8000
User Manual
Fax: +1 678 475 8100
E-mail: sales.medical@barco.com
http://www.barcoview.com
BarcoView LTD
16F-1, Cheng Loong Plaza 33, Min Sheng Road
Section 1, Pan Chiao, Taipei Hsien, Taiwan, R.O.C.
Phone: +886 2 2957 8357
Fax: +886 2 2957 4080
Advertisement
Table of Contents
Related Manuals for Barco MFGD 3220 D
Summary of Contents for Barco MFGD 3220 D
- Page 1 B410024 / 02 November 2002 © 2002 BARCO NV. All rights reserved MFGD 3220 D BarcoView Theodoor Sevenslaan 106 8500 Kortrijk, Belgium Phone: +32(0)56 23 32 44 Fax: +32(0)56 23 33 74 E-mail: sales.medical@barco.com http://www.barcoview.com BarcoView Inc 3059 Premiere Parkway...
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS Operation of this equipment • Read the safety and Water and moisture in a residential area is likely operating instructions before • Never expose cause harmful operating the apparatus. apparatus to rain or moisture. interference in which case •... - Page 3 MFGD 3220D User's Guide...
-
Page 4: Table Of Contents
CONTENTS 1. Overview ......................7 1.1 Introduction ....................7 1.2 Package contents ..................8 1.3 Controls and connectors ................8 2. Installation ..................... 10 2.1 Precautions ..................... 10 2.2. Before installing the display ..............10 2.3 Portrait or landscape position ..............11 2.4 Connecting the signals ................ - Page 5 MFGD 3220D User's Guide...
-
Page 6: Overview
1. OVERVIEW 1.1 Introduction The MFGD 3220D, BARCO’s 21” 3 megapixel greyscale LCD display, guarantees perfect image quality in medical imaging applications. The display combines a TFT (thin film transistor) liquid crystal display panel structure and a built-in backlight with inverter for a better picture quality. It... -
Page 7: Package Contents
1.2 Package contents The package should include the following items, please check. If some of the items are missing, please contact the reseller you have purchased the unit from. The MFGD 3220D display 12V DC power supply European power cord American power cord Video cable This user manual... - Page 8 Power LED - The LED is off when the display is off. - The LED is green when the display is on. Note: This function can be switched off by software. - The LED is blinking green when the display is in Suspend power-saving mode. - The LED is orange when the display is in Stand-by power-saving mode.
-
Page 9: Installation
2. INSTALLATION 2.1 Precautions • Keep your original packaging. It is designed for this display and is the ideal protection during transport. • Avoid reflections in the flat panel to reduce eye strain. • Place the display on a strong and stable table or desk. -
Page 10: Portrait Or Landscape Position
Pull the red strap out of the fixation holes in the foot. You can better leave the cover off the foot while connecting the signal cables to the display. 2.3 Portrait or landscape position You can change the orientation of the panel at any time, but it is more convenient to select landscape or portrait orientation before connecting the cables. -
Page 11: Connecting The Signals
2.4 Connecting the signals To get access to the connectors, open the cover of the connector compartment by pulling down the 2 clips of the cover. To connect the video & sync signals: Connect one end of the video cable to the DVI input (5) of the display. -
Page 12: Routing The Signal Cables
Connect the other end of the power cord to a grounded power outlet. 2.5. Routing the signal cables After connecting all cables, fix them in the cable tie at the rear of the connector compartment. You can also bind the cables together by means of the 2 velcro strips included in the package. -
Page 13: Tilt And Swivel Positioning
2.6 Tilt and swivel positioning Adjust the position of the panel for best viewing conditions. The display foot allows adjusting the panel height, horizontal viewing angle and vertical viewing angle. 2.7 Starting up Proceed as follows: Switch on the computer. If necessary, select a suitable resolution in the computer operating system. -
Page 14: Controls
CONTROLS The control wheel (2) at the bottom (landscape orientation) or at the side (portrait orientation) allows you to perform some controls. You can switch the display in stand-by and control the brightness. 3.1 Stand-by switching When the display is on, depress the control wheel slightly to switch the display in stand-by. -
Page 15: Maintenance
We recommend to let this cleaning procedure be done in a BARCO service center. However, when really necessary, you can perform the cleaning on site if you can work in conditions that are as clean and dust-free as possible. -
Page 16: Troubleshooting
5. TROUBLESHOOTING Pixel Faults Permanently dark or bright pixels can happen to TFT displays. 20 or less permanently dead pixels do not make out a good case for exchanging the unit. Please contact our Customer Service Department if the number of pixel faults exceeds the above- mentioned figure. -
Page 17: Technical Specifications
6. TECHNICAL SPECIFICATIONS Picture panel 20.8-inch diagonal viewable screen TFT (thin film transistor) active matrix, greyscale liquid crystal display Resolution Native: 2048 x 1536 Display area (H x V) 423.7 x 318 (mm) Viewing angle (@ 10/1 contrast) Vertical: 170º Horizontal: 170º... - Page 18 DUE TO OUR POLICY OF CONTINUOUS PRODUCT IMPROVEMENT, THE ABOVE SPECIFICATIONS ARE SUBJECTED TO CHANGE WITHOUT NOTICE. BARCO SHALL NOT BE LIABLE FOR TECHNICAL OR EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN; NOR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES WHATSOEVER RESULTING FROM...
