Speco HHDI04D1B User Manual

Hdcctv 720/1080p selectable indoor dome wall/ceiling mount dc auto iris 2.8~12mm dual voltage (12vdc / 24vac) hd-sdi, cvbs & second video out

Advertisement

Quick Links

HHDI04D1B
HHDI04D1W
HDcctv 720/1080P Selectable
INDOOR DOME
Wall/Ceiling Mount
DC auto iris 2.8~12mm
Dual Voltage (12VDC / 24VAC)
HD-SDI, CVBS & Second video out
Please read this manual thoroughly before operation and keep
it handy for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HHDI04D1B and is the answer not in the manual?

Questions and answers

Summary of Contents for Speco HHDI04D1B

  • Page 1 HHDI04D1B HHDI04D1W HDcctv 720/1080P Selectable INDOOR DOME Wall/Ceiling Mount DC auto iris 2.8~12mm Dual Voltage (12VDC / 24VAC) HD-SDI, CVBS & Second video out Please read this manual thoroughly before operation and keep it handy for future reference.
  • Page 2: Warning And Caution

    WARNING & CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK D O N O T R E M O V E C O V E R ( O R B A C K ) . N O U S E R S E R V I C E A B L E P A R T S I N S I D E R E F E R S E R V I C I N G T O Q U A L I F I E D...
  • Page 3: Package Contents & Installation

    PACKAGE CONTENTS & INSTALLATION Please make sure that the following items are included in the Package: 2 Mounting Screws 1 Video Test Connector 1 Power Cable Compatible Accessories...
  • Page 4 FEATURES 1. MEGAPIXEL HIGH RESOLUTION 1/3” 2.1Megapixel Progressive CMOS sensor provides Full HD 1080p video resolution. 2. SENS-UP Digitally manipulates the exposure level of the image to produce bright images in the darkest of scenarios. 3. DNR (Digital Noise Reduction) The high performance DSP Technology reduces the gain noise in digital image processing, producing clear sharp images in low light condition.
  • Page 5: Osd Menu Tree

    OSD MENU TREE LENS Mode ● DC  ● Indoor ● Outdoor EXPOSURE ● SHUTTER ● AGC ● SENS-UP ● BRIGHTNESS ● ACCE ● DEFOG ● BACKLIGHT ● RETURN WHITE BAL. ● ATW ● AWC->SET ● INDOOR ● OUTDOOR ● MANUAL DAY &...
  • Page 6: Osd Menu Details

    OSD MENU DETAILS 1) LENS <DC > 2) EXPOSURE <SHUTTER / AGC / SENS-UP / BRIGHTNESS /ACCE/ DEFOG / BACKLIGHT / RETURN> SHUTTER : Adjust shutter settings : Auto / A. FLK / Manual - A. FLK mode reduces on-screen flickering. - Electronic Shutter Control (AUTO) adjusts brightness level on screen.
  • Page 7 OSD MENU DETAILS 3) WHITE BAL. <ATW / AWC-SET / INDOOR / OUTDOOR / MANUAL> ATW : Auto Tracking White Balance. - Use this mode when the color temp. is between 1,800~10,000K AWC->SET : - To find the optimal setting for current luminance environment in this mode.
  • Page 8 OSD MENU DETAILS 6) SPECIAL 6-1) CAM TITLE : To program and display a camera title on the monitor. 6-2) D-EFFECT : <Freeze / Mirror / D-Zoom / Neg.Image / Return> - Freeze : Freezes the display image. - Mirror : Changes the video image via a Vertical flip or mirror. - D-Zoom : Digital Zoom In / Out up to X64.
  • Page 9: Specifications

    SPECIFICATIONS Item HHDI04D1B / HHDI04D1W 1/3” Progressive CMOS Sensor Image Sensor Total Pixels 2010(H) x 1180(V) Approx. 2.22Megapixels Effective Pixels 1944(H) x 1092(V) Approx. 2.12Megapixels Video Output 1920(H) X 1080(V) 30P, 1280(H) X 720(V) 60P HD-SDI Output (1.5G/s, SMPTE 292M),...
  • Page 10 DIMENSIONS Unit : mm * TOP VIEW * SIDE VIEW...
  • Page 11: Warranty

    WARRANTY...
  • Page 12 200 New Highway Amityville, NY 11701 631-957-8700 www.specotech.com Rev. 120823 Speco Technologies is constantly developing product improvements. We reserve the right to modify product design and specifications without notice and without incurring any obligation.
