Page 2: Introduction
INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Ford may change the contents without notice and without incurring obligation.
Page 3 Driving chapter. Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation package. Notice to owners of utility type vehicles Before you drive your vehicle, please read this Owner’s Guide carefully.
Page 4 Instrumentation Instrument cluster Speed control* (pg. 6) (pg. 62) THEFT FUEL SELECT km/h RESET RESET P RN BRAKE ACCEL Headlamp control Turn signal and Driver side air bag (pg. 16) wiper/washer control (pg. 95) (pg. 67) Instrument panel * if equipped dimmer switch (pg.
Page 5: Climate Control
Instrumentation Gearshift (includes overdrive button) Electronic sound system (pg. 122) (pg. 19) VOL-PUSH ON FM 1 FADE AUTO BASS TREB SEEK DOLBY 8 NR TAPE CD SCAN TUNE DISCS SIDE 1-2 COMP SHUFFLE PANEL & FLOOR PASSENGER AIRBAG FLOOR PANEL FLR&...
Page 6: Warning Lights And Chimes
Instrumentation WARNING LIGHTS AND CHIMES Standard instrument cluster THEFT DOOR AJAR RANGE FUEL FUEL SELECT SERVICE km/h RESET RESET ENGINE SUSP SOON P RN BRAKE FUEL DOOR Optional instrument cluster DOOR THEFT AJAR RPMX1000 RANGE FUEL SELECT/RESET SERVICE km/h SUSP ENGINE SOON P RN...
Page 7 Instrumentation Service engine soon Your vehicle is equipped with a SERVICE computer that monitors the engine’s ENGINE emission control system. This SOON system is commonly known as the On Board Diagnostics System (OBD II). The OBD II system protects the environment by ensuring that your vehicle continues to meet government emission standards.
Page 8 Instrumentation Light is blinking: Engine misfire is occurring which could damage your catalytic converter. You should drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced at the first available opportunity. Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.
Page 9: Instrumentation
Instrumentation Anti-lock brake system (ABS) Momentarily illuminates when the ignition is turned to the ON position and the engine is off. If the light remains on, continues to flash or fails to illuminate, have the system serviced immediately. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the brake warning light also remains illuminated with parking brake released.
Page 10 (TCIL). The TCIL may flash steadily if a malfunction is detected. If the TCIL is flashing, contact your Ford dealer as soon as possible. If this condition persists, damage to the transmission could occur. Four wheel drive low (if equipped) This light momentarily illuminates when the ignition is turned to ON.
Page 11 Instrumentation Check air suspension (if equipped) Illuminates momentarily when the ignition is turned to the ON position and the engine is OFF. The light also SUSP illuminates when the air suspension system requires servicing. For information, refer to Air suspension system in the Driving chapter. Door ajar Illuminates when the ignition is in the ON or START position and any...
Page 12: Fuel Gauge
Instrumentation GAUGES Standard instrument cluster gauges THEFT DOOR AJAR RANGE FUEL FUEL SELECT SERVICE km/h RESET RESET ENGINE SUSP SOON P RN BRAKE FUEL DOOR Optional instrument cluster gauges DOOR THEFT AJAR RPMX1000 RANGE FUEL SELECT/RESET SERVICE km/h SUSP ENGINE SOON P RN BRAKE...
Page 13 Instrumentation Speedometer Indicates the current vehicle speed. km/h Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H” and “C”). If it enters the red section, the engine is overheating.
Page 14 Instrumentation Trip odometer Registers the kilometers (miles) of individual journeys. Press and release the reset button until a “T” P RN appears in the display (this represents the trip mode). Press and hold the button for 2.5 seconds to reset. Tachometer Indicates the engine speed in revolutions per minute.
Page 15 Instrumentation Engine oil pressure gauge This shows the engine oil pressure in the system. Sufficient pressure exists as long as the needle remains in the normal range (the area between the “L” and “H”). If the gauge indicates low pressure, stop the vehicle as soon as safely possible and switch off the engine immediately.
Page 16: Controls And Features
Controls and features HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking PULL lamps. Rotate to the second position to also turn on the headlamps. Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. To activate: •...
Page 17 Controls and features PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlamp and parklamp operation. • Rotate up to brighten. • Rotate down to dim. • Rotate to full down position to turn off. AUTOLAMP CONTROL (IF EQUIPPED) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally...
Page 18 Controls and features 4WD CONTROL (IF EQUIPPED) This control operates the 4WD. Refer to the Driving chapter for more information. AUXILIARY POWER POINT The auxiliary power point is located on the instrument panel. Do not plug optional electrical accessories into the cigarette lighter. Use the power point.
