OPERATING THE LX2 HAND-HELD SYSTEM

TRANSMITTER
LX2 HAND-HELD MICROPHONE SYSTEM OPERATION
1. Slide the transmitter PWR/OFF switch to the PWR position. One of the three lights
on the transmitter illuminates.
2. Press the POWER button on the receiver. The green power on indicator and the
RF light(s) illuminates.
3. Slide the transmitter ON/MUTE switch to the ON position and begin speaking or
playing your instrument.
NOTE: If the red PEAK light on the receiver does not flicker during the loudest
sounds, the transmitter gain may need to be increased. Refer to the Adjusting the
Transmitter Audio Gain Level section. Then, if the system is still not operating
properly, consult the Troubleshooting table.
4. During the performance or presentation, slide the ON/MUTE switch to the MUTE
position when the system is not in use.
5. When the performance or presentation is over, slide the transmitter PWR/OFF
switch to the OFF position to conserve battery power.
LX2
RECEIVER
FIGURE 15
LX Wireless System
15
