KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Vent housing • D) (4) 1/2" screws • E) (4) Panel clips
A
B
Metra. The World's Best Kits.
®
Ford Mustang
Visit
MetraOnline.com
for more detailed information about the product and up-to-date vehicle
specific applications
KIT FEATURES
• ISO DDIN radio provision
• Painted matte black
C
MetraOnline.com
1994-2000
D
E
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
95-5703B
I N S TA L L AT I O N I N S T R U C T I O N S
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................3
Kit Assembly ..........................................................3
WIRING & ANTENNA CONNECTIONS
Wiring Harness: 70-1770 • 70-5510*
(sold separately)
Antenna Adapter: Not required
*Amplified models
TOOLS REQUIRED
• 1/8" drill bit• Cutting tool
• Ford radio removal tools* • Phillips screwdriver
• T-20 Torx screwdriver
* Metra part number 86-5618
Attention!
Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
REV. 1/23/19 INST95-5703B
Advertisement
Related Manuals for Metra Electronics 95-5703B
Summary of Contents for Metra Electronics 95-5703B
- Page 1 When testing the aftermarket equipment, ensure that all factory equipment is connected before cycling the key to ignition. Metra. The World’s Best Kits. MetraOnline.com ® © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 1/23/19 INST95-5703B...
- Page 2 DASH DISASSEMBLY 1. Unclip, unplug, and remove the trim panel surrounding the shifter. (Figure A) 2. Using Metra’s 86-5618 radio removal tools (sold separately), release the radio from the dash. Slide the radio out, then unplug and remove the radio. If the vehicle is equipped with a CD player below, remove in the same manner.
- Page 3 KIT PREPARATION KIT ASSEMBLY To the 95-5703B radio trim panel: 1. Secure the radio brackets to the radio using the screws supplied with the radio. 1. Attach the factory a/c vents removed in (Figure A) Dash Disassembly to the vent housing.
- Page 4 Log onto www.installerinstitute.com or call 800-354-6782 for more information and take steps toward a better tomorrow. Metra recommends MECP certified technicians Metra. The World’s Best Kits. MetraOnline.com ® © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 1/23/19 INST95-5703B...
