- Page 1 VIESMANN Service instructions for contractors Vitosol-T For applicability, see the last page VITOSOL-T Please keep safe. 5458 009 GB 3/2010...
-
Page 2: Safety Instructions
Observe the following when working on Replace faulty components only this system with original Viessmann spare ■ all legal instructions regarding the pre- parts. vention of accidents, ■ all legal instructions regarding envi- ronmental protection, ■... - Page 3 Installing non-authorised components and non-approved modifications or conversions can compromise safety and may invalidate our warranty. For replacements, use only orig- inal spare parts supplied or approved by Viessmann.
-
Page 4: Table Of Contents
Index Index Commissioning, inspection, maintenance Steps - commissioning, inspection and maintenance.......... Further details regarding the individual steps............Scope of inspection................... 14 Parts lists Parts list Vitosol 200-T, type SP2................. 15 Parts list Vitosol 300-T, type SP3A..............17 Specification Vitosol 200-T, type SP2..................19 Vitosol 300-T, type SP3A.................. -
Page 5: Commissioning, Inspection, Maintenance
Commissioning, inspection, maintenance Steps - commissioning, inspection and maintenance For further information regarding the individual steps, see the page indicated Commissioning steps Inspection steps Maintenance steps Page • 1. Checking pressure conditions and pre-charge pressure................• • • 2. Checking the function of the safety equipment..... •... -
Page 6: Further Details Regarding The Individual Steps
Cover the collectors. Note A manual pressure gauge can be found Note in the solar service case available as an The glass cover of Viessmann flat-plate accessory. collectors is coated with a protective foil. Enter values into the following table. -
Page 7: Checking The Function Of The Safety Equipment
Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) Documentation of pressure System pressure of the solar thermal system 1 bar Supplement per metre static ceiling + 0.1 bar/m System operating pressure (pressure gauge) ....bar Pressure reserve for venting + 0.1 bar Filling pressure .... -
Page 8: Flushing, Testing For Leaks And Filling The Solar Thermal System
Note Note The glass cover of Viessmann flat- To flush and fill the solar thermal plate collectors is coated with a pro- system, use the filling container or tective foil. filling station available as acces- For vacuum tube collectors, use the sories. - Page 9 Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) Solar-Divicon (accessory) L/Min A Thermometer/non-return valve, C Safety assembly, with 6 bar safety flow valve B Thermometer/non-return valve, D Flow indicator return Fill valve (accessory) E Shut-off tap F Drain & fill taps...
- Page 10 Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) A Pressure gauge C Container for heat transfer medium B Drain & fill taps D Shut-off valve 1. Open shut-off taps or valves. With the 2. Close shut-off tap E; open drain & Solar-Divicon, open the non-return fill taps F on the fill valve (see dia- valves by turning the thermometers...
-
Page 11: Determining The Flow Rate And Adjusting If Required
Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) 3. Use a high speed pump to flush the 5. Close the fill tap on the fill valve; open system. Observe the fluid level in the the fill pump. container and top up with heat trans- Pressure must not drop for at least 30 fer medium if necessary to prevent minutes. -
Page 12: Starting The System
Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) Specific flow rate 25 l/(h·m Collector area in Flow rate in l/min Starting the system Close the air vent valve. Observe operating instructions of installed components. Checking the switching function of the solar control unit Solar control unit installation and service instructions Checking heat transfer medium and replacing if required... - Page 13 Tyfocor G-LS. Never mix with water or third party media. 2. Check the frost protection tempera- ture of the heat transfer medium with a Viessmann antifreeze tester or the manual refractometer in the solar service case. Solar service case operating instructions...
-
Page 14: Scope Of Inspection
Scope of inspection Scope of inspection The solar thermal system should be inspected once a year to ensure opera- tional reliability. In addition to this, a visual check of all essential components (e.g. collectors and pipework) is recommended every three to five years. ■... -
Page 15: Parts Lists
Parts lists Parts list Vitosol 200-T, type SP2 When ordering spare parts: 014 Support sleeve Quote the part and serial no. (see type 015 Thermal insulation cap, complete plate) and the position no. of the required 016 Mounting bracket part (as per this parts list). 017 Fixing pin Obtain standard parts from your local 019 Locking bracket... - Page 16 Parts lists Parts list Vitosol 200-T, type SP2 (cont.)
-
Page 17: Parts List Vitosol 300-T, Type Sp3A
Parts lists Parts list Vitosol 300-T, type SP3A When ordering spare parts: 011 Elbow fitting with support ferrule Quote the part and serial no. (see type 012 Connection pipe plate) and the position no. of the required 013 Support sleeve part (as per this parts list). - Page 18 Parts lists Parts list Vitosol 300-T, type SP3A (cont.)
-
Page 19: Specification
Specification Vitosol 200-T, type SP2 Absorber area 2.00 3.02 Aperture area 2.15 3.23 Optical efficiency η 76.6 76.6 Heat loss factor k 1.42 1.42 W/(m ·K) Heat loss factor k 0.005 0.005 W/(m ·K Thermal capacity c kJ/(m ·K) Max. idle temperature °C Permiss. -
Page 20: Certificates
Certificates Declaration of conformity We, Viessmann Werke GmbH&Co KG, D-35107 Allendorf, declare as sole respon- sible body, that the products Vitosol 200-T and 300-T conform to the following standards: DIN 1055 EN 12975 to solar KEYMARK In accordance with the following directives, these products are designated _:... - Page 24 Part no. SK02 101 Vitosol 300-T, type SP3A, 2 m Part no. SK01 430 Vitosol 300-T, type SP3A, 3 m Part no. SK01 431 Viessmann Werke GmbH&Co KG Viessmann Limited D-35107 Allendorf Hortonwood 30, Telford Telephone: +49 6452 70-0 Shropshire, TF1 7YP, GB...
