- Page 1 Figure: AX-1E ® ATCOM Digital Card AX-1E Product Guide Version: 1.0 Written by Robert.Ao 09-02-2010...
-
Page 2: Table Of Contents
Content CONTACT ATCOM ..........................2 CHAPTER 1 THE INTRODUCTION OF AX-1E ..................3 CHAPTER 2 HARDWARE SETTING ....................... 4 CHAPTER 3 SOFTWARE INSTALLATION....................5 CHAPTER 4 SOFTWARE CONFIGURATION ................... 7 CHAPTER 5 TESTING ........................... 9 CHAPTER 6 REFERENCE ........................10... -
Page 3: Contact Atcom
Contact ATCOM The Introduction of ATCOM Founded in 1998, ATCOM technology has been always endeavoring in the R&D and manufacturing of the internet communication terminals. The product line of ATCOM includes IP Phone, USB Phone, IP PBX, VoIP gateway and Asterisk Card. -
Page 4: Chapter 1 The Introduction Of Ax-1E
Chapter 1 the Introduction of AX-1E Overview of the AX-1E AX-1E Asterisk card is the telephony PCI card that supports one ISDN PRI E1 port. Using AX-1E digital PRI card, open source Asterisk PBX and stand alone PC, users can create their IP PBX telephony solution which includes all the sophisticated features of traditional PBX and extended features such as voicemail in IP PBX. -
Page 5: Chapter 2 Hardware Setting
LEDs: If the port is connected to E1 cable successfully, one of the red LED will be red stable, once the channel is busy (during communication), both of the two red LEDs will be red stable. Please do not care about the other two green LEDs. www.atcom.cn... -
Page 6: Chapter 3 Software Installation
Install mISDN [root@localhost src]# tar -xvzf mISDN.tar.gz [root@localhost src]# cd mISDN-1_1_9.1/ [root@localhost mISDN-1_1_9.1]# make [root@localhost mISDN-1_1_9.1]# make install Install mISDNuser 1) [root@localhost src]# tar -xvzf mISDNuser.tar.gz 2) [root@localhost src]# cd mISDNuser-1_1_9.1/ 3) [root@localhost mISDNuser-1_1_9.1]# make 4) [root@localhost mISDNuser-1_1_9.1]# make install www.atcom.cn... - Page 7 Install asterisk 1) [root@localhost src]# tar -xvzf asterisk-1.4.29.tar.gz 2) [root@localhost src]# cd asterisk-1.4.29 3) [root@localhost asterisk-1.4.29]# ./configure 4) [root@localhost asterisk-1.4.29]# make 5) [root@localhost asterisk-1.4.29]# make install 6) [root@localhost asterisk-1.4.29]# make samples www.atcom.cn...
-
Page 8: Chapter 4 Software Configuration
[ii] make your port (1) available in asterisk by editing "/etc/asterisk/misdn.conf The port of AX-1E works in TE mode by default setting, customer can change it to work in NT mode by editing file /etc/misdn-init.conf, find one line “te_ptmp=1”, then change it to “nt_ptmp=1”, after this, please run misdn-init restart to make the setting effect. - Page 9 /sbin/modprobe mISDN_dsp debug=0x0 options=0 poll=128 dtmfthreshold=100 To check if the driver of AX-1E is loaded successfully, please run cat /proc/interrupts, getting one line with HFC-multi, and the number of interrupt increases after running cat /proc/interrupts again, it proves that the driver of AX-1E is loaded successfully.
-
Page 10: Chapter 5 Testing
6. Please use a registered sip phone to call 111, then two of the LEDs turn to red stable, it show s the following information: *CLI> -- Executing [111@from-internal:1] Dial("SIP/500-00000002", "misdn/1/111") in new stack -- Called 1/111 -- mISDN/1-u8 is proceeding passing it to SIP/500-00000002 -- mISDN/1-u8 answered SIP/500-00000002 www.atcom.cn... -
Page 11: Chapter 6 Reference
Chapter 6 Reference http://www.misdn.org/index.php/Main_Page http://www.asteriskguru.com/ http://www.asterisk.org/downloads http://www.openippbx.org/index.php?title=Main_Page http://www.atcom.cn/ www.atcom.cn...
