Package Contents
•
Serial ATA 4-Channel RAID
•
4 Serial ATA data cables (1M)
•
2 Dual Connector Serial ATA power cables
•
2 "Y" split power cables
•
Driver CD
•
Quick Installaton Guide
Layout
Hard Disk
LED Pins
Figure 1. Serial ATA 4-Channel RAID layout
2
CN4
CN3
Serial ATA
Connectors
CN2
CN1
