Page 7 Introduction Ford’s Commitment to You At Ford Motor Company, excellence is the continuous commitment to achieve the best result possible. It is dedication to learning what you want, determination to develop the right concept, and execution of that concept with care, precision, and attention to detail.
Page 8: Notes And Warnings
This guide describes equipment and gives specifications for equipment that was in effect when this guide was approved for printing. Ford may discontinue models or change specifications or design without any notice and without incurring obligation.
Page 9 If you lose your Warranty Information Booklet, you can get a new one free of charge. Contact any Ford or Lincoln-Mercury dealer, or refer to the addresses and phone numbers on the first page of this...
Page 10: Ford Extended Service Plan
You can get more protection for your new car or light truck by purchasing a Ford Extended Service Plan (Ford ESP). Ford ESP is the only extended service program with the Ford name on it and the only service contract backed by Ford Motor Company.
Page 11 100 miles (160 km) of city driving or 1,000 miles (1,600 km) of highway driving. Use only the type of engine oil that Ford recommends. See Engine oil recommendations in the Index. Do not use special “break-in” oils.
Page 12 Instrumentation The instrument panel (dashboard) on your vehicle is divided into several different sections. The illustrations on the following pages show the major parts of the instrument panel that are described in this chapter. Some items shown may not be on all vehicles.
Page 13 The Instrument Panel...
Page 14 The Instrument Cluster...
Page 15: Brake System Warning Light
Indicator Lights and Chimes Brake System Warning Light The warning light for the brakes can show two things — that the parking brake is not fully released, or that the brake fluid level is low in the master cylinder reservoir. If the fluid level is low, the brake system should be checked by your dealer or a qualified service technician.
Page 16: Anti-Lock Brake System Warning Light
Anti-Lock Brake System Warning Light This light comes on for a few seconds when you turn the ignition key to the START position. It should go off shortly after the engine starts. If it stays on longer than five (5) seconds, it indicates that your anti-lock brake system may not be working properly.
Page 17 4. If the level is low, add only as much oil as necessary before you start the engine again. Do not overfill. Do not operate the engine if the light is on, regardless of the oil level. Contact your nearest dealer for further service actions. For more information about adding oil, see Adding engine oil in the Maintenance and Care chapter.
Page 18: Cruise Control Indicator Light
Cruise Control Indicator Light This light comes on when the speed control system is actively maintaining the set speed. It will go off when the brakes are used or if the speed control is turned off. Charging System Light This light indicates that your battery is not being charged and that you need to have the electrical system checked.
Page 19: Turn Signal Indicator Lights
Turn Signal Indicator Lights When you push the turn signal lever up before making a right turn, the right side arrow on the instrument panel flashes. When you push the turn signal lever down before making a left turn, the left side arrow on the instrument panel flashes.
Page 20 Chime for Headlamps On This chime sounds if the driver or any passenger door is open when the parking lamps or headlamps are on. The chime sounds until you close the door, turn off the lamps or turn the ignition to the ON position.
Page 21: The Instrument Cluster
The Instrument Cluster In addition to warning lights, the instrument cluster has an electronic odometer, a speedometer, tachometer, fuel and coolant temperature gauges. Odometer The odometer tells you the total number of miles (kilometers) your vehicle has been driven. Speedometer The speedometer The speedometer tells you how many miles (kilometers) per hour your vehicle is moving.
Page 22: Engine Coolant Temperature Gauge
Tachometer The tachometer The tachometer displays the approximate engine revolutions per minute (rpm), or how fast the engine is running. You can drive your vehicle at most rpm points on the tachometer but you must stay out of the red zone.
Page 23 The pointer moves from the C (cold) mark into the NORMAL band as the engine coolant warms up. It is acceptable for the pointer to fluctuate within the NORMAL band under normal driving conditions. Under certain driving conditions such as, heavy stop and go traffic, or driving up hills in hot weather, the pointer may indicate at the top of the NORMAL band.
Page 24: Fuel Gauge
Fuel Gauge The fuel gauge displays approximately how much fuel you have in the fuel tank. For a proper fuel gauge indication after adding fuel, the ignition switch should be in the OFF position while the vehicle is being refueled. The fuel gauge indicator may vary slightly while the vehicle is in motion.
Page 25: Operator Selectable Features
Continuous warning reporting of monitored systems You can select different features for the M/C to display by using the keyboard directly below the M/C display. You will hear a tone when you press one of these controls. However, if the M/C detects a warning from any of the monitored systems then the M/C will display the appropriate warning message.
Page 26 Vehicle Settings Menu A press of the VEHICLE SETTINGS control causes the Message Center to display the menu features which affect the vehicle regardless of which driver personality profile is currently selected. Repeated pressing of the VEHICLE SETTINGS control allows quick cycling through the menu features.
Page 27 OIL CHANGE RESET — This option allows you to reset the oil monitoring system to 100% (or your Personalized Oil Reset Percentage) after each oil change. The RESET control must be pressed and held for 5 seconds while the display counts down to trigger an oil change reset.
Page 28 4. Press the VEHICLE SETTINGS control to complete the procedure. A press of any control besides RESET or VEHICLE SETTINGS will abort the procedure and will not establish a new Personalized Oil Reset Percentage. When your Personalized Oil Reset Percentage has been established, it will be used beginning with the completion of your next OIL CHANGE RESET procedure.
Page 29 PHONE SCREEN — (if equipped with a factory phone) when a call is placed, information about the call is displayed in the message center. Fuel Range A press of the RANGE switch allows you to display approximately how many miles (kilometers) you can drive before you run out of fuel.
Page 30: Fuel Economy
Fuel Economy A press of the FUEL ECONOMY control allows you to display one of two features (Average Fuel Economy or Instantaneous Fuel Economy). The first press of the FUEL ECONOMY control will allow you to display your average fuel economy in miles/gallons or liters/100 kilometers.
Page 31 Reset A press of the RESET control will allow you to reset the current feature being displayed. Warnings, Average Fuel Economy, Clock Set, Compass Adjustment, Vehicle Settings, and Driver Settings are the only features which respond to the RESET control. Range and Instantaneous Fuel Economy cannot be reset.
Page 32 Press DATE/TIME repeatedly to select the correct month of the year. Then press RESET to proceed to the date adjustment display. Press DATE/TIME repeatedly to select the correct day of the month. Then press RESET to complete the set/adjustment procedure. Time Only Display —...
Page 33: System Check
To START the Elapsed Time count when it is stopped without resetting the counter, briefly press the reset control for less than 2 seconds. To reset the elapsed time counter, hold the reset control down until the count reads 00:00:00 (about 2 seconds). Compass Pressing the COMPASS control will display one of the following eight compass displays: North,...
Page 34 Traction Control (If equipped) Fuel Level At normal conclusion of the system check sequence, the M/C will display the last displayed feature before pressing the SYSTEM CHECK control or the warnings that are active. For two of the systems reported in the system check (Engine Oil Life Left and Fuel Level), there are two messages to describe the status of the system.
Page 35 Vehicle System Status Displays These messages are displayed on the Message Center when the operator uses one of the vehicle systems below, or the operation of a vehicle system occurs. PHONE SCREEN — This display will show the status of the cellular phone usage (if the vehicle is equipped with the factory installed cellular phone).
Page 36: System Warnings
System Warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems. There are 23 warning messages which can be displayed by the Message Center to show the status of the monitored systems. When a warning occurs, the warning message is displayed and a tone sounds.
Page 37 The following is a list of warning messages and their associated reset category:...
Page 38 DRIVER’S DOOR AJAR — This warning message is displayed when the driver’s door is not completely closed and the ignition switch is either ON or in ACC mode. RIGHT DOOR AJAR — This warning message is displayed when the right (passenger side) door is not completely closed and the ignition switch is either ON or in ACC mode.
Page 39 the engine to start without alerting the oil monitoring system. This may also cause the LOW OIL LEVEL warning to come on when you start your vehicle, even though the oil is at the correct level. For further information about adding oil, see Engine oil in the index.
Page 40 CHECK TRANS-MISSION — This warning message is displayed when the transmission is not operating properly. If this warning stays on or comes on, contact your dealer for transmission service as soon as safely possible. TRANS-MISSION OVERHEAT — This warning message is displayed when the transmission is overheating.
Page 41 CHECK FRT TURN LAMPS — This warning message is displayed when you turn on the front turn lamps and at least one of them is burned out. Check the lamps as soon as safely possible, and have the burned out lamp replaced following the instructions in the Maintenance and Care chapter.
Page 42 AIR RIDE SWITCH OFF — This warning message is displayed when the AIR SUSPENSION SERVICE SWITCH is in the OFF position. The air suspension service switch is located in the vehicle trunk in the jack stowage area on the left side. For more information refer to the Air Suspension section in the Driving chapter.
Page 43 OIL CHANGE RESET PROCEDURE — This procedure allows you to reset the oil monitoring system to 100% (or your Personalized Oil Reset Percentage) after each oil change. 1. Press the VEHICLE SETTINGS control until the “OIL CHANGE RESET” display appears. 2.
