  • Page 1 Internet Telephony Gateway VIP-160/VIP-260 User’s manual...
  • Page 2 Copyright (C) 2004 PLANET Technology Corp. All rights reserved. The products and programs described in this User’s Manual are licensed products of PLANET Technology, This User’s Manual contains proprietary information protected by copyright, and this User ’s Manual and all accompanying hardware, software, and documentation are copyrighted.
  • Page 3 Home System Uptime: specifies the amount of time, which the system has been up. This time is reset every time the system is reset. LAN IP Address: indicates the IP Address of your LAN. MAC address: MAC address is the address of your MAC. Security: for your password, which is configured in the “System”...

  • Page 4: Network Status

    Network Network status Interface Status: these are the details of your interface’s status. Enabled: “Yes”, lets you know that your interface is enabled and ready to be used. Service: either “Routed or Bridged”, tells you the level of your interface’s connection.
  • Page 5 MAC address: Your specified MAC address. Subnet Mask: indicates the IP address of your mask. Default Gateway: is the IP address of the gateway. The gateway IP could be retrieved from DHCP offer in DHCP mode, or be set up manually in fixed IP mode.

  • Page 6: Wan Configuration

    WAN Configuration 1. Device Operating Mode: you choose either “Router” or “Bridge”, depending on your operation. 2. You will check either “Obtain WAN configuration dynamically” or “Specify fixed WAN configuration”. When you choose “Obtain WAN configuration dynamically”, the information is detected automatically through DHCP. If you choose “Specify fixed WAN configuration”, you are required to enter the IP address, IP of the Sub mask, IP of the Gateway, and IP of the DNS Server, if applicable.

  • Page 7: Wan Pppoe Configuration

    WAN PPPoE Configuration 1. Enable PPPoE: “Yes” or “No”, to enable/disable PPPoE 2. Under “Authentication”, you enter the username and password given by your ISP. 3. Settings: Idle Timeout: Idle timeout before PPP connection is closed due to inactivity Echo Timeout: the duration between PPP echo requests being sent to the server.
  • Page 8 MAC Cloning Configuration WAN MAC Address (Spoofed): This is only available when devices are under the router mode. The spoofed MAC address to be used by the device’s WAN interfaces, the Ethernet address of the outgoing packets from the WAN interface would be replaced with this address.

  • Page 9: Lan Configuration

    LAN Configuration 1. Under “Network Settings”, you enter the IP address and subnet mask of your network.

  • Page 10: Dhcp Server Configuration

    DHCP Server Configuration These configuration parameters are for the device’s internal DHCP server. 1. Server Setting: “Yes” or “No”, to enable/disable DHCP Client IP Address Range: Minimum and Maximum limit on the DHCP IP address pool 2. Client Network Information Domain Name: LAN domain name provided to DHCP clients during the OFFER process.

  • Page 11: Port Forwarding Configuration

    Port Forwarding Configuration 1. Under “Reserved Ports”, specified are the ports, which cannot be forwarded to the LAN. 2. Under “Port Forwarding to LAN”, you enter the specifications, which you will be forwarding to the LAN, including port range, protocol(Both, TCP or UDP), and destination IP address.

  • Page 12: Sip Configuration

    SIP Configuration 1. Under “SIP Server Settings”, you enter the server address, port, domain name, and expiration time unit, if you choose to send a registration request with an expiration time. 2. Gateway Settings Dial Plan: refer to appendix A of this guide # use as a quick dial function: If this box is checked, the dialed digits would be sent out when the ‘#’...

  • Page 13: Sip Extensions

    SIP Extensions 1. Support PRACK method: enable SIP PRACK support. 2. Encode SIP URI with user parameter: encode user=phone parameter in SIP URI. 3. Send INVITE with Timer header: encode Timer header in all INVITE requests for ringing timeout 4. SIP session timer: enable SIP session timer function. 5.

  • Page 14: Dtmf Configuration

    DTMF Configuration This sub-page allows configuration of the out-of-band signalling options for SIP. Select whether OOB telephone event signalling is to be done using the SIP INFO message, or to be done via RFC2833 RTP signalling. For additional information please refer to the RFC2833.
  • Page 15 ToS/DiffServ This sub-page is used to configure the Type-of-Service/Diffserv byte values, which are to be used in the IP header of all transmitted SIP signalling packets and RTP packets. The ToS/DiffServ byte values are entered as two-digit hexadecimal values. If no special ToS/DiffServ value is to be used for a particular traffic type, enter “00”...
  • Page 16 CODEC Voice Codec Configuration 1. CODECS: configure the silence suppression to your desired settings. 2. Packetization: configure the packet sending increments. 3. Jitter Buffer: configure the timing of the voice buffering. Selection between adaptive or fixed jitter buffer. Default = ADAPTIVE Set the adaptive jitter buffer maximum playout delay.
  • Page 17 SYSTEM Set Administrator Password Configure a password for the system.
  • Page 18 Time /Area Setup Choose the correct country for a proper impedance match, as well as the NTP Server, and Time Zone. Check the “Adjust clock for daylight savings”, when applicable. Click on “Save Localization Settings”, to save your configurations.

  • Page 19: Snmp Configuration

    SNMP Configuration 1. SNMP Trap Configuration IP address: Trap host IP address Trap Community: The community name used by the SNMP manager to verify traps. The default value is ‘public’ 2. SNMP Community Configuration Read Community: The community name used by the SNMP manager when reading SNMP data items from a client MIB.
  • Page 20 Access Privilege Configuration Check the proper boxes enabling LAN and WAN for the HTTP, SNMP, and VoIP Discovery. Click on “DONE”, to save the configurations.

  • Page 21: Firmware Upgrade

    Firmware upgrade For both HTTP and TFTP methods, the device will reboot itself into downloader mode if the main application is being executed, and proceed with the ROM file download and permanent write of the application to the device’s flash memory. After the download is completed, the download status page will be displayed.
  • Page 22 Reset Chose the “Reboot machine” option to reset the system.

  • Page 23: Appendix A. Dial Plans

    Appendix A. Dial Plans The machine will allow provisioning (via web browser) of the dial plan. A dial plan gives the unit a map to determine when a complete number has been entered and should be passed to the gatekeeper for resolution into an IP address. Dial plans are expressed using the same syntax as used by MGCP NCS specification.

  • Page 24: Sample Dial Plans

    Sample Dial Plans Simple Dial Plan Allows the dialing of 7 digit numbers (e.g. 5551234) or an operator on 0. Dial plan is (0T|xxxxxxx) Non-dialed Line Dial Plan As soon as the handset is lifted, the unit contacts the gatekeeper (used for systems where dtmf detection is done in-call).