Page 19 Controls and features USING YOUR AUDIO SYSTEM AM/FM Stereo PUSH SEEK TONE TONE VOL TUNE AM/FM AM/FM Stereo PUSH SEEK TONE TONE VOL TUNE AM / FM STEREO AM/FM Your vehicle is equipped with a delayed accessory feature. This feature enables the audio playing media to continue playing up to 10 minutes after the ignition has been turned off, or until a door is opened.
Page 20: Controls And Features
Controls and features Volume/power control Press the control to turn the audio PUSH system on or off. Turn the control to raise or lower volume. PUSH If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 21 Controls and features • Press to move to the next frequency up the band (whether or not a listenable station is located there). Hold for quick movement. Seek function The seek function control works in radio mode. Seek function in radio mode •...
Page 22 Controls and features Treble adjust The treble adjust control allows you PUSH to increase or decrease the audio system’s treble output. TONE With the electronic AM/FM stereo, press the TONE control twice, then use the volume knob to adjust the level.
Page 23 Controls and features • to decrease hours and • to increase hours. SEEK SEEK TUNE TUNE To set the minute, press and hold the CLK control and press: TONE • to decrease minutes and SEEK SEEK • to increase minutes. TUNE TUNE The CLK control will allow you to...
Page 24 Controls and features AM/FM Stereo/Cassette (CD changer compatible) VOL - PUSH ON BASS TREB FADE TAPE SEEK SIDE 1 - 2 SCAN TUNE DISCS COMP SHUFFLE Your vehicle is equipped with a delayed accessory feature. This feature enables the audio playing media to continue playing up to 10 minutes after the ignition has been turned off, or until a door is opened.
Page 25 Controls and features If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. AM/FM select The AM/FM select control works in radio, tape and CD changer modes (if equipped).
Page 26 Controls and features Tune adjust for CD changer (if equipped) • Press to select the previous SEEK disc in the CD changer. (Play will begin on the first track of the TUNE disc unless the CD changer is in DISCS shuffle mode.
Page 27 Controls and features Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the SCAN control again to stop the scan mode. Scan function in CD changer mode (if equipped) Press the SCAN control to hear a brief sampling of all selections on the CD.
Page 28 Controls and features Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output. TREB Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers.
Page 29 Controls and features Automatic Music Search The Automatic Music Search feature allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection. TAPE To activate the feature, momentarily depress the TAPE AMS button. Then, press either REW (for the beginning of the current selection) or FF (to advance to the next selection).
Page 30 Controls and features Fast forward The fast forward control works in tape and CD changer modes. To fast forward in tape mode, press SIDE 1 - 2 the 1–2/FF control. Tape direction will automatically reverse when the end of the tape is reached.
Page 31 Controls and features Eject function Press the control to stop and eject a tape. Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise reduction. The noise reduction system is manufactured under license from Dolby Laboratories Licensing Corporation.
Page 32 Controls and features To set the minute, press and hold the CLK control and press: TAPE • to decrease minutes and SEEK SEEK • to increase minutes. TUNE TUNE The CLK control will allow you to switch between media display mode (radio station, stereo information, etc.) and clock display mode (time).
Page 33 Controls and features Premium AM/FM Stereo/Cassette/Premium Sound (CD Changer Compatible) BASS TREB FADE PUSH ON TAPE TUNE SEEK SCAN AUTO MUTE SIDE 1 . 2 COMP SHUFF Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated.
Page 34 Controls and features Volume/power control Press the control to turn the audio system on or off. PUSH ON Turn the control to raise or lower volume. PUSH ON If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 35 Controls and features • to increase volume compensation • to decrease or shut off the volume compensation AM/FM select The AM/FM select control works in radio, tape and CD modes (if equipped). AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations.
Page 36 Controls and features Tune adjust for CD changer • Press to select the previous TUNE disc in the CD changer. (Play will begin on the first track of the disc unless the CD changer is in shuffle mode.) Refer to Shuffle feature for more information. Hold the control to continue reversing through the discs.
Page 37 Controls and features Scan function The scan function works in radio, tape or CD mode (if equipped). SCAN Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the SCAN control again to stop the scan mode.
Page 38 Controls and features Autoset memory preset Autoset allows you to set strong radio stations without losing your original manually set preset stations. This feature is helpful on trips when you travel between cities with different radio stations. Starting autoset memory preset 1.
Page 39 Controls and features Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Press the BAL control. Use the SEL FADE control to adjust the sound between the speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers.
Page 40 Controls and features • In CD mode, pressing the REW control for less than three seconds results in slow rewind. Pressing the control for more than three seconds results in fast rewind. Fast forward The fast forward control works in tape and CD modes (if equipped).
Page 41 Controls and features Compression feature Compression adjust brings soft and COMP loud CD passages together for a more consistent listening level. Press the COMP control to activate and deactivate compression adjust. The effect of the feature varies with the music content. Shuffle feature The shuffle feature operates in CD SHUFF...