Page 44: Electronic Compass
Function/Status Error Messages For some functions displayed by the Message Center, there will be error messages displayed, instead of the requested information, if that information is not currently available because of improper operation of sensor systems, or the vehicle network communication between electronic modules.
Page 45 Factors Affecting Compass Accuracy Magnetic mounted devices (antennas, racks, etc.) should not be located on the front third of the vehicle roof. Placement of these devices near the compass will cause the compass to be inaccurate. If these devices are used, for improved accuracy, recalibrate the compass with the device(s) installed.
Page 46 Set zone variation adjustment 1. Press and hold the COMPASS control, press the RESET control. Next, release both controls. The display will show: 2. Press the ENGLISH/METRIC control to enter the Set Zone mode. The display will now show: NOTE: The display shows “##” (where ## is a number from 1-15) when called up, which is the zone stored internally in the compass computer.
Page 47 4. Press the RESET control until the number shown in the display is the correct number for the zone you are in. When the zone number reaches 15, pressing the RESET control will set the zone number to 1. 5. Press the COMPASS control to complete the zone setting.
Page 48: Calibration Procedure
Calibration Procedure 1. Find an open, level area free from steel structures and high voltage lines. An empty, level parking lot is recommended. 2. Press and hold the COMPASS control, then press the RESET control. Next, release both controls. The display will show: 3.
Page 49: Troubleshooting
Troubleshooting If the display shows the following message during any of the compass adjustment procedures, contact your dealer: If the compass always displays one direction while turning a full 360-degree circle, perform the Calibration Procedure. A system of warning lights are located below the Message Center.
Page 50: Check Engine Warning Light
Check Engine Warning Light This light illuminates when the engine’s Emission Control System requires service. It will also illuminate when the ignition key is in the ON position and the engine is off. Air Bag Readiness Light The air bag system uses a readiness light and a tone to indicate the condition of the system.
Page 51: Overdrive Off Indicator
If the light fails to illuminate, continues to flash, remains on, or you hear a beeping sound, have the system serviced at your Ford or Lincoln-Mercury dealer immediately. Overdrive Off Indicator This light tells you that the Transmission Control Switch on the gearshift lever has been pushed.
Page 52 This light will also flash if the passive anti-theft system is not functioning correctly. If the light continues to flash have the system serviced at your Ford or Lincoln-Mercury dealer immediately. NOTE: If this light flashes rapidly, the vehicle will be disabled.
Page 53 Traction Control Off Light This light tells you that the traction control system has been turned off using the Vehicle Settings menu in the Message Center. The traction control system defaults to “ON” (light is not illuminated) whenever the vehicle is shut off and restarted.
Page 54: Electronic Sound Systems
Electronic Sound Systems Premium Stereo Cassette...
Page 55 Premium Stereo Cassette and Stereo Cassette with CD DJ...
Page 56 Your vehicle is equipped with either a premium stereo cassette radio or a premium compact disc radio. Both systems are available with a JBL upgrade system, which includes a Ford 10-CD changer. Individual functions of these systems follow: Using the Controls on Your New Radio How to turn the radio on and off Press the “VOL/PUSH”...
Page 57 can set to any desired frequency. These four methods are described below. Using the “TUNE” function You can change the frequency up or down one increment at a time by pressing and releasing either the left b or right a side of the “TUNE” button. To change frequencies quickly, press and hold down either the right or left side of the button.
Page 58 Follow the easy steps below to set these buttons to the desired frequencies: 1. Select a band, then select a frequency. 2. Press one of the memory preset buttons and hold the button until the sound returns. That station is now held in memory on that button. 3.
Page 59 Increasing or decreasing treble response Press the top c of the “TREBLE” button to increase treble; press the bottom d of the treble button to decrease treble. Adjusting speaker balance Balance control allows you to adjust the sound distribution between the right and left speakers. Press the top c of the “BAL”...
Page 60 NOTE: A cassette tape can be loaded with the ignition on whether or not the radio power is on. However, with radio power off, the cassette tape is loaded and stored. NOTE: Noise reduction system manufactured under license from Dolby Labs Licensing Corporation. “Dolby”...
Page 61 In order to keep your cassette tape player performing the way it was meant to, read and follow these simple precautions: Using a Ford or equivalent cassette cleaning cartridge to clean the tape player head after 10-12 hours of play will help maintain the best playback sound and proper tape operation.
Page 62 Protect cassettes from exposure to direct sunlight, high humidity and extreme heat or cold. If they are exposed to extreme conditions, allow them to reach a moderate temperature before playing. If a tape is loose inside the cassette, tighten it before playing by putting your finger or a pencil into one of the holes and turning the hub until the tape is tight.
Page 63 How to take care of and clean the CD playe r and discs To ensure the continued performance of your CD player, carefully read the following precautions: Always handle a disc by the edge. Never touch the playing surface. Before playing, inspect all discs for any contamination.
Page 64: Loading Instructions
— CD-ER 0002 — Eject error. — CD-ER 0100 — Computer CD loaded. — CD-ER ____ (other codes) — Mechanism malfunctions. Ford 10-CD Changer (If equipped) Introduction The 10-CD Changer Unit is mounted in the trunk (10-disc capacity) and is remotely controlled through the Premium Audio System on your instrument panel.
Page 65 2. Push EJECT button to eject the disc “magazine” (which holds 10 discs) (Figure 2). Figure 2 3. Load discs into disc magazine slots (numbered 1 through 10) one at a time with labeled surfaces upward, starting with bottom slot number 1 (Figure 3).
Page 66 How to Operate the Ford 10-CD Changer Using the Controls on the Radio If your vehicle is equipped with the Ford 10-CD Changer System, you operate it through the controls of your Premium Audio System. Several of the controls on the radio operate in the...
Page 67 If the CD Changer is empty, “NO CD” will flash in the display and radio play will continue. If your vehicle is not equipped with the Ford 10-CD system and the “CD” button is pushed, “NO DJ” will flalsh and radio play will continue.
Page 68 Operating the Shuffle feature While in the CD mode, pressing the “SHUFFLE”/#6 button will randomly select a track from the disc currently being played. The display will indicate “SHF” followed by the disc and track number (dd-tt). The CD Changer will continue to randomly select tracks for play until the shuffle feature is turned off by pressing the “SHUFFLE”...
Page 69 Before playing, inspect all discs for any contamination. If needed, clean discs with an approved disc cleaner, such as the Discwasher Compact Disc Cleaner or the Allsop 3 Compact Disc Cleaner, by wiping from the center out to the edges. Do not use a circular motion to clean.
Page 70 CD format. Because of this, a new disc that is free of dust and scratches could be defective and may not play on your Ford Compact Disc Player. If play does not begin after the CD button is pushed: The radio is not on.
Page 71 Antenna The antenna for the audio system is integral to the rear window glass. The AM portion of the antenna uses the same pattern of lines as the grid for the rear defroster. The FM portion of the antenna uses the top three lines on the glass, which are indicated by the word “RADIO.”...
Page 72 To minimize these conditions, a stereo/mono blend circuit has been incorporated into this system. This feature automatically switches a weak stereo signal to a clearer monaural signal, which improves the quality of reception. Several sources of static are normal conditions on AM frequencies.
Page 73: About Your Warranty
50,000 miles (whichever occurs first). Consult your vehicle warranty booklet for further information. Servicing Your Audio System At Ford, we stand behind our audio systems with a comprehensive service and repair program. If anything should go wrong with your Ford audio system, return to your dealer for service.
Page 74: Controls And Features
Controls and Features The Climate Control System Electronic Automatic Temperature Control System The Electronic Automatic Temperature Control (EATC) module is located at the center of the instrument panel and operates only when the key is in the ON position. The EATC feature maintains the temperature you select and automatically controls the airflow for your comfort.
Page 75 The automatic temperature control system To turn your EATC on, push the AUTOMATIC button or any of the six override buttons along the bottom of the control. To turn your EATC off, press the OFF button. When the system is off, the display window will be blank (dark).
Page 76 If you want continuous maximum cooling, push the BLUE button until 60˚F (16˚C) is shown in the display window. Your EATC will cool at maximum and disregard the 60˚F (16˚C) setting until you select a warmer temperature with the RED button. If you want continuous maximum heating, push the RED button until 90˚F (32˚C) is shown in the display window.
Page 77 When in AUTOMATIC and weather conditions require heat, air will be sent to the floor. But, a feature is included in your EATC to prevent blowing cold air to the floor if the engine coolant is not warm enough to allow heating. In 3-1/2 minutes or less, the fan speed will start to increase and the airflow will change to the floor area.
Page 78 Fan speed and thumbwheel Your EATC automatically adjusts the fan speed to the existing conditions. You must push AUTOMATIC for automatic fan speed operation. To control the fan speed yourself, use the thumbwheel which will cancel the automatic fan speed control. The thumbwheel is located at the extreme right side of the EATC control panel.
