12 Button Apartment Entry Phone with Built
Model K-1205 (shown in optional
VE-5x10-SS, not included)
F
e
a
t
u
r
e
s
F
e
a
t
u
r
e
s
• Built-in high resolution color video camera with
wide viewing, tilt/swivel adjustments and wide
operating temperature of -30°F to 150°F
• Operates on 12 to 24 volts AC/DC
• 12 speed dial buttons (22 digits each)
• 12 alternate number positions (22 digits each)
• One button operation (no call button)
• Hang-up on CPC, busy, silence, time-out or
dial tone return
• Touch tone restriction from microphone
• Integral relays for camera control and door
strike
• Works with C-1000B for increased security
• Works with C-3000 for "No CO" (phone line)
operation
• Optional Enhanced Weather Protection (EWP)
• 50 keyless entry codes
• Postal lock input
S
S
C
O
M
O
L
U
T
I
O
N
S
C
O
M
O
L
U
T
I
O
N
S
in Door Strike Relay and Camera
The K-1205 Entry Phone is a two-way, handsfree telephone with 12 but-
tons for calling individual residences in an apartment building. It also has
a built-in color CCTV video camera. The rugged stainless steel faceplate
has a printed directory housed in a waterproof, scratch-resistant lens.
Each button is beside the tenants name in the directory so there are no
confusing codes to deal with. Calling a particular tenant is as easy as
pressing a single button. The K-1205 has a built in speed dialer that can
handle up to 12 primary phone numbers, each with 22 digits. If there is
no answer at the first number, a second number can be called automati-
cally. Once the tenant answers their phone, a single touch tone command
can activate the door strike relay. For "no phone line" applications, the K-
1205 is compatible with the C-3000 no CO (phone line) controller. The
high resolution video camera is mounted on an adjustable bracket so it
can be positioned just right to view the outside visitor.
For outdoor applications, the K-1205 is available with Enhanced Weather
Protection. EWP products feature rubber gaskets and boots, closed cell
foam gasketing, hand soldered silicone sealed connections, anti-corro-
sive gel filled butt connectors, as well as urethane encapsulated circuit
boards with internally sealed trim POTS and DIP switches.
P
r
a
c
P
r
a
c
2
1
C
2
1
C
F
O
R
T
H
E
S
T
F
O
R
T
H
E
S
T
A
p
p
l
i
A
p
p
l
i
• Small apartment buildings
• Professional buildings
• Gated communities
S
p
e
c
S
p
e
c
Dimensions: 127mm x 254mm x 63.5mm (5" x 10" x 2.5")
Shipping weight: 2.5 kg (5.5 lbs.)
Operating Temp: -35°C to 66°C (-30°F to 150°F)
Relay Contact Rating:
Door Strike: 5A @ 30VDC/250VAC Maximum
Camera: 0.5A @ 125 VAC, 1.0A @ 30VDC
Connections: (13) gel-filled butt connectors (3M Scotchlok UR2)
(See page 2 for complete specifications)
K-1205-EWP
K-1205-EWP
Multi-Button Handsfree
t
i
c
e
t
i
c
e
Entry Phone with Camera
December 15, 2008