Page 42 Controls and features • Use the SEL control to select ON or OFF. With the feature on, use the SEEK or SCAN control to find a radio station broadcasting a traffic report (if it is broadcasting RDS data). Program type •...
Page 43 Controls and features • Use the SEL control to select TYPE, NAME or NONE. RDS clock feature Refer to Setting the clock for information. Mute mode Press the control to mute the playing media. Press the control MUTE again to return to the playing media. Setting the clock with radio data system (RDS) feature Press the RDS control until CLOCK HOUR or CLOCK MINUTE is...
Page 44 Controls and features Premium AM/FM Stereo/Single CD Radio with Premium Sound BASS TREB FADE PUSH ON TUNE AUTO SEEK SCAN MUTE COMP SHUFF Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated.
Page 45 Controls and features Turn the control to raise or lower volume. PUSH ON If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
Page 46 Controls and features AM/FM select in tape mode Press this control to stop tape play and begin radio play. AM/FM select in CD changer mode (if equipped) Press this control to stop CD play and begin radio play. Tune adjust The tune control works in radio or CD changer mode.
Page 47 Controls and features Seek function for CD or CD changer (if equipped) • Press to seek to the previous track of the current disc. If a SCAN selection has been playing for three seconds or more and you press , the CD changer will replay that selection from the beginning. •...
Page 48 Controls and features Autoset memory preset Autoset allows you to set strong radio stations without losing your original manually set preset stations. This feature is helpful on trips when you travel between cities with different radio stations. Starting autoset memory preset 1.
Page 49 Controls and features Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. FADE Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. FADE CD select To begin CD play (if CD[s] are loaded), press the CD control. The first track of the disc will begin playing.
Page 50 Controls and features Eject function Press the control to stop and eject a tape or CD. Compression feature (if equipped) Compression adjust brings soft and COMP loud CD passages together for a more consistent listening level. Press the COMP control to activate and deactivate compression adjust.
Page 51 Controls and features • Use the SEL control to select ON or OFF. With the feature on, use the SEEK or SCAN control to find a radio station broadcasting a traffic report (if it is broadcasting RDS data). Program type •...
Page 52 Controls and features • Use the SEL control to select TYPE, NAME or NONE. RDS clock feature Refer to Setting the clock for information. Mute mode Press the control to mute the playing media. Press the control MUTE again to return to the playing media. CD changer (if equipped) The CD changer is either located behind the driver’s seat or in the center console of your vehicle.
Page 53 Controls and features Press to eject the magazine. Make sure only one disc is inserted in each slot. Each disc must be inserted with the label surface upward. Depending on your system, you may insert up to six or ten CDs. COMPACT 6 COMPACT DISC MAGAZINE DIGITAL AUDIO...
Page 54 Controls and features Troubleshooting the CD changer (if equipped) The laser beam used in the compact disc player is harmful to the eyes. Do not attempt to disassemble the case. If sound skips: • You may be traveling on a rough road, playing badly scratched discs or the disc may be dirty.
Page 55 Controls and features • Do not expose tapes to direct sunlight, high humidity, extreme heat or extreme cold. Allow tapes that may have been exposed to extreme temperatures to reach a moderate temperature before playing. • Tighten very loose tapes by inserting a finger or pencil into the hole and turning the hub.
Page 56 Controls and features Audio system warranties and service Refer to the “Warranty Guide” for audio system warranty information. If service is necessary, see your dealer or a qualified technician. CLIMATE CONTROL SYSTEM Heater only system (if equipped) PANEL COOL WARM Fan speed control Controls the volume of air circulated in the vehicle.
Page 57 Controls and features • FLOOR-Allows for maximum heating. Distributes outside air through the floor ducts. • FLOOR & DEF-Distributes outside air through the floor ducts and the windshield defroster ducts. • DEF -Distributes outside air through the windshield defroster ducts. It can be used to clear ice or fog from the windshield. Operating tips •...
Page 58 Controls and features Manual heating and air conditioning system (if equipped) PANEL COOL WARM Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. COOL WARM Mode selector control Controls the direction of the airflow PANEL...
Page 59 Controls and features • MAX A/C-Uses recirculated air to cool the vehicle. MAX A/C is noisier than A/C but more economical and will cool the inside of the vehicle faster. Airflow will be from the instrument panel registers. This mode can also be used to prevent undesirable odors from entering the vehicle.
Page 60 Controls and features Operating tips • In humid weather, select DEF before driving. This will prevent your windshield from fogging. After a few minutes, select any desired position. • To prevent humidity buildup inside the vehicle, don’t drive with the climate control system in the OFF position.
