SYSTEM FEATURES
Shure LX Wireless Systems offer a number of exceptional features, including:
•
Exclusive Shure MARCAD Circuitry (LX4). MARCAD (MAximum Ratio Com-
bining Audio Diversity) circuitry constantly monitors signals from both receiver
sections and combines them to create a single output signal. The result is im-
proved reception and exceptional freedom from dropouts.
Half-Rack Receiver Size. The LX3 and LX4 receivers interface with the HR
•
(half-rack) format, and are supplied with both single and dual rack-mount hard-
ware. An optional WA503 accessory kit lets you front-mount antennas.
•
Power/Battery Fuel Gauge. The LX1 and LX2 transmitters include a three-light
gauge that indicates both "power on" and the amount of battery life remaining
(see page 12).
•
Dual RF Level Meters (LX4). Instead of a conventional single RF meter, the
LX4 receiver has two meters, one for each antenna. The dual meters indicate
received signal strength at each antenna, and make it easier to identify and trou-
bleshoot RF "dead spots."
•
Audio Metering. A five-light audio meter helps to optimize transmitter gain set-
ting and lets you monitor audio level during operation.
•
True Guitar Sound. Guitar players demanding the highest degree of sound
quality and reliability will appreciate the low noise and uncolored sound of the
LX Wireless System.
•
Noise Squelch. This circuit analyzes signal quality instead of signal strength.
This virtually eliminates the possibility of annoying noise bursts coming through
your receiver.
•
Body-Pack Transmitter Belt Clip. The belt clip has a wider contact surface for
a better grip, and firmly holds thinner, more slippery materials. It can be re-
moved or inverted for special positioning.
•
Grip/Switch Cover Accessory. The unbreakable WA555 grip/switch cover ac-
cessory, supplied with all LX2 hand-held microphone-transmitters, prevents ac-
cidental movement of the power and mute switches and provides a "grip" feel.
•
Compact Power Adapter. The supplied ac power adapter incorporates small,
in-line transformers that save space on ac power strips. It also has mounting
tabs so it can be secured to any surface, as well as locking dc power connectors
to prevent accidental disconnection from the receiver.
4