Page 79 You can override the fan speed at any time. If you use the thumbwheel to override the fan speed, the EATC will continue to control the temperature but you control the fan speed. To return to auto fan control, press the AUTOMATIC button. If you are operating in one of the override functions (FLOOR, MAX A/C, etc.), automatic fan control will continue unless you rotate the fan thumbwheel.
Page 80 MAX A/C button The MAX A/C feature allows for faster cooling because air is drawn from inside the vehicle. Using inside air causes the fan to sound louder which is normal for this selection. The Display window will change to indicate 60˚F (16˚C) and MAX A/C. The fan will run and the airflow will be from the instrument panel registers.
Page 81 DEF button Push this button to get air to the floor and windshield defrosters at the same time. The display will show the set temperature, FLR and the Defrost symbol. If the outside temperature is about 50˚F (10˚C) and above, the air will be dehumidified to remove moisture.
Page 82 To prevent humidity buildup inside your vehicle, always drive with the EATC System turned on. Do not put objects under the front seats that interfere with the flow of air to the back seat area. Remove any snow, ice, or leaves from the air intake area of your EATC System which could block the air intake.
Page 83: Daytime Running Light System
The button that controls the rear window defroster and heated outside rearview mirrors Before using the defroster, clear away any snow that is on the rear window and outside rearview mirrors. With the engine running, push the defroster button. After approximately 10 minutes, the defroster will turn off.
Page 84 NOTE: If you have a vehicle with an automatic lighting system, the DRL system is active until the automatic system turns on the headlamps. NOTE: You may notice that the lights flicker when the vehicle is turned on or off. This is a normal condition.
Page 85 Setting the Autolamp On/Off Delay System By using the autolamp, you can set the headlamps turn on the lamps automatically at night turn off the lamps automatically during daylight keep the lamps on for up to three minutes after you turn the key to OFF. The controls for the autolamp To use the autolamp: 1.
Page 86 3. Rotate the headlamp control counterclockwise from the OFF position. NOTE: The Message Center will display the amount of time that has been set for the autolamp to turn off the headlamps after turning the key to off. 4. The autolamp will automatically turn the lamps on and off for you.
Page 87 The thumbwheel that controls the light on the instrument panel and the interior light To dim the instrument panel lights, rotate the PANEL DIM thumbwheel down. To turn on the interior lights, turn the PANEL DIM thumbwheel all the way up. The interior lights also come on when any side door is opened.
Page 88 Ignition Understanding the Positions of the Ignition The positions of the key in the ignition ACC allows some of your vehicle’s electrical accessories such as the radio and the windshield wipers to operate while the engine is not running. NOTE: Your vehicle is also equipped with an accessory timer.
Page 89: Key System
ON allows you to test your vehicle’s warning lights (except the brake system warning light) to make sure they work before you start the engine. The key returns to the ON position once the engine is started and remains in this position while the engine runs.
Page 90: Turn Signals
WARNING Do not leave children, unreliable adults, or pets unattended in your vehicle. The Turn Signal Lever You can use the turn signal lever on the left side of the steering column to: operate the turn signals and cornering lamps turn the high beams on/off flash the lights turn the windshield wipers and washer on/off...
Page 91: High Beams
For lane changes, move the lever far enough to signal but not to latch. The lever will return to the off position when you release it. When the turn signal is used when the headlamps are on, the cornering lamps will automatically light on either the right or left side depending on the direction of the turn.
Page 92: Windshield Washer
LOW — wipers will operate at low speed until turned off. HIGH — wipers will run at high speed until turned off. MIST — rotate the wiper switch down to the MIST position; the wipers will operate at low speed as long as the switch is held in this position.
Page 93 If the washer does not work, check the washer fluid level and fill it if it is low. See the Maintenance and Care chapter. If there is enough fluid, consult your nearest Ford or Lincoln-Mercury dealer. Do not try to clean the windshield when the...
Page 94: Hazard Flasher
For information about refilling the washer fluid or replacing your windshield wiper blades, see Windshield washer fluid and Wipers in the Index. Hazard Flasher The hazard flasher serves as a warning to other drivers to be careful when approaching or passing your vehicle.
Page 95 Horn To sound the horn, push the center pad area of the steering wheel. The horn on the steering wheel...
Page 96: Power Tilt/Telescope Steering Column
Power Tilt/Telescope Steering Column WARNING Never adjust the steering wheel when the vehicle is moving. The steering column positions are automatically saved and can be recalled along with the vehicle personality features when a memory position is selected through the keypad, keyless entry transmitter or memory switch on the driver’s door.
Page 97 During autoglide operation the column will move to the full in and up position. The column will return when autoglide is completed. During easy exit (if activated through the Message Center) operation the column will move to the full in and up position. When the key is inserted into the ignition switch the column will return to the previous setting.
Page 98: Speed Control
Speed Control The speed of the vehicle cannot be automatically controlled until the vehicle speed is at or above 30 mph (48 km/h). Use of radio transmitting equipment that is not Federal Communications Commission (FCC) or in Canada the Canadian Radio and Telecommunications Commission (CRTC) approved may cause the speed control to malfunction.
Page 99: To Turn Speed Control Off
To Turn Speed Control Off Press OFF, Turn off the vehicle ignition. Once speed control is switched off, the previously programmed set speed will be erased. To Turn Speed Control On Press ON To Set a Speed Press SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 30 mph (48 km/h).
Page 100: Indicator Light
To Set a Higher Set Speed Press and hold SET ACCEL. Release the switch when the desired vehicle speed is reached. OR Press and release SET ACCEL. Each press will increase the set speed by 1 mph (1.6 km/h). Accelerate with your accelerator pedal, then press SET ACCEL.
Page 101: Rear Courtesy/Reading Lamps
Turning On the Lamps Map and Reading Lamps Your vehicle has two map lamps for the passenger and the driver. To turn on the map lamps, push the switch next to each lamp. Front seat map and dome lamps Map lamp (with optional moon roof) The dual beam map lamps are located on each side of the dome lamp.
Page 102: Moonroof (If Equipped)
With the switch pushed in one position, the courtesy/reading lamp will illuminate when any door is opened or when the instrument panel dimmer switch is rotated to the courtesy lamp position. Push the switch to illuminate the lamp continuously. Rear seat courtesy/reading lamps Moon Roof (If equipped) You can move the moon roof back to open the glass panel, or you can tilt it up to ventilate the...
Page 103 The switch for the moon roof To open the moon roof, press and hold the rear portion of the switch. The glass panel will move to the intermediate position and stop. If the rear of the switch is pressed again the glass panel will move to the full open position and stop.
Page 104: Automatic Dimming Inside Rearview Mirror
The moon roof WARNING Do not let children play with the moon roof. They may seriously hurt themselves. Sliding Shade The moon roof has a sliding shade that you can manually open or close to block the sun when the glass panel is shut.
Page 105 short delay. The delay starts when glare goes away. The delay prevents excessive changing of the mirrors as traffic moves behind and around the vehicle, or on rolling hills and curves. The automatic non-glare mirror There are two light sensors (photocells) in this mirror.
Page 106: Sun Visors
Sun Visors Illuminated Visor Mirror (If equipped) To turn on the visor mirror, lift the mirror cover. The mirror on the sun visor HomeLink Universal Transmitter (If equipped) The HomeLink Universal Transmitter provides a convenient way to replace up to three hand-held transmitters with a single built-in device.
Page 107 Do not use this HomeLink Transmitter with any garage door opener that lacks safety “stop” and “reverse” features as required by federal safety standards, (this includes any garage door opener model manufactured before April 1, 1982). A garage door opener which cannot “detect” an object in the path of a closing door and then automatically “stop”...
Page 108 4. Using both hands, push the hand-held transmitter button and the desired button on the HomeLink Transmitter. Continue to press both buttons through step 5. 5. Hold down both buttons until you see the red light on the HomeLink Transmitter flash, first slowly and then rapidly.
Page 109 Operating the HomeLink Universal Transmitter Once it is programmed, the HomeLink Universal Transmitter can be used in place of your hand-held transmitter(s). To operate, simply press the appropriate button on the HomeLink Transmitter. The red light comes on while the signal is being transmitted.
Page 110: Erasing Channels
Remove the cover panel from your garage door opener receiver. (The receiver should be located by the garage door opener motor.) Locate the training button on the garage door opener receiver. The exact location and color of the button may vary by garage door opener brand.
Page 111 NOTE: When selling your vehicle, be sure to erase all channels on the HomeLink Transmitter that you programmed. Accessories Accessories for your HomeLink Universal Transmitter are available from the manufacturer of the device. If you would like additional information or would like to purchase other accessories such as home lighting or security products that can be operated by the HomeLink Universal Transmitter, please call toll-free: 1-800-355-3515.