Page 61 Controls and features PASSENGER AIR BAG ON/OFF SWITCH This switch must be used to deactivate the passenger air bag whenever a child seat is used in the right front or center front passenger seat position. Refer to Passenger air bag ON/OFF switch in the Seating and safety restraints chapter.
Page 62 Controls and features TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. SPEED CONTROL (IF EQUIPPED) To turn speed control on • Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph).
Page 63 Controls and features To turn speed control off • Press OFF or • Turn off the vehicle ignition. Once speed control is switched off, the previously programmed set speed will be erased. To set a speed • Press SET/SET ACC/SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater...
Page 64 Controls and features To set a higher set speed • Press and hold SET/SET ACC/ SET ACCEL. Release the control when the desired vehicle speed is reached or • Press and release SET/SET ACC/ SET ACCEL. Each press will increase the set speed by 1.6 km/h (1 mph) or •...
Page 65 Controls and features To disengage speed control • Depress the brake pedal or • Depress the clutch pedal (if equipped) Disengaging the speed control will not erase the previously programmed set speed. Pressing OFF will erase the previously programmed set speed.
Page 66 Controls and features To return to a previously set speed • Press RES/RSM/RESUME. For RES/RSM/RESUME to operate, the vehicle speed must be faster than 48 km/h (30 mph). TILT STEERING WHEEL (IF EQUIPPED) Pull the tilt steering control toward you to move the steering wheel up or down.
Page 67 Controls and features HAZARD FLASHER For information on the hazard flasher control, refer to Hazard flasher in the Roadside emergencies chapter. WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers.
Page 68 Controls and features HIGH BEAMS Push forward to activate. FLASH TO PASS Pull toward you to activate and release to deactivate. OVERDRIVE CONTROL Activating overdrive (Overdrive) is the normal drive position for the best fuel economy. The overdrive function allows automatic upshifts to second, third and fourth gear.
Page 69 Controls and features The transmission will operate in gears one through three. To return OVERDRIVE to normal overdrive mode, press the Transmission Control Switch again. The TCIL (the word OFF) will no longer be illuminated. When you shut off and re-start your vehicle, the transmission will automatically return to normal (Overdrive) mode.
Page 70 Controls and features • Press the bottom portion of the rocker switch to open. AUTO One touch down • Press AUTO completely down and release quickly. The driver’s window will open fully. Depress again to stop window operation. AUTO Accessory delay (if equipped) With accessory delay, the window switches may be used for up to ten minutes after the ignition switch is turned to the OFF position or until any door is opened.
Page 71 Controls and features POWER SIDE VIEW MIRRORS (IF EQUIPPED) The ignition must be in ACC or ON position to adjust the power side view mirrors. To adjust your mirrors: 1. Select L to adjust the left mirror or R to adjust the right mirror. MIRRORS 2.
Page 72 Controls and features Fold-away mirrors Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash. TAILGATE LOCK (IF EQUIPPED) Your vehicle is equipped with a tailgate lock designed to prevent theft of the tailgate. •...
Page 73 Controls and features TAILGATE REMOVAL Your tailgate is removable to allow more room for loading. 1. Lower the tailgate. 2. Use a screwdriver to pry the spring clip (on each connector) past the head of the support screw. Disconnect cable. 3.
Page 74 Controls and features 3. Pull one side of the cover outward and upward away from the side rail working from the rear to the front. 4. Starting from the opposite side of the vehicle, pull cover away from the side rail and roll the cover from rear to front. 5.
Page 75 Controls and features Flareside only: • Remove two cross bars from pickup box by pushing towards either side to release tension. • Lower tailgate, depress the levers on each side of the rear rail and remove rear rail from pickup box.
Page 76 Controls and features Styleside only: • Remove three cross bars from pickup box by pushing towards either side to release tension. Stow the cross bars in the notches behind the rolled cover in the pickup box. • Lower tailgate, depress the levers on each side of the rear rail and push rear rail towards the front of the pickup box securing it behind the cross bars and cover.
Page 77 Controls and features your vehicle. Each time you start your vehicle, the SecuriLock key is read by the SecuriLock passive anti-theft system. If the SecuriLock key identification code matches the code stored in the SecuriLock passive anti-theft system, the vehicle’s engine is allowed to start. If the SecuriLock key identification code does not match the code stored in the system or if a SecuriLock...
Page 78 Controls and features keys). Your dealership can program your new SecuriLock key(s) to your vehicle or you can do it yourself using the following simple procedure. To program a new SecuriLock key yourself, you will need two previously programmed SecuriLock keys (keys that already operate your vehicle’s engine).
Page 79 Controls and features If the programming procedure was not successful, the new SecuriLock key(s) will not operate the vehicle’s engine. The theft indicator will flash on and off. Wait at least one minute and then repeat the procedure from step 1. If failure repeats, bring your vehicle to your dealership to have the spare SecuriLock key(s) programmed.
