Ford 2000 F-150 Owner's Manual

Ford 2000 F-150 Owner's Manual

Ford motor company 2000 ford f-150 owner's guide
Hide thumbs Also See for 2000 F-150:

Advertisement

All rights reserved. Reproduction by any means, electronic or mechanical
including photocopying, recording or by any information storage and retrieval
system or translation in whole or part is not permitted without written
authorization from Ford Motor Company.
Copyright
1999 Ford Motor Company

Table of contents

2
4
6
8
9
10
11
15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2000 F-150 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ford 2000 F-150

  • Page 1: Table Of Contents

    All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Copyright Table of contents...
  • Page 2: Introduction

    SVT F–150 Lightning. If you have any questions, please call us at the Ford Special Vehicle Team hotline from 8:30 a.m. to 6:00 p.m. EST at 1–800–FORD-SVT (1–800–367–3788).
  • Page 3 SVT-specific line of apparel and accessories available through your SVT dealer. Contact the SVT team leader at the dealership for details and ordering information or call 1–800–FORD-SVT. To order direct, call 1–888–490–6837. The SVT Enthusiast, written and published by SVT Headquarters.
  • Page 4: Svt F-150 Lightning Specific Features

    SVT F-150 Lightning specific features F–150 LIGHTNING SPECIFIC FEATURES 5.4L 2V Triton Supercharged Intercooled V8 engine Modified 4R100 4–speed automatic transmission with OD lockout Limited-slip differential Auxiliary transmission fluid cooler Eaton supercharger Engine super cooling system Heavy duty battery Unique front fascia with integrated, round fog lamps Unique upper and lower grilles Unique front lower air deflectors Unique cab rocker and lower box moldings...
  • Page 5 SVT F-150 Lightning specific features FUEL SERVICE ENGINE SOON PREMIUM UNLEADED FUEL ONLY Unique electro-luminescent instrument cluster with SVT signature white-faced gauges, including vacuum/boost gauge Unique 60/40 leather/cloth seats Standard 6–way power driver’s seat Accentuated seat back and cushion lateral bolstering 4-spoke leather-wrapped steering wheel Leather-wrapped door trim inserts Premium electronic AM/FM stereo/CD clock radio, including...
  • Page 6: Engine/Transmission

    Engine/Transmission 5.4L SUPERCHARGED V8 ENGINE 1. Engine oil dipstick 2. Power steering fluid reservoir 3. Brake fluid reservoir 4. Power distribution box 5. Engine coolant reservoir 6. Air filter assembly 7. Intercooler coolant reservoir 8. Windshield washer fluid reservoir 9. Battery 10.
  • Page 7: Engine

    ENGINE Configuration Bore x Stroke Displacement Compression ratio Horsepower (SAE net) Torque Redline Specific output Valvetrain Fuel system Ignition system Mass air sensor Throttle body Supercharger Exhaust manifolds Exhaust system Engine/Transmission Supercharged longitudinally mounted, 90-degree V8, single overhead cam, cast iron cylinder block and cast aluminum cylinder heads 90.2 x 105.8 mm (3.55 x 4.17 in)
  • Page 8: Drivetrain

    Drivetrain DRIVETRAIN Rear axle Driveshaft Transmission Gear ratios 9.75 in limited-slip differential with 3.55:1 final drive ratio Steel with hardened yoke Modified 4R100 4-speed automatic with OD lockout Gear 4th (OD) Reverse Ratio 2.71 1.53 1.00 0.71 2.176...
  • Page 9: Performance

    PERFORMANCE 0-100 km/h (0-60 mph) 400 meters (quarter mile) Top speed Braking, 100-0 km/h (60-0 mph) 41.8 meters (137 ft.) 183 meter slalom (600 ft.) 61 meter skid pad (200 ft.) Performance 6.2 seconds 14.63 seconds @ 156.7 km/h (97.4 mph) 225 km/h (140 mph) 102.4 km/h (63.6 mph) 0.85 g...
  • Page 10: Options, Color And Trim

    Options, color and trim OPTIONS, COLOR AND TRIM Tonneau cover 6–disc CD player Trailer tow package Dark tint rear sliding window Exterior: Black Clearcoat Oxford White Bright Red Clearcoat Interior: Medium Graphite Leather/Cloth...
  • Page 11: Motorcraft Part Numbers

    MOTORCRAFT PART NUMBERS Component Air filter element Fuel filter Battery Oil filter PCV valve Spark plugs Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. If a spark plug is removed for inspection, it must be reinstalled in the same cylinder.
  • Page 12: Refill Capacities

    Transmission fluid Windshield washer fluid Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford Extended Life Engine Coolant (orange in color). Fill 6 mm to 14 mm (1/4 inch to 9/16 inch) below bottom of fill hole.
  • Page 13: Octane Recommendations

    Maintenance handle. MERCON and MERCON V are not interchangeable. DO NOT mix MERCON and MERCON V. Refer to your Scheduled Maintenance Guide to determine the correct service interval. Indicates only approximate dry-fill capacity. Some applications may vary based on cooler size and if equipped with an in-tank cooler. The amount of transmission fluid and fluid level should be set by the indication on the dipstick’s normal operating range.
  • Page 14: Wheels And Tires

    Maintenance WHEELS AND TIRES Tires 295/45 ZR 18 BSW tires SVT-Signature style, 18 in x 9.5 in aluminum 5-spoke Wheels wheels TIRE ROTATION Unidirectional tire rotation For vehicles equipped with unidirectional tires and full-size spare, your vehicle can be driven with the unidirectional full-size spare, rotating counter to the directional arrow on the tire...
  • Page 15: A Word About Warranty Coverage

    Ford-Lincoln-Mercury dealer nationwide. SVT does not recommend modifying or racing our vehicles, as they are designed and built to be driven as delivered from the factory. The Ford Motor Company Warranty Guide discusses the installation of aftermarket parts and their effect on warranty coverage as follows: Repairs are not reimbursable under warranty when: “The repairs are required because of abuse, misuse, racing, fire,...

This manual is also suitable for:

F-150 1999