Page 112: Smart Locks
Smart Locks The Smart Locks feature helps prevent you from locking the keys in your vehicle. With the key in the ignition (in any switch position) and either the driver’s or passenger’s door open, the doors cannot be locked using the front door lock switches. NOTE: Your vehicle can still be locked, while the key is in the ignition, by manually pressing down the lock button or with remote/keyless entry.
Page 113 Using the Power Windows Each door has an illuminated power control that opens and closes the window on that door. The driver’s door has a master control panel that operates the windows. Power windows can only be opened or closed when the ignition switch is in the ON or ACC position.
Page 114 There is also an Express Down feature on the driver’s power window. This feature can be activated through the menu functions of your Message Center. For conventional operation press the driver’s window control to the first detent in the down position.
Page 115 Memory Profile System (If equipeed) The Personality Memory Feature customizes your Mark VIII for up to two (2) drivers. The following features are automatically recalled when unlocking the doors using the remote entry transmitter, keyless entry keypad, or by pressing the Memory 1 or Memory 2 switches on the driver’s door: All driver’s seat positions except power lumbar and head restraint.
Page 116 Personality Memory recall from the remote transmitter can be disabled. This is done by sliding the switch on the back of the transmitter to OFF. Personality Memory can still be recalled using keyless entry code or the Memory 1 or Memory 2 switches.
Page 117: Side View Mirrors
the right of the instrument cluster) to identify yourself; otherwise, setting will not be saved and subsequent changes will not be saved. Turning Personality OFF The Personality Memory feature can be turned off using the Memory OFF switch on the driver’s door. The amber indicator light will be lit when the feature is turned OFF.
Page 118 The electric remote control switch To adjust the side mirrors: 1. Find the control switch in the driver’s door panel. 2. Select the right or left mirror by moving the selector switch to R or L. 3. Move the mirror switch in the direction you want to move the mirror.
Page 119 For information about the cellular phone in your vehicle, refer to the Cellular Phone User’s Manual provided with your phone. For further questions about your Lincoln cellular phone, contact the Ford Cellular System at 1-800-367-3013(U.S.). In Canada, please contact your dealer.
Page 120 Console Your vehicle has a full console. The full console has the features shown in the following illustration. The features on the full console...
Page 121: Floor Mat
Cupholder With Full Console To open the cupholder, push down on the cupholder and release. WARNING Use only soft cups in the cupholder. Hard objects can injure you in a collision. Positive Retention Driver’s Side Floor Mat When installing or removing the driver’s side floor mat you must attach/detach from the hook on the floor.
Page 122 Trunk Opening the Trunk Manually To open and close the trunk from the outside: The trunk lock cylinder 1. Insert the key into the lock on the trunk. 2. Turn the key to the right until the trunk opens. 3. Remove the key before you close and lock the lid.
Page 123: Keyless Entry System
Using the Power Trunk Release The remote trunk lock switch located in the driver’s door trim panel can be operated at any time unless you render the switch inoperable by locking the button with your master key. The remote control for the trunk Keyless Entry System You can lock or unlock the vehicle doors and open the trunk without using a key.
Page 124: Unlocking The Doors With The Keyless Entry System
When you bought your vehicle, you were given a computer code that operates the system for your vehicle. For your convenience, we have duplicated this code in three places. The code is: on your owner’s wallet card found in the glove compartment taped to the right hinge of the trunk lid taped to the computer module inside the...
Page 125 3. To unlock the trunk, press the 5/6 button within five (5) seconds of unlocking the driver’s or passenger’s door, or re-enter the code to open the driver’s door, then press 5/6. As long as the driver’s door has been unlocked first, you can open the passenger door or the trunk in any order.
Page 126 To program your own code: 1. Select five digits for your personal code. 2. Enter the factory code that the dealership gave you. 3. Within five (5) seconds, press 1/2. 4. Within five (5) seconds of pressing 1/2, enter your personal code, pressing each digit within five (5) seconds of the previous digit.
Page 127: Remote Entry System
Arming, disarming and resetting your anti-theft system from the keyless entry The Keyless Entry system will arm the anti-theft system when you use the 7/8 and 9/0 keys to lock the doors, and will disarm or reset a triggered anti-theft alarm when you enter in the five digit code to unlock the driver’s door.
Page 128: Locking The Doors
Unlocking the doors and opening the trunk To unlock the driver’s door, press the UNLOCK control. To unlock the passenger’s door, press the UNLOCK control a second time within five (5) seconds of unlocking the driver’s door. To open the trunk, press the TRUNK button twice within five (5) seconds.
Page 129 When you use the remote entry UNLOCK, TRUNK or PANIC buttons, the illuminated entry system turns on the interior lights for 25 seconds. You can turn these lights off with the LOCK button or by turning the ignition to the RUN position. Memory Seat/Mirrors/Steering Column Feature Your vehicle allows the remote keyless entry system...
Page 130: Replacing The Batteries
If you notice a significant decrease in operating range, the batteries should be replaced. Replacement batteries can be purchased at most pharmacies, watch stores or at your Ford or Lincoln-Mercury dealer. NOTE: The operating range of the remote entry...
Page 131: Battery Saver
Battery Saver When the ignition is turned off, the vehicle will turn off battery voltage to the courtesy lamps after 10 minutes and the demand lamps after 30 minutes. This will prevent draining of the battery if those lights have been left on inadvertently or if a door is not completely closed.
Page 132: Arming The System
Arming the System To arm the system, do the following four steps in sequence. 1. Remove the key from the ignition. 2. Open any door. The alarm indicator light will start flashing to remind you to arm the system. 3. Lock the doors by using the power door lock switch, pressing the remote entry transmitter LOCK control or pressing the last two buttons (7/8, 9/0) of the keyless entry keypad.
Page 133 The anti-theft system is designed to work with the factory installed remote entry system. It may not work with other remote entry systems. Disarming an Untriggered Anti-Theft System You can disarm the system by: unlocking a front door with the key (turn the key all the way to the end of travel or the system will not disarm).
Page 134: Theft Indicator
Be sure to purchase only coded keys with a Ford or Mercury logo on it to ensure proper functionality. If both supplied keys are lost or stolen, the vehicle must be brought to the dealership for re-initialization.
Page 135 Spare Key Programming Procedure Two electronically coded keys were supplied with your vehicle, use one of these with the procedure below: Using a coded key that you can start your engine with, turn the ignition from the ON to the OFF position. Within 15 seconds, insert a new key into the ignition and turn it to ON or START.
Page 136: Seating And Safety Restraints
Seating and Safety Restraints Seats Head Restraints If you use them properly, head restraints will help protect your head and neck in a collision. A head restraint should be placed as high as possible behind your head without interfering with your vision.
Page 137 Adjustin g the Seats WARNING Never adjust the driver’s seat or seatback when the vehicle is moving. WARNING Always drive and ride with your seatback upright and the lap belt snug and low across the hips. WARNING Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop.
Page 138 latc h wil l allo wth e seatbac 5 ˚ forwar d befor e i t locks y t o unloc k th e seatbac downhil l grade s o r afte WARNING Check to see that the seat and seatback are latched securely in position.
Page 139 The rotating boot on the lap belt is designed to allow both rear seat entry/exit and access to the front seat passengers. To enter the rear seat: 1. Rotate the safety belt boot rearward. 2. Enter the rear seat in front of the safety belt. 3.
Page 140: Heated Seats - If Equipped
Heated Seats (If equipped) The driver’s and front passenger’s Heated Seats are controlled by the HEATED SEATS panel, which is located directly below the climate control panel. The Heated Seat System will only operate with the ignition key in the ON position and will maintain a temperature automatically once it is selected.
Page 141 To operate the Heated Seat System: 1. Select mode. “Both” to heat the seat back and seat cushion “Back” to heat the seat back only 2. Turn the knob to “LO” (the lowest heat level). Allow five minutes for the heat level to stabilize.
Page 142 If the seatback is moved from its forward stop angle while the seat is traveling forward, the seat will stop. If the seatback is returned to the forward stop angle position, the seat will resume its forward travel. If the seatback is returned to its upright position, the seat will return to the original position.
Page 143 The easy in/easy out feature of the driver seat moves the seat two inches forward when: the transmission is in N (Neutral) or P (Park) the driver safety belt is buckled the ignition switch is turned to ON. Important Safety Belt Information The use of safety belts helps to restrain you and your passengers in case of a collision.
Page 144 WARNING It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
Page 145: Combinatio N Lap And Shoulder Belts
WARNING Ford recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 146 Fastening the combination lap and shoulder belt Fastening the rear seat lap and shoulder belt NOTE: Be sure to read and understand Important Safety Belt Information in this chapter. To adjust the lap part of the belt, pull up on the shoulder belt until the lap belt fits snugly and as low as possible around your hips.
Page 147 While the belt retracts, guide the tongue to its original position to prevent it from striking you or the vehicle. Unfastening the lap/shoulder belts Right Front or Rear Window Seating Positions Your vehicle is equipped with a dual locking mode retractor on the shoulder belt portion of the combination lap/shoulder safety belt for front seat passenger and rear outboard passengers.