Page 80 Controls and features This process will also arm your anti-theft system (if equipped). For more information on arming the anti-theft system, refer to Anti-theft system in this chapter. Sounding a panic alarm Press this control to activate the alarm. To deactivate the alarm, press the control again or turn the ignition to ACC or RUN.
Page 81 Controls and features Deactivating/activating the autolock feature Before following the procedure, make sure that the ignition is OFF and all vehicle doors and the liftgate window are closed. You must complete steps 1-7 within 30 seconds or the procedure will have to be repeated.
Page 82 Controls and features To replace the battery: 1. Twist a thin coin between the two halves of the transmitter near the key ring. DO NOT TAKE THE FRONT PART OF THE TRANSMITTER APART. 2. Place the positive (+) side of new battery in the same orientation.
Page 83 Controls and features Illuminated entry The illuminated entry system will turn on the interior lights when the remote transmitter unlock control is pressed. The illuminated entry system will turn off the interior lights if the ignition switch is turned to the RUN position, or if the remote transmitter lock control is pressed, or after 25 seconds of illumination.
Page 84: Seating And Safety Restraints
Seating and safety restraints SEATING Adjusting the front manual seat Never adjust the driver’s seat or seatback when the vehicle is moving. Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop. Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 85 Seating and safety restraints Full bench seat (if equipped) • Lift the release bar to move the seat forward or backward. Ensure that the seat is relatched into place. • Pull up on the release lever to quickly fold the seatback forward. 60/40 split bench seat (if equipped) •...
Page 86 Seating and safety restraints Captain’s chair (if equipped) • Lift the release bar to move the seat forward or rearward. Make sure that the seat is relatched into place. • Pull the seatback handle up to recline the seat. • Push the release lever down to quickly fold the seatback forward.
Page 87 Seating and safety restraints Press to raise or lower the rear portion of the seat cushion. Press the control to move the seat forward, backward, up or down. Using the manual lumbar support Turn the lumbar support control toward the front of vehicle to increase firmness.
Page 88 Seating and safety restraints 60/40 Split Rear Seat (if equipped) When folded down, the rear seats provide a “load floor” for additional storage space. To fold down the rear seats: • Pull the straps to lower the seat cushions. • Store the center safety belt in the opening on the seat back.
Page 89 Seating and safety restraints SAFETY RESTRAINTS Safety restraints precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips. To prevent the risk of injury, make sure children sit where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving.
Page 90 Seating and safety restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
Page 91 Seating and safety restraints Automatic locking mode In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. When to use the automatic locking mode •...
Page 92 Seating and safety restraints • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode.
Page 93 Seating and safety restraints Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 94 (slide bar)(if equipped), shoulder belt height adjusters (if equipped), child safety seat tether bracket assemblies (if equipped), and attaching hardware, should be inspected after a collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced.
Page 95 Seating and safety restraints AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 50 60 FUEL 0 0 0 0 0 0 THEFT DOOR AJAR CHECK SUSP BRAKE km/h RPMx1000 P R N CHECK ENGINE PULL PANEL ACCEL Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the safety belt to help protect the driver and...
Page 96 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer. Children and air bags For additional important safety information, read all information on safety restraints in this guide.
Page 97 Seating and safety restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 98 Seating and safety restraints • and the electrical wiring which connects the components. The RCM (restraints control module) monitors its own internal circuits and the supplemental air bag electrical system warning (including the passenger air bag deactivation switch, the impact sensors, the system wiring, the air bag system readiness light, the air bag back up power and the air bag ignitors).
Page 99 PASSENGER AIRBAG If the light fails to illuminate when the passenger air bag switch is in the OFF position and the ignition switch is in ON, have the passenger air bag switch serviced at your Ford or Lincoln-Mercury dealer immediately.
Page 100 If the light is illuminated when the passenger air bag switch is in the ON position and the ignition switch is in ON, have the passenger air bag switch serviced at your Ford or Lincoln-Mercury dealer immediately. The passenger side air bag should always be ON (the air bag OFF light...
Page 101 Seating and safety restraints The safety belts for the driver and right front passenger seating positions have been specifically designed to function together with the air bags in certain types of crashes. When you turn OFF your air bag, you not only lose the protection of the air bag, you also may reduce the effectiveness of your safety belt system, which was designed to work with the air bag.
Page 102 Seating and safety restraints • the infant has a medical condition which, according to the infant’s physician, makes it necessary for the infant to ride in the front so that the driver can constantly monitor the child’s condition. 2. Child age 1 to 12. A child age 1 to 12 must ride in the front seat because: •...
