12 Button Apartment Entry Phone with Built
Model K-1205 (shown in optional
VE-5x10-SS, not included)
F
e
a
t
u
r
e
s
F
e
a
t
u
r
e
s
• Vandal Resistant Features: 14 gauge louvered 316
stainless steel faceplate with permanent laser etched
graphics, stainless steel speaker/mic screen, heavy
duty metal keypad and hex drive mounting screws.
• Weather Resistant Features: Marine grade 316
stainless steel faceplate and screws. Internally sealed
keypad. Mylar speaker. Self-draining mic mount.
Faceplate, mic and speaker gaskets.
• K-1205-EWP is designed to meet IP66 Ingress
Protection Rating (see DOD# 859 for more information)
• Built-in high resolution color video camera with wide
viewing, tilt/swivel adjustments and wide operating
temperature of -30°F to 150°F
• Operates on 12 to 24 volts AC/DC
• 12 speed dial buttons (22 digits each)
• 12 alternate number positions (22 digits each)
• One button operation (no call button)
• Hang-up on CPC, busy, silence, time-out or dial tone
• Touch tone restriction from microphone
• Integral relays for camera control and door strike
• Works with C-1000B for increased security
• Works with C-3000 for "No CO" (phone line) operation
• 50 keyless entry codes and postal lock input
S
S
C
O
M
O
L
U
T
I
O
N
S
C
O
M
O
L
U
T
I
O
N
S
in Door Strike Relay and Camera
The K-1205 Entry Phone is a two-way, handsfree telephone with 12 but-
tons for calling individual residences in an apartment building. It also has
a built-in color CCTV video camera. The rugged stainless steel faceplate
has a printed directory housed in a waterproof, scratch-resistant lens.
Each button is beside the tenants name in the directory so there are no
confusing codes to deal with. Calling a particular tenant is as easy as
pressing a single button. The K-1205 has a built in speed dialer that can
handle up to 12 primary phone numbers, each with 22 digits. If there is
no answer at the first number, a second number can be called automati-
cally. Once the tenant answers their phone, a single touch tone command
can activate the door strike relay. For "no phone line" applications, the K-
1205 is compatible with the C-3000 no CO (phone line) controller. The
high resolution video camera is mounted on an adjustable bracket so it
can be positioned just right to view the outside visitor.
The K-1205-EWP shares all of the features of the K-1205 in addition to
Enhanced Weather Protection (EWP) for outdoor installations where the
unit is exposed to precipitation or condensation. EWP products feature
foam rubber gaskets and boots, sealed connections, gel-filled butt con-
nectors, as well as urethane or thermal plastic potted circuit boards with
internally sealed, field-adjustable trim pots and DIP switches for easy on-
site programming.
P
r
a
c
P
r
a
c
2
1
C
2
1
C
F
O
R
T
H
E
S
T
F
O
R
T
H
E
S
T
A
p
p
l
i
A
p
p
l
i
• Small apartment buildings
• Professional buildings
• Gated communities
S
p
e
c
S
p
e
c
Dimensions: 127mm x 254mm x 63.5mm (5" x 10" x 2.5")
Shipping weight: 2.5 kg (5.5 lbs.)
Operating Temp: -35°C to 66°C (-30°F to 150°F)
Relay Contact Rating:
Door Strike: 5A @ 30VDC/250VAC Maximum
Camera: 0.5A @ 125 VAC, 1.0A @ 30VDC
Connections: (13) gel-filled butt connectors (3M Scotchlok UR2)
(See page 2 for complete specifications)
K-1205-EWP
K-1205-EWP
Multi-Button Handsfree
t
i
c
e
t
i
c
e
Entry Phone with Camera
August 29, 2012