Page 148 Automatic locking mode I n thi s operatin g mode , th e shoulde wil l b e automaticall whe n th e combinatio buckled , an d doe s no t allo o f movement . Thi s mod e provide A tigh t lap/shoulde Chil...
Page 149: Safety Belt Extension Assembly
Unfastening the center rear lap safety belt NOTE: Be sure to read and understand Important Safety Belt Information in this chapter. Pull the belt across your hips and insert the tongue into the correct buckle on your seat until you hear a snap and feel it lock.
Page 150: Safet Y Belt Maintenance
WARNING Failure to follow these instructions will affect the performance of the safety belts and increase the risk of personal injury. Safet y Belt Maintenance Chec k th e safet y bel e tha t the y wor k properl Al l safet y bel t assemblies...
Page 151 Failure to follow these instructions may increase the risk of personal injury in the event of a collision. WARNING Do not attempt to service, repair, or modify the air bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer.
Page 152 WARNING If you are close to an inflating air bag, it could seriously injure you. Position your seat such that it is as far back from the steering wheel as possible but still allows you to properly control the vehicle. Childre n and Air Bags NOTE : Fo r additiona o n th e prope...
Page 153 th e burn t propellant ma y consis t o f cornstarc i s use d t o lubricat compounds , suc h a s sodiu soda ) tha t resul t fro inflate s th e ai r bag . Smal hydroxid e ma y b e presen n an d eyes , bu t non e o f th e residu...
Page 154 If any of these things happen, even intermittently, have the Air Bag Supplemental Restraint System serviced at your Ford or Lincoln-Mercury dealer immediately. Unless serviced, the system may not function properly in the event of a collision.
Page 155 Disposa l of Air Bags and Air Bag Equippe d Vehicles Fo r disposa l o f ai r bag s o r ai r ba g equippe se e you r loca l For d o r Lincoln-Mercur bag s MUS T B E dispose Safet y Restraint s for Children I n th e U.S .
Page 156 WARNING Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision. WARNING Safety belts and seats can become hot in a vehicle that has been closed up in...
Page 157 WARNING Rear-facing child seats or infant carriers should never be placed in the front seats. WARNING When using forward-facing child seats move the passenger seat as far back from the instrument panel as possible. Never secure rear-facing child seats or infant carriers in the front seat.
Page 158 WARNING Always keep the buckle release button pointing upward and away from the child seat, with the tongue between the child seat and the release button as shown in the following illustration. Safety belt buckle placement for child seats...
Page 159 WARNING Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision. Installin g Child Safet y Seats in the Fron t Seat and Rear Windo w Passenger Seatin g Positions...
Page 160 2. Pull down on shoulder belt, then grasp shoulder belt and lap belt together. See Figure...
Page 161 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. See Figure 2. Be sure that the belt webbing is not twisted. Routing the lap/shoulder belt...
Page 162 4. Insert the belt tongue into the proper buckle for that seating position until you hear and feel the latch engage. See Figure 3. Make sure tongue is latched securely to buckle by pulling on tongue. Buckling the belt.
Page 163 5. Grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. At this time, the retractor is in the automatic locking mode (child restraint mode). See Figure 4. NOTE: The dual locking mode retractor must be in the automatic locking mode to properly restrain a child seat.
Page 164 6. Allow the belt to retract. A clicking sound will be heard as the belt retracts. This indicates the retractor is in the automatic locking mode. Pull on the lap belt portion across the child seat towards the buckle and continue to pull up on the shoulder belt portion while pushing down on the child seat allowing the shoulder belt to retract to remove any slack in the seat belt.
Page 165 7. Before placing the child in the child seat, forcibly tilt the seat from side to side and in forward directions to make sure that the seat is securely held in place. See Figure 7.
Page 166 8. Double check that the retractor is in the automatic locking mode. Try to pull more belt out of the retractor. If you cannot, the belt is in the automatic locking mode. See Figure 8. Checking that the seat is secure...
Page 167: Attaching Safety Seats With Tether Straps
Checking the retractor 9. Check to make sure that the child seat is properly secured prior to each use. If the retractor is not locked, repeat steps 6 through NOTE: To remove the retractor from automatic lock mode, allow seat belt to retract fully to its stowed position and the retractor will automatically switch back to the vehicle sensitive locking mode for normal adult usage.
Page 168 Tether anchorage hardware Attachmen t hole s (a t eac h rea r outboar position ) hav e bee n provide attac h ancho r hardware hardwar e kit s (par t numbe instructions , ma y b e obtaine For d o r Lincoln-Mercur fo r sal e i n Canad...
Page 169 T o improv e th e fi t o f la p an d shoulde childre n who hav e outgrow recommend s us e o f a belt-positionin t i s labelle d a s conformin vehicl e safet y standards seat s rais...
Page 170: Starting Your Vehicle
Starting Fuel-Injected Engines Whe n startin g a fuel-injecte d engine , important thing to remember is to avoid pressing down on the accelerator before or during starting. Onl y us e the accelerato r whe n you hav e problem s gettin g you r vehicl e started . See Starting Your Engine in thi s chapte r for details abou t whe n to us e the accelerato r whil e yo u start you r vehicle.
Page 171: Starting Your Engine
3. Make sure that the gearshift is in P (Park) and the parking brake is set before you turn the key. Before you start your vehicle, you should test the warning lights on the instrument panel to make sure that they work. Refer to the Instrumentation chapter.
Page 172 Whenever you start your vehicle, release the key as soon as the engine starts. Excessive cranking could damage the starter. After you start the engine, let it idle for a few seconds. Keep your foot on the brake pedal and put the gearshift lever in gear.
Page 173: Engine Block Heater - If Equipped
WARNING Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. WARNING Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire.
Page 174: Guarding Against Exhaust Fumes
Pushing Vehicle s wit h automati c transmission s canno t be starte d by pushing . Follo w the direction s unde r Your Vehicle Needs a Jump-Start in the Roadside Emergencies Chapter. Guarding Against Exhaust Fumes Carbo n monoxide , althoug h colorles s an d odorless, is presen t in exhaus t fumes .
Page 175 Have the exhaust and body ventilation systems checked whenever: your vehicle is raised for service the sound of the exhaust system changes your vehicle has been damaged in a collision Improve your ventilation by keeping all air inlet vents clear of snow, leaves, and other debris. If the engine is idling while you are stopped in an open area for long periods of time, open the windows at least one inch (2.5 cm).
Page 176: Applying The Brakes
Ford Motor Company has not found any detrimental effects of popular mobile radio transmitting equipment installed on vehicles with the anti-lock brake system, if the equipment is installed according to the manufacturer’s...
Page 177 ligh t come s on at an y tim e othe r tha n righ t after yo u tur n the ke y to the ON positio n or durin g a sudde n stop , hav e you r mobil e radi o deale r inspect the installation.
Page 178 WARNING If the parking brake is fully released, but the Brake System light remains on, have the brakes checked immediately. They may not be working properly. WARNING To prevent personal injury, do not release the parking brake while outside the vehicle. To disengag e the parkin g brake: Th e ignitio n ke y mus t be in the RU N position.
Page 179: Traction Control
Manual parking brake release lever The parking brake is not designed to stop a moving vehicle, but you can use the parking brake to stop your vehicle in an emergency if the normal brakes fail. However, since the parking brake applies only the rear brakes, the stopping distance will increase greatly and the handling of your vehicle will be adversely affected.
Page 180: Air Suspension System
NOTE: Engine torque reduction is NOT active when engine coolant temperature is below -10˚F (-23˚C). During the Traction Control often occurs during low speed acceleration on slippery surfaces, a noise may be heard coming from the engine compartment. This is normal and may last for a few seconds during the acceleration of the vehicle.
Page 181 ignition switch is in the ON position and the shutoff switch is in the OFF position. “CHECK AIR RIDE” will appear when a system fault has been detected and the ignition switch is in the ON position. Normal vehicle operation does not require any action by the driver.
Page 182: Steering Your Vehicle
NOTE: If the temperatur e drop s overnight , the vehicl e ma y appea r low becaus e the air in the air sprin g contracts . Thi s is normal ! Th e vehicl e will retur n to regula r heigh t soo n afte r the vehicl e is started.
Page 183 To move the shifter out of P (Park), the ignition key must be turned to the ON position. This vehicle is also equipped with the brake shift interlock safety feature which prevents shifting the transmission out of the P (Park) position without the brake pedal being depressed if the key is in the ON position.
Page 184 WARNING DO NOT DRIVE YOUR VEHICLE UNTIL YOU VERIFY THAT THE BRAKELAMPS ARE WORKING. Onc e yo u plac e the gearshif t securel y int o position, graduall y releas e the brak e peda l an d us e the accelerato r as necessary.
Page 185 R (Reverse) With the gearshift in the R (Reverse) position, the vehicle will move backward. You should always come to a complete stop before shifting into or out of R (Reverse). N (Neutral) With the gearshift in the N (Neutral) position, the vehicle can be started and is free to roll.