Page 103 Seating and safety restraints • the child has a medical condition that, according to the child’s physician, makes it necessary for the child to ride in the front seat so that the driver can monitor the child’s condition. 3. Medical condition: A passenger has a medical condition that, according to his or her physician: •...
Page 104 To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all Federal motor vehicle safety standards. Belt-positioning booster seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child.
Page 105 (passenger side front and outboard rear seating positions)(if equipped). Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage. For more information on top tether straps, refer to Attaching safety seats with tether straps.
Page 106 Seating and safety restraints Installing child safety seats in combination lap and shoulder belt seating positions 1. Position the child safety seat in a seat with a combination lap and shoulder belt. An air bag can kill or injure a child in a child seat. If you must use a forward-facing child seat in the front seat, move seat all the way back.
Page 107 Seating and safety restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 108 Seating and safety restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 109 Carefully follow the instructions provided with the kit. If you have a SuperCab, Ford recommends you attach tether safety seats in the rear seating position (if possible) with the tether strap attached to the tether anchorage bracket as shown in the instructions provided with the tether anchor kit.
Page 110 Starting PREPARING TO START YOUR VEHICLE Engine starting is controlled by the ignition system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
Page 111 Starting 2. Make sure the headlamps and vehicle accessories are off. If starting a vehicle with an automatic transmission: • Make sure the parking brake is set. • Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: •...
Page 112: Starting The Engine
Starting 3. Turn the key to 4 (ON) without turning the key to 5 (START). THEFT DOOR AJAR RANGE FUEL FUEL SELECT SERVICE km/h RESET RESET ENGINE SUSP SOON P RN BRAKE FUEL DOOR Make sure the corresponding lights illuminate briefly. If a light fails to illuminate, have the vehicle serviced.
Page 113 Starting 3. If the temperature is below -12°C (10°F) and the engine does not start in fifteen seconds on the first try, turn the key OFF and wait ten seconds and try again. If the engine does not start in two attempts, depress the accelerator and start the engine while holding the accelerator down to the floor.
Page 114 Starting Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm. Important ventilating information If the engine is idling while the vehicle is stopped in an open area for long periods of time, open the windows at least 2.5 cm (one inch).
Page 115 Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
Page 116: Driving
Driving ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned on and the engine is off. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced.
Page 117 Driving Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and BRAKE remains illuminated (when the ignition is turned ON) until the parking brake is released.
Page 118 Driving Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. TRACTION-LOK AXLE (IF EQUIPPED) This axle provides added traction on slippery surfaces, particularly when one wheel is on a poor traction surface.
Page 119 Driving If the steering wanders or pulls, the condition could be caused by any of the following: • underinflated tire(s) on any wheel(s) • high crown in center of road • high crosswinds • wheels out of alignment • loose or worn components in steering linkage AIR SUSPENSION SYSTEM (IF EQUIPPED) The air suspension system is designed to improve ride, handling and general vehicle performance for static, on and off-road driving conditions.
Page 120 Driving again. If the warning light reappears, turn the air suspension switch off and have the vehicle serviced by a dealer or qualified service technician. If the vehicle is loaded beyond the recommended maximum payload, the CK SUSP light may illuminate. To correct this condition, remove or redistribute the payload according to the recommended requirements and follow the procedure outlined above.
Page 121 Driving If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your dealer or a qualified service technician. Driving with a 4–speed automatic transmission Understanding gearshift positions Pull the gearshift lever towards you and downward to move the automatic gearshift.
Page 122 Driving N (Neutral) With the gearshift in N (Neutral), the vehicle can be started and is free to roll. Hold the brake pedal down while in this gear. (Overdrive) The normal driving position for the best fuel economy. Transmission operates in gears one through four. (Overdrive) can be deactivated by pressing the Transmission OVERDRIVE...
Page 123 Driving 2 (Second) Use 2 (Second) to start-up on slippery roads or to provide additional engine braking on downgrades. 1 (First) Use 1 (Low) to provide maximum engine braking on steep downgrades. Upshifts can be made by shifting to 2 (Second) or to (Overdrive).
Page 124 Driving 4. Turn ignition to position 5 (START) to start the engine, let the engine idle for a few seconds, then shift into gear. 5. Release the brake pedal. 6. Release clutch slowly while pressing down slowly on the accelerator pedal. •...
Page 125 Driving Recommended shift speeds Upshift and downshift according to the following charts for your specific engine/drivetrain combination: Upshifts when accelerating (recommended for best fuel economy) Shift from: Transfer case position (if equipped) 2H or 4H 1 - 2 14 km/h (9 mph) 5 km/h (3 mph) 2 - 3 32 km/h (20 mph)
Page 126 Driving Parking your vehicle 1. Disengage the clutch, apply brake and shift into N (Neutral). 2. Set parking brake. 3. Shift into 1 (First). 4. Turn the ignition key to position 3 (OFF).
