Trademarks Copyright PLANET Technology Corp. 2002. Contents subject to revision without prior notice. PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
Page 3
10 units of various type media converter at a central location for multiple segments cross connection. Independent power supply in each bay of the MC-1000R, you can freely install the converters without interrupting the rest of networks. Moreover, each bay of the media center can deploy to PLANET’S converter family like Ethernet, Fast Ethernet twisted pair to...
Page 4
LED remains off while power is on. Please consult your local dealer to replace the FAN. The rear panel of the MC-1000R is with two fans, one ON/OFF Switch and a power inlet that accept 100~240V AC, 50/60Hz power input.
Page 5
» Turn off the Converter Chassis power » Verify the Media Converter is right for this Chassis and locate +5VDC power jack on converter back, carefully slide in and plug to match 19" Chassis slot +5V DC receptacle. Push up the picket fence to lock the converters Note: The slide-in Media Converters and Converter Chassis should be supplied only from PLANET, both Media Converters and Chassis are...
Page 6
Remove the cover of power supply on front panel » To install the redundant power to MC-1000R, carefully, push the power to make it connected firmly, once the power installed, turn on the I/O switch. The LED indicator should turn on to indicate the redundant power is operating.
Page 7
Note: Push the latch to right side (see Figure 4) when install or remove the redundant power Fig.4 Push the latch to right side when install or remove the redundant power MC-1000R Converter Chassis Specifications Dimension 440 mm x 125 mm x 220 mm (WxHxD) Converter slots...
