INSTALLATION INSTRUCTIONS FOR PART 95-5025
95-5025
KIT FEATURES
• Double DIN Head Unit Provision
• ISO Stacked Head Unit Provision
KIT COMPONENTS
A) Double DIN Brackets • B) Double DIN Trim plate • C) (4) # 8 X 1" Phillips Screws
A
WIRING ANDANTENNA CONNECTIONS (Sold Separately)
• 70-1770 - Ford harness - 1985-2004
• Phillips Screwdriver • Socket Wrench • Rotary Cutting Tool
1-800-221-0932
© COPYRIGHT 2009 METRA ELECTRONICS CORPORATION
APPLICATIONS
FORD Mustang
1987-1993
B
TOOLS REQUIRED:
• Radio Removal Tools (Part # 86-5618)
C
www.metraonline.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Metra Electronics 95-5025
Summary of Contents for Metra Electronics 95-5025
- Page 1 A) Double DIN Brackets • B) Double DIN Trim plate • C) (4) # 8 X 1” Phillips Screws WIRING ANDANTENNA CONNECTIONS (Sold Separately) • 70-1770 - Ford harness - 1985-2004 • Phillips Screwdriver • Socket Wrench • Rotary Cutting Tool •...
-
Page 2: Kit Assembly
- Ford Mustang 1987-1993 ........ - Page 3 Note: The threaded studs from under this bracket will also need to be removed for the aftermarket Double DIN radio to clear. (Figure B) Continue to kit assembly. ALSO REMOVE (2) THREADED STUDS FROM UNDER BRACKET 95-5025 DASH DISASSEMBL Y 7/16” (2) HEX BOLTS RADIO SUB-DASH BRACKET...
- Page 4 (Figure A) Mount the head unit/ kit assembly to the dash using the four supplied # 8 x 1” Phillips screws. (Figure B) 1-800-221-0932 REV. 08-19-09 © COPYRIGHT 2009 METRA ELECTRONICS CORPORATION 95-5025 KIT ASSEMBL Y www.metraonline.com INST95-5025...