Page 127 Driving Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully. Reverse Make sure that your vehicle is at a complete stop before you shift into R (Reverse).
Page 128 Driving FOUR-WHEEL DRIVE (4WD) OPERATION (IF EQUIPPED) When Four–wheel drive (4WD) is engaged, power is supplied to all four wheels through a transfer case. 4WD power can be selected when additional driving power is desired. If equipped with the Electronic Shift 4WD System, and the instrument panel control is moved to 4WD Low while the vehicle is moving, the system will not engage and no damage will occur to the 4WD system.
Page 129 Driving N (Neutral) – No power to either axle. 4L (4WD Low) – Power to front and rear axles at reduced speed. Shifting from 2H (2WD high) to 4H (4WD high) Move the transfer case lever to 4H (4WD High) at a stop or any forward speed up to 88 km/h (55 mph).
Page 130 Driving Using the N (Neutral) position The transfer case neutral position overrides the transmission and puts the vehicle in neutral regardless of transmission gearshift lever position. The vehicle can move forward or backwards. This position should only be used when towing the vehicle. Refer to Wrecker towing in the Roadside emergencies chapter.
Page 131 Driving Shifting from 4H (4WD high) to 2H (2WD high) Move the 4WD control to 2H at any forward speed. Shifting between 4H (4WD high) and 4L (4WD low) 1. Bring the vehicle to a stop. 2. Depress the brake. 3.
Page 132 Driving You should either know the terrain or examine maps of the area before driving. Map out your route before driving in the area. For more information on driving off-road, read the “Four Wheeling” supplement in your owner’s portfolio. If your vehicle gets stuck If the vehicle is stuck it may be rocked out by shifting from forward and reverse gears, stopping between shifts, in a steady pattern.
Page 133 Driving Replace rear axle lubricant any time the axle has been submerged in water. The rear axle does not normally require a lubricant change for the life of the vehicle. Rear axle lubricant quantities are not to be checked or changed unless a leak is suspected or repair is required.
Page 134 Driving VEHICLE LOADING Before loading a vehicle, familiarize yourself with the following terms: • Base Curb Weight : Weight of the vehicle including any standard equipment, fluids, lubricants, etc. It does not include passengers or aftermarket equipment. • Payload : Combined maximum allowable weight of cargo, passengers and optional equipment.
Page 135 Driving Do not exceed the GVWR or the GAWR specified on the Safety Compliance Certification Label. Do not use replacement tires with lower load carrying capacities than the originals because they may lower the vehicle’s GVWR and GAWR limitations. Replacement tires with a higher limit than the originals do not increase the GVWR and GAWR limitations.
Page 136 Driving DRIVING THROUGH WATER Do not drive quickly through standing water, especially if the depth is unknown. Traction or brake capability may be limited and if the ignition system gets wet, your engine may stall. Water may also enter your engine’s air intake and severely damage your engine.
Page 137 Driving Do not exceed the GVWR or the GAWR specified on the Safety Compliance Certification Label. Towing trailers beyond the maximum recommended gross trailer weight could result in engine damage, transmission/axle damage, structural damage, loss of control, and personal injury. Trailer towing tables F-150 4x2 with automatic transmission Engine...
Page 138 Driving F-150 4x2 manual transmission Engine Rear axle Maximum GCWR- Maximum trailer ratio kg (lbs.) weight-kg (lbs.) Regular Cab F-150 4.2L 3.08 2 944 (6 500) 1 132 (2 500) 4.2L 3.55 3 533 (7 800) 1 630 (3 600) 4.6L 3.08 2 944 (6 500)
Page 139 Driving F-150 4x4 manual transmission Trailer towing table (F-150 4x4 manual transmission) Engine Rear axle Maximum GCWR- Maximum trailer ratio kg (lbs.) weight-kg (lbs.) Regular Cab F-150 4.2L 3.31 2 944 (6 500) 861 (1 900) 4.2L 3.55 3 533 (7 800) 1 451 (3 200) 4.6L 3.08...
Page 140 Driving F-250 4x2 manual transmission Engine Rear axle Maximum GCWR- Maximum trailer ratio kg (lbs.) weight-kg (lbs.) Regular Cab F-250 4.6L 3.31 3 261 (7 200) 1 179 (2 600) 4.6L 3.73 3 533 (7 800) 1 451 (3 200) SuperCab F-250 4.6L 3.31...
Page 141 Driving Trailer frontal area considerations: • Not to exceed towing vehicle front area without Class III trailer towing package • Not to exceed 5.52 square meters (60 square feet) with Class III trailer towing package Preparing to tow Use the proper equipment for towing a trailer, and make sure it is properly attached to your vehicle.
