SIIG Serial ATA 4-Channel RAID Quick Installation Manual page 4

2. Connect the Serial ATA hard disk drive to the system
power supply using the included Dual Connector
Serial ATA power cable.
3. Connect one end of the Serial ATA data cable to the
hard disk drive.
Figure 2. Hard disk drive connections
4. Attach the other end of the Serial ATA data cable to
the Serial ATA connector on the Serial ATA
4-channel RAID.
Figure 3. Connecting the Serial ATA cable
5. Follow the same instructions to connect up to four
hard drives. Device connection is now complete.
4
Serial ATA cable
Power cable adapter