Page 186 When to use D (Overdrive) Overdrive is the usual driving position for an automatic overdrive transmission. It works the same way Drive works, automatically upshifting or downshifting as the vehicle speeds or slows. However, Overdrive also shifts into a fourth gear — an overdrive gear —...
Page 187 You can tel l a console-mounte d gearshif t is securely latche d in P (Park ) if the leve r is adjacen t to the P (Park ) an d yo u canno t mov e it withou t pushin g in the thum b button.
Page 188 Limiting Your Vehicle’s Load The load that you add to your vehicle must not exceed the maximum load stated on the Safety Compliance Certification Decal attached to the left front door pillar. To figure the weight of your vehicle’s load, add the weights of: the driver and passengers luggage and any other items that you put in...
Page 189: Trailer Towing
Trailer Towing Your vehicle does not come from the factory fully equipped to tow. No towing packages are available through Ford or Lincoln/Mercury Because towing a trailer puts extra strain on your vehicle, you must follow certain precautions for your safety and the good of your vehicle: Stay within the load limits for towing your vehicle.
Page 190: Preparing To Tow
Also, make sure that all towing equipment is properly attached to your vehicle. If you are not certain that you are using the right equipment in the proper manner, see your Ford or Lincoln-Mercury dealer.
Page 191 Do not use hitches that clamp onto your vehicle’s bumper. The bumper is not designed to bear the load. Always check the pressure in all your vehicle’s tires when preparing to tow (see inflation recommendation on the tire label). Using the hitch Your vehicle uses a load carrying hitch.
Page 192: Driving While You Tow
To get the proper equipment for hooking up your trailer’s lights, see your local trailer dealer and your Ford dealer. Be sure to follow their instructions carefully. If you do not install trailer lights correctly, you may cause damage to the vehicle’s lighting system.
Page 193 If you tow in D (Overdrive) while riding through hilly country, your vehicle may frequently shift between Overdrive and Third gears. To prevent your vehicle from shifting too much, press the Transmission Control Switch located on the shift lever. This will also give the engine more power going up hills and better engine braking going down hills.
Page 194: Roadside Emergencies
Roadside Emergencies Hazard Flashers The flashers work whether your vehicle is running or not. The flashers work for up to two hours when the battery is fully charged and in good condition without draining the battery excessively. If the flashers run for longer than two hours or if the battery is not fully charged, the battery can be drained.
Page 195 The fuel pump shut-off switch WARNING If you see or smell fuel, do not reset the switch or try to start your vehicle. Have all the passengers get out of the vehicle and call the local fire department or a towing service. If your engine cranks but does not start after a collision or substantial jolt: 1.
Page 196 5. Check under the vehicle again for leaking fuel. If you see or smell fuel, do not start your vehicle again. If you do not see or smell fuel, you can try to start your vehicle again. Fuses Fuses (miniature and high current) protect your vehicle’s wiring system from overloading.
Page 197 The instrument panel fuse box...
Page 198 The Instrument Panel Fuses, Circuit Breakers and Relays...
Page 200 High current fuses are circuit protectors that are part of the wiring harness for some electrical equipment. These, like fuses, open when the circuit load exceeds their amperage rating. High current fuses may be purchased from your Ford or Lincoln-Mercury dealer.
Page 201 The high current fuse panel is located in the engine compartment on the left-hand fender apron. WARNING Always disconnect the battery before servicing high current fuses. Ford recommends that high current fuses be replaced by a qualified technician. The high current fuse panel location...
Page 203 The high current fuses...
Page 204: Checking And Replacing Fuses
Checking and Replacing Fuses If you need to check a fuse, follow these steps: 1. Find the fuse panel on driver’s side end of the instrument panel by opening the door. Unsnap cover from the instrument panel. 2. Find the fuse you want to check (fuses are numbered on the fuse panel) and remove it with the fuse pulling tool that is provided.
Page 205 The side view of a Blade type fuse The side view of a high current fuse 4. Replace the fuse with one that has the right amperage rating. (See the following charts.)
Page 206: Changing A Tire
WARNING Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. 5. Replace the cover. Even after you replace a fuse, it may continue to blow if you do not find what caused the overload.
Page 207: Spare Tire Location
When you drive with the temporary spare tire, DO NOT: exceed 50 mph (80 km/h) under any circumstances. load your vehicle so that it is heavier than the maximum vehicle load rating listed on the tire decal. tow a trailer. use tire chains on this tire.
Page 208 The spare tire location To remove the spare tire: 1. Remove the spare tire cover. 2. Unscrew the wing-nut holding down the spare tire. NOTE: Wing-nut is not removable. 3. Unscrew the wing-bolt holding down the jack and handle. 4. Lift out the spare tire, jack, and lug wrench. Preparing to Change the Tire 1.
Page 209 WARNING On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle. The air suspension switch — located in the trunk...
Page 210 WARNING If the vehicle slips off the jack, you or someone else could be seriously injured. 2. Get out the spare tire and jack. WARNING To avoid injury, never run the engine with one wheel off the ground, such as when changing a tire.
Page 211 WARNING To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire.
Page 212 NOTE: Never use the differential housing as a lift point. The slot for the jack 2. Turn the jack handle clockwise until the wheel clears the ground. Remove the wheel lug nuts. 3. Replace the flat tire with the spare tire, making sure that the air valve stem is facing outward.
Page 213 (not the dealer) to get a replacement key. NOTE: If entire lug wrench/lug nut key assembly is lost, see your nearest Ford or Lincoln-Mercury dealer who has access to a master set of keys. NOTE: DO NOT USE A POWER IMPACT...
Page 214: Jump-Starting Your Vehicle
The anti-theft lug nut and key Removing the anti-theft lug nut Insert the key over the locking lug nut. Make sure that you hold the key square to the lug nut. If you hold the key on an angle, you may damage the key and the lug nut.
Page 215: Preparing Your Vehicle
WARNING To protect yourself when charging a battery, always shield your face and eyes. Make sure that you can breathe fresh air. WARNING Applying too much pressure on the ends when lifting a battery could cause acid to spill. Lift the battery with a carrier or with your hands on the opposite corners.
Page 216 2. Do not disconnect the battery of the disabled vehicle. You could damage the vehicle’s electrical system. 3. Park the booster vehicle close to the hood of the disabled vehicle. Make sure the vehicles do not touch each other. Set the parking brake on both vehicles and stay clear of the engine cooling fan and other moving parts.
Page 217: Jump Starting
WARNING Do not connect the end of the second cable to the negative ( ) terminal of the battery to be jumped. A spark may cause an explosion of the gases that surround the battery. Jump-Starting 1. Make sure that the jumper cables are not in the way of moving engine parts, then start the booster vehicle.
Page 218: Towing Your Vehicle
After the vehicle is started, let it idle for a while to let the engine “relearn” its idle conditions. Drive it around for a while with all electrical accessories turned off to let the battery recharge. Driveability may be deteriorated slightly until all drive modes are “relearned.”...
Page 219 DO NOT TOW WITH SLINGBELT EQUIPMENT. Ford Motor Company has not developed or approved a T-hook sling-type procedure. Use wheel lift or flatbed equipment. When towing your Mark VIII with wheel lift equipment, be sure dollies are in place under the trailing wheels if the air suspension is deflated to prevent damage to the air deflector.
Page 220: Maintenance And Care
Maintenance and Care Service Made Easy Ford has two goals for servicing your vehicle. 1. When we can, we design parts that do not need to be serviced. 2. We want to make servicing your vehicle as easy as possible. To help you:...
Page 221 Ford replacement parts. While imitation body parts may appear similar to genuine Ford parts on the surface, differences in quality become obvious when both are subjected to standard Ford quality tests.
Page 222: Precautions When Servicing Your Vehicle
Precautions When Servicing Your Vehicle Be especially careful when inspecting or servicing your vehicle. Here are some general precautions for your safety: Do not work on a hot engine. The engine cooling fan may come on unexpectedly. Always turn the engine off and let it cool. WARNING The cooling fan is automatic and may come on at any time.
Page 223 3. Block the wheels. This will prevent your vehicle from moving unexpectedly. Working with the engine on: 1. Set the parking brake fully and make sure that the gearshift is securely latched in P (Park). 2. Block the wheels. This will prevent your vehicle from moving unexpectedly.
Page 224: Opening The Hood
Opening the Hood 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel. The hood release under the instrument panel 2. Go to the front of the vehicle and release the auxiliary latch that is located under the hood at the center of the vehicle.
Page 225: Engine Compartment
Whenever you close the hood, latch it securely. NOTE: Apply lubricant to the hood latch at six-month intervals to maintain smooth and trouble-free operation. NOTE: Read and understand Precautions When Servicing Your Vehicle at the beginning of this chapter before opening the hood. If the battery is disconnected, the computer must relearn its idle control.
Page 226 A 4.6 Liter 4V SFI engine...
