USER MANUAL
HANDSFREE COMMUNICATION
www.blulogicupdate.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HANDSFREE COMMUNICATION and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota HANDSFREE COMMUNICATION

  • Page 1 USER MANUAL HANDSFREE COMMUNICATION www.blulogicupdate.com...
  • Page 2: Table Of Contents

    Table of Contents Quick-Start Guide..............4-5 Pairing Guide................6 Pairing TroubleShooting............8 Using The System..............9-12 Connection................9 Disconnection...............10 Voice Dial................10 Call Answer................11 Call End................11 Call Reject................11 Last Number Re-dial.............11 Mute & Un-Mute..............11 Volume Adjustment...............11 Call Interchange..............12 Call Waiting................12 Sound Quality................12 If You Need Assistance............13 Product Specification............14-15 FCC Warning: Changes or modifications not expressly approved by the party responsible for compliance could void...
  • Page 3 Caution: This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement Cto OET65. This equipment has very low levels of RF energy that it deemed to comply without maximum permission exposure evaluation (MPE).
  • Page 4 Quick-Start Guide BLU Logic is a hands-free phone system Getting Started for your vehicle. BLU Logic connects First, your Hands-free equipped cellular to any hand held celluar phone device phone must be paired or electronically equipped with Bluetooth Wireless tech- ®...
  • Page 5: Quick-Start Guide

    Quick-Start Guide Making and Answering Calls Adjust the Short Press Volume  Down Answer a Short Press Press for 4 Transfer  seconds and Call a Call to  release when you Handset Ending a Short Press hear 2 beeps ...
  • Page 6: Pairing Guide

    Pairing Guide 4. Select “BLU Logic XXXX” from the Pairing your phone is simple, just list. Enter the pre-programmed passkey follow these steps: “1234” and press “OK” to pair the kit and The system can pair up to 8 hand-sets. the hand-set.
  • Page 7 Pairing Guide 6. To pair another phone, repeat steps Pairing Order: 1 through 5. If more than one phone will be used with the BLU Logic system, the pairing order of the phones will determine the order in which the phones will auto- connect to the vehicle.
  • Page 8: Pairing Troubleshooting

    Pairing Troubleshooting Cannot find the Hands-free menu: 6. Delete all paired devices from your hand-set and try again. There is a possibil- Please refer to your hand-set user manual ity that your hand-set is paired to too many for assistance on various phones. devices and exceeds the maximum number of connections.
  • Page 9: Connection

    Using The System All three phones in car, Phone 1 (1) Connection: As soon as you enter the car and turn the connects ignition on, the system will link with your hand-set automatically. You will hear one beep when the connection is established. Note: If the Hands-free connection/link is re- moved (for example: Mobile hand-set is...
  • Page 10: Using The System

    Using The System No Phone 2 in car, Phone 1 (B.) If the phone does not automatically disconnect Select “disconnect” from your connects hand-set menu. See your hand-set user manual for more details. Using The System (1) Voice Dial: If your mobile’s hand-set is voice dial enabled, when in standby mode, press the key.
  • Page 11: Call Answer

    Using The System (6) Mute & Un-mute: (2) Call Answer: When a conversation is in progress, you Press the key to accept a call, or answer can mute or un-mute the microphone so via your mobile hand-set in the normal that the other party cannot hear you.
  • Page 12: Call Interchange

    Using The System (8) Call Interchange: (10) Sound Quality When a conversation is in progress, you For improved sound quality during BLU may transfer the call in between the system Logic operation, please: and hand-set. System to Hand-set: Press key for 4 sec- - Keep all windows up onds and release when you hear 2 beep’s.
  • Page 13: If You Need Assistance

    Using The System (11) If You need Assistance Both Toyota and your Toyota dealer are dedicated to serving your automotive needs. Should you have a problem or concern please take the following steps. Step 1 Discuss the situation with the dealership or customer relations manager.
  • Page 14: Product Specification

    Product Specifications Hands-free Specifications Version 2.1 + EDR; Class 2, 10 Meters/ 30 ft. Hands-free Profile Supported HSP1.1, HFP1.5 Operating Frequency Band 2.402 to 2.480GHz unlicensed ISM band Multi-Pairing Up to 8 Hands-free devices Hands-free DSP Full Duplex, Noise Reduction, Echo Cancellation Power supply voltage range DC 9 ~ 25 volts Working temperature...
  • Page 15: Product Specification

    Product Specifications Microphone Category: Omni Directional Sensitivity: -56dB ± 2dB tolerance (including amplifying circuit) SN ratio: >55dB (Min) Frequency response: Tuned to optimize voice response from 200Hz - 3kHz Amplifier output Output power: 10W Peak (loudspeaker) Impedance: 4 Ohm Max output current: 3A Max undistorted amplitude: 10Vpp Mute mode Active Low Mute...