Page 227: Engine Oil Recommendations
Engine Oil Recommendations We recommend using Motorcraft oil or an equivalent oil meeting Ford Specification WSS-M2C153-F and displaying the American Petroleum Institute CERTIFICATION MARK on the front of the container. The API Certification Mark Never use: “Non-Detergent” oils Oils labeled API SA, SB, SC, SD, SE, SF or SG...
Page 228: Checking And Adding Engine Oil
Checking and Adding Engine Oil Since the proper amount of engine oil is important for safe engine operation, check the oil using the dipstick each time you put fuel in your vehicle. Remember the engine must be off, the oil must be warm and the vehicle must be parked on level ground.
Page 229: Changing The Engine Oil And The Oil Filter
It may be necessary to add some oil between oil changes. Make sure you use a CERTIFIED engine oil of the preferred viscosity. Your vehicle’s warranty coverage may not apply if engine damage is caused by the use of improper engine oil. Add engine oil through the oil filler cap highlighted in yellow.
Page 230: Brake Fluid
If the fluid is low, carefully clean and remove the cap from the reservoir. Fill the reservoir to the MAX line with Ford High Performance DOT 3 Brake Fluid C6AZ-19542-AB or equivalent DOT 3 fluid meeting Ford specification ESA-M6C25-A.
Page 231 WARNING If you use a brake fluid that is not DOT 3, you will cause permanent damage to your brakes. Do not fill the reservoir above the MAX line. If you find that the fluid level is excessively low — below the seam or ridge on the outside of the plastic reservoir —...
Page 232: Windshield Washer Fluid
Windshield Washer Fluid Washer Fluid Check the level of the windshield washer fluid periodically, or when the warning message indicates low fluid. The reservoir for washer fluid is located in front of the engine compartment behind driver’s side headlamp. The reservoir for the windshield washer fluid WARNING Do not put windshield washer fluid in the container for the engine coolant.
Page 233: Engine Coolant
Engine Coolant Checking the Engine Coolant NOTE: Be sure to read and understand Precautions When Servicing Your Vehicle at the beginning of this chapter. WARNING The cooling fan is automatic and may come on at any time. Always disconnect the negative terminal of the battery before working near the fan.
Page 234: Adding Engine Coolant
Adding Engine Coolant WARNING Do not put engine coolant in the container for the windshield washer fluid. If sprayed on the windshield, engine coolant could make it difficult to see through the windshield. When the engine is cool, add a 50/50 mixture of engine coolant and water to the engine coolant recovery reservoir —...
Page 235 Ford specification ESE-M97B44-A. Ford Premium Engine Coolant is an optimized formula that will protect all metals and rubber elastomers used in Ford cooling systems for 4 years or 50,000 miles (80,000 km). Do not use alcohol or methanol antifreeze or any engine coolants mixed with alcohol or methanol antifreeze.
Page 236: Engine Coolant Refill Procedure
concentration in your vehicle is such that the coolant will not freeze at the temperature level in which you drive during winter months. Never increase the engine coolant concentration above 60%. Leave a 50/50 mixture of engine coolant and water in your vehicle year-round in non-extreme climates.
Page 237 Reinstall the engine coolant tube fill plug when the system is full. Select maximum heater temperature and fan speed settings. Position control to discharge air at A/C vents in instrument panel. Start engine and allow to idle. While engine is idling, feel for hot air at A/C vents.
Page 238: Power Steering Fluid
Power Steering Fluid Check the level of the power steering fluid at least twice a year (i.e., every Spring and Fall). Checking and Adding Power Steering Fluid 1. Start the engine and let it run until the power steering fluid reaches normal operating temperature.
Page 239: Automatic Transmission Fluid
Fluid level for power steering Use only MERCON ATF power steering fluid. If the power steering fluid is low, do not drive your vehicle for a long period of time before adding fluid. This can damage the power steering pump. Automatic Transmission Fluid Under normal circumstances, you do not need to check the fluid level of the transmission, since your...
Page 240 NOTE: If the vehicle has been operated for an extended period at high speeds or in city traffic during hot weather, or pulling a trailer, the vehicle should be turned off for about 30 minutes to allow the fluid to cool before checking. Checking the Automatic Transmission Fluid With the vehicle on a level surface and the brake...
Page 241 NOTE: Always dispose of used automotive fluids in a responsible manner. Follow your community’s standards for disposing of these types of fluids. Call your local recycling center to find out about recycling automotive fluids. Automatic transmission dipstick Battery Your vehicle may have a Motorcraft maintenance-free battery.
Page 242: Wiper Blades
Help Us Protect Our Environment Ford Motor Company strongly recommends that used lead-acid batteries be returned to an authorized recycling facility for disposal. Battery recycling symbol Because your vehicle’s engine is electronically controlled by a computer, some control conditions are maintained by power from the battery. If you ever disconnect the battery or install a new battery, you must allow the computer to “relearn”...
Page 243: Wiper Blade Replacement
Rinse thoroughly with clear water. Do not use fuel, kerosene, paint thinner, or other solvents to clean your wiper blades. These will damage your blades. To make reaching the wiper blades easy, simply turn the ignition to the ACC position and turn your wipers on.
Page 244: Tire Rotation
Tire Rotation Because your vehicle’s front and rear tires perform different jobs, they often wear differently. To make sure your tires wear evenly and last longer, rotate them as indicated in the following diagram. Do not include the spare tire as part of your rotation.
Page 245: Replacing The Tires
Replacing the Tires Replace any tires that show wear bands. When your tire shows a wear band, it has only 1/16 inch (2 mm) of tread left. A worn-out tire Because your vehicle’s tires may wear unevenly, you may need to replace them before a wear band appears across the entire tread.
Page 246 Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation — Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 247: Temperature A B C
WARNING The traction grade assigned to this tire is based on braking (straightahead) traction tests and does not include cornering (turning) traction. Temperature A B C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 248: Filling The Fuel Tank
The all weather tread pattern on your tires helps maintain traction in rain or snow. However, to achieve the best traction in snow and ice conditions, you may need to use snow tires. To prevent body damage, do not use snow chains on your Mark VIII.
Page 249 If the fuel door does not open when you push the release button, open the trunk and find the override release on the right side. The override release is a handle which says FUEL FILLER DOOR RELEASE MANUAL OVERRIDE. Open the fuel door by pulling on the handle.
Page 250: Choosing The Right Fuel
3. To replace the fuel cap, align the tabs on the cap with the notches on the filler pipe. Push down and turn it clockwise until it stops. 4. Push the fuel door closed. WARNING If you do not use the proper fuel cap, the pressure in the fuel tank can damage the fuel system or cause it to work improperly in a collision.
Page 251 If the condition persists, see your dealer or a qualified service technician. The American Automobile Manufacturers Association (AAMA) issued a gasoline specification to provide information on high quality fuels that optimize the performance of your vehicle. We recommend the use of gasolines that meet the AAMA specification if they are available.
Page 252 Cleaner Air Ford approves the use of gasolines to improve air quality, including reformulated gasolines that contain oxygenates such as a maximum of 10% ethanol or 15% MTBE. There should be no more than 5% methanol with cosolvents and additives to protect the fuel system.
Page 253: Running Out Of Fuel
If you are taking the medication “Antabuse” or other forms of disulfiram for the treatment of alcoholism, vapor or skin contact with a gasoline-methanol blend, may cause the same kind of adverse reaction as drinking an alcoholic beverage. In sensitive individuals, serious personal injury or sickness could result.
Page 254 To calculate fuel economy: 1. Fill the tank completely and record the initial odometer reading. 2. Every time you buy fuel record the amount (in gallons or liters) purchased. 3. After at least three to five tankfuls, fill the fuel tank and record the final odometer reading.
Page 255: Emission Control System
Extended use of the A/C, defroster, rear window defroster and other accessories Underinflated tires Heavy loads Aftermarket add-ons such as bike, ski or luggage racks, bug deflectors, etc. Self-Service Pointers If you choose to do your own fueling, you should also perform a few simple maintenance routines.
Page 256 In general, maintenance, replacement, or service of the emissions control devices or systems in your new Ford Motor Company vehicle or engine may be performed at your expense by any automotive repair establishment or individual using automotive parts equivalent to those which your vehicle or engine was originally equipped.
Page 257 WARNING Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Watch for fluid leaks, strange odors, smoke, loss of oil pressure, the charge warning light, the check engine light, or the temperature warning light.
Page 258 How to Prepare Your Vehicle for Inspection/Maintenance (I/M) Testing In some localities it may become a legal requirement to pass an Inspection/Maintenance (I/M) test of the On-Board Diagnostic (OBD) II system. If the vehicle’s powertrain system or its battery has just been serviced, the OBD II system is reset to a not ready for I/M testing condition.
Page 259: Headlamp Bulb
The alignment of your headlamps should be checked if: oncoming motorists frequently signal you to turn off your vehicle’s high beams when you do not have the high beams on the headlamps do not seem to give you enough light to see clearly at night the headlamp beams are pointed substantially away from a position slightly down and to the right...
Page 260 Headlamp bulb removal Removing the high beam headlamp bulb 1. Make sure that the headlamp switch is in the OFF position. 2. Lift the hood, remove the sight shield above the headlamp and find the bulb in the headlamp socket. 3.
Page 261 4. Replace the high beam dust cap by aligning tabs and rotating clockwise 1/4 turn. 5. Replace the sight shield. Aiming Headlamps Your vehicle is equipped with a Vehicle Headlamp Aim Device (VHAD) on each headlamp body. Each headlamp may be properly aimed in the horizontal direction (left/right) and the vertical position (up/down).
Page 262 Before adjusting your headlamps, you must make sure that the air suspension has been adjusted to the proper ride height. In order to do this: 1. Position the vehicle on a level surface. 2. Make sure the air suspension switch in the luggage compartment is in the ON position.
Page 263 Horizontal aim adjustment 1. Open the hood and lift the front end cover from its velcro attachments. Locate the horizontal level indicator and adjustment screw. 2. Use a 6mm socket and ratchet to turn the horizontal adjusting screw until the horizontal indicator is in line with the “0”...
Page 264 Bulb specifications...
Page 265: Cleaning Your Vehicle
Ford, however, believes that continual improvement in customer satisfaction is a high priority. For this reason, Ford has authorized its dealers to repair, at no charge to the owner, the surfaces of new vehicles damaged by environmental fallout within 12 months or 12,000 miles (20,000 km) of purchase, whichever comes first.
Page 266: Cleaning Plastic Parts
Cleaning Plastic Parts Some of your vehicle’s exterior trim parts are plastic. Clean with a tar and road oil remover if necessary. Use a vinyl cleaner for routine cleaning. Do not clean plastic parts with thinners, solvents or petroleum-based cleaners. If you have your vehicle rustproofed, remove oversprayed rustproofing with a tar and road oil remover.
Page 267: Cleaning The Wheels
Cleaning the Interior Lamps Your interior dome lamps and map lamps are plastic and should be cleaned with a mild detergent diluted in water. Rinse them with clear water. Cleaning the Seats Leather For routine cleaning, wipe the surface with a soft, damp cloth.
Page 268: Capacities And Specifications
Capacities and Specifications Refill Capacities, Motorcraft Parts, and Lubricant Specifications Motorcraft Parts...
Page 269: Fluid Specifications And Capacities
Fluid Specifications and Capacities NOTE: Rear axle lube quantities must be replaced every 100,000 miles (160,000 km) or if the axle has been submerged in water. Otherwise, the lube should not be checked or changed unless a leak is suspected or repair required.
Page 270: Lubricant Specifications
Lubricant Specifications...
Page 271: Vehicle Storage
NOTE: Rear axle lube quantities must be replaced every 100,000 miles (160,000 km) or if the axle has been submerged in water. Otherwise, the lube should not be checked or changed unless a leak is suspected or repair required. Vehicle Storage Maintenance Tips If you plan on storing your vehicle for an extended period of time (60 days or more), refer to the...
Page 272 This can damage rubber and other polymers in the fuel system and may also clog small orifices. Ford Gas Stabilizer should be added whenever actual or expected storage periods exceed 60 days. Follow the instructions on the label. The vehicle should then be operated at idle speed to circulate the additive throughout the fuel system.
Page 273 Battery Check and recharge as necessary. Keep connections clean and covered with a light coat of grease. If storing your vehicle for more than 30 days without recharging the battery, disconnect the battery cables to ensure battery charge is maintained for quick starting. NOTE: If battery cables are disconnected, it will be necessary to reset any memory features (eg.
Page 274: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 366-0123 in the Washington, D.C.
Page 275: Customer Assistance
If you are away from home when your vehicle needs to be serviced, or if you need more help than the dealer gave you, contact the Ford Customer Assistance Center to find an authorized dealership that may be able to help you.
Page 276: The Dispute Settlement Board (U.s. Only)
Ford Motor Company vehicles The Dispute Settlement Board may not be available in all states. Ford Motor Company reserves the right to change eligibility limitations, modify procedures and/or to discontinue this service without notice...
Page 277 Ford, Mercury and Lincoln cars and Ford and Mercury light trucks under the new vehicle limited warranty that have not been resolved by either a dealer or Ford Motor Company, except those involving: a non-Ford product a non-Ford dealership...
Page 278 DSB’s independent administrator Your dealership and a Ford Motor Company representative are asked to submit statements at this time. To review your case properly, the Board needs the...
Page 279 Board’s decision. The decisions of the Board are binding on the dealer and Ford, but not on consumers who may elect to pursue other remedies available to them under state or federal law. Decisions of the Board may be...
Page 280: To Request A Dsb Brochure/Application
To Request a DSB Brochure/Application For a brochure/application, speak to your dealer or write to the Board at the following address: Ford of Canada Customer Assistance If you live in Canada and have any questions or concerns that the dealership cannot answer, contact the Lincoln Centre.
Page 281: Canada Only
CAMVAP decisions are fast, fair and final as the arbitrator’s award is binding on both you and Ford of Canada. CAMVAP services are available in all territories and provinces, except Quebec. For more information, without charge or obligation, call your CAMVAP Provincial Administrator directly at 1-800-207-0685.
Page 282 Use of leaded fuel in your vehicle without a proper conversion may damage the effectiveness of your emissions control system and may cause engine knocking or serious engine damage. Ford Motor Company is not responsible for any damage that is caused by use of improper fuel.
Page 283 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write to: If you are in other foreign countries, contact the nearest Ford dealership.
Page 284 Ford-built vehicle. In addition, each accessory is made from high quality materials and meets or exceeds Ford’s rigid engineering and safety specifications. That is why Ford brand accessories are warranted for up to 12 months or 12,000 miles (20,000 km), whichever comes first.
Page 285 NOTE: When adding accessories, equipment, passengers, and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR, GAWR as shown on the Safety Compliance Certification Label). Consult your dealer for specific weight information.
Page 286 5 watts or less will not ordinarily affect your vehicle’s operation.) NOTE: Because we have no control over the installation, design, or manufacture of such systems, Ford cannot assume responsibility for any adverse effects or damage that may result if you use this equipment.
Page 296 Index ABS warning light (see Anti-lock brake system) ... . Accessory position on the ignition ..Accident damage ... . 216 Air bag supplemental restraint system .
Page 297 Anti-theft system arming the system ..127 description ... . . 127 disarming an untriggered system ..128 disarming a triggered system.
Page 298 Brakes adjustment ... . . 171 anti-lock ....171 anti-lock brake system (ABS) warning light ... applying the brakes.
Page 299 Chains, tires ....242 Changing a tire ... . 201 Charging system warning light ..Child safety restraints .
Page 300 Cruise control indicator light ..Customer Assistance Centre, Ford of Canada ... . 276 Daytime running light system ..
Page 301 Driving under special conditions heavy load ... . . 182 towing a trailer ... 184 Electrical system, fuses ..191 Electronic sound system antenna.
Page 302 Exhaust fumes ... . . 169 Extended Service Plan, Ford ..4 Fan ....217 engine fan, avoiding injury .
Page 303 Ford of Canada Customer Assistance Centre ... 276 Foreign registration ... 278 French owner guides, how to obtain ..
Page 304 Gas cap (see Fuel cap) ..243 Gas mileage (see Fuel economy) . . . Gasoline (see Fuel) ... 243 Gauges engine coolant temperature gauge . . . fuel gauge.
Page 305 Headlamps (continued) flashing ....high beam ... . . replacing bulbs ... 253 turning on and off .
Page 306 Keyless entry system locking and unlocking doors ..119 programming entry code ..120 Keys key in ignition chime ..positions of the ignition ..removing from the ignition .
Page 307 Load limits ....182 GAWR ....182 GVWR ....182 trailer towing .
Page 308 Octane rating ... . . 246 Odometer ....Oil filter ... . Oil (see Engine oil) .
Page 309 Remote entry system arming and disarming the anti-theft system ..123 locking/unlocking doors..123 opening the trunk ..123 panic alarm .
Page 310 for infants... head ....131 lap and shoulder belts ..138 lap belt .
Page 311 Sliding moon roof (see Moon roof) ..Snow tires and chains ..242 Spare tire ....201 changing the tire.
Page 312 Tires ....238 changing ....201 checking the pressure..238 cleaning .
Page 313 Variable interval wipers ..VECI (Vehicle Emission Control Information) decal ....252 Vehicle loading automatic transmissions ..183 calculating the load .
Page 314 Wheels anti-theft lugnuts ... 208 cleaning ....262 covers ... . inspection and maintenance .
Page 315: Service Station Information
Service Station Information...

This manual is also suitable for:

1997 mark viii

Ford 1999 Taurus Owner's Manual

Quick Links

Related Manuals for Ford 1999 Taurus

Summary of Contents for Ford 1999 Taurus

This manual is also suitable for:

Table of Contents