Page 142 Driving Safety chains Always connect the trailer’s safety chains to the vehicle. To connect the trailer’s safety chains, cross the chains under the trailer tongue and allow slack for turning corners. If you use a rental trailer, follow the instructions that the rental agency gives to you.
Page 143 Driving When towing a trailer: • Use a lower gear when towing up or down steep hills. This will eliminate excessive downshifting and upshifting for optimum fuel economy and transmission cooling. • Anticipate stops and brake gradually. Exceeding the GCWR rating may cause internal transmission damage and void your warranty coverage.
Page 144 2. Shift the transfer case to N (Neutral). 3. Lockout the center disconnect by capping off one of the front axle vacuum motor lines. See your Ford dealer for assistance. 4. Vehicle speed should not exceed 88 km/h (55 mph) and there are no...
Page 145 88 km/h (55 mph) and there are no mileage restrictions. See your dealer for help with disconnecting the driveshaft. SNOWPLOWING Ford recommends the following specifications for low speed, personal use snow removal: • F-150/F–250 4WD Regular Cab long wheelbase • 4.6L or 5.4L engine •...
Page 146 Driving • The Front Axle Accessory Reserve Capacity and the Total Accessory Reserve Capacity listed on the bottom right of the Safety Compliance Certification Label will determine whether or not the addition of a snowplow will overload your vehicle. • The weight of the snowplow and supporting components distributed to the front axle must not exceed the front accessory reserve capacity.
Page 147 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer. Engine temperature while plowing...
Page 148 Driving If you are driving more than 24 km (15 miles) at temperatures above freezing, angle the plow blade either full left or full right to provide maximum airflow to the radiator. If you are driving less than 24 km (15 miles) at speeds up to 64 km/h (40 mph) in cold weather, you will not need to worry about blade position to provide maximum airflow.
Page 149: Roadside Emergencies
Roadside emergencies HAZARD FLASHER Use only in an emergency to warn traffic of vehicle breakdown, approaching danger, etc. The hazard flashers can be operated when the ignition is off. • The hazard lights control is located on top of the steering column.
Page 150: Fuses And Relays
Roadside emergencies The fuel pump shut-off switch is located in the passenger’s foot well, behind the kick panel. FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse.
Page 151: Passenger Compartment Fuse Panel
Roadside emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse Link Maxi Rating Fuses Fuses Fuses Cartridge Fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 152 Roadside emergencies The fuses are coded as follows. Fuse/Relay Fuse Amp Description Location Rating Audio Powertrain Control Module (PCM), Cluster Cigar Lighter, OBD-II Scan Tool Connector Autolamp Module, Remote Entry Module, Mirrors AC Clutch Relay, Speed Control Module, Reverse Lamp, Climate Mode Switch, Daytime Running Lamp Relay Cluster, Brake Shift Interlock Solenoid, Rear Air Suspension Module, GEM Module...
Page 153 Roadside emergencies Fuse/Relay Fuse Amp Description Location Rating — Not Used Front Washer Pump Relay, Wiper Run/Park Relay, Wiper Hi/LO Relay, Windshield Wiper Motor — Not Used Stop Lamp Switch (Lamps), Turn/Hazard Flasher, Speed Control Module Battery Saver Relay, Interior Lamp Relay, Accessory Delay Relay (Power Windows) Stop Lamp Switch, (Speed Control, Brake Shift Interlock, ABS, PCM Module Inputs),...
Page 154: Power Distribution Box
Roadside emergencies Fuse/Relay Fuse Amp Description Location Rating Passive Anti Theft Transceiver, Cluster, Ignition Coils, Powertrain Control Module Relay — Not Used Relay 1 — Interior Lamp Relay Relay 2 — Battery Saver Relay Relay 4 — One Touch Down Window Relay Relay 5 —...
Page 155 Roadside emergencies The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Description Location Rating 25A * Power Point 30A* Powertrain Control Module 30A* Headlamps/Autolamps 15A* Air Suspension 20A* Trailer Tow Backup/Park Lamps 15A* Parklamps/Autolamps 20A* Horn 15A* Power Door Locks 15A* Daytime Running Lamps (DRL), Fog Lamps 20A*...
Page 156 Roadside emergencies Fuse/Relay Fuse Amp Description Location Rating 50A* Junction Block Battery Feed 30A** 4x4 Shift Motor & Clutch 40A** Climate Control Front Blower — Not Used — Not Used 30A** Trailer Tow Electric Brake 50A** Air Suspension Compressor 30A** Power Windows 50A** Ignition Switch Battery Feed (Start and...
Page 157 Roadside emergencies Fuse/Relay Fuse Amp Description Location Rating — Not Used — Powertrain Control Module Diode — A/C Clutch Diode — Not Used — Not Used — Not Used *Mini fuses **Maxi fuses CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed.
Page 158 Roadside emergencies Removing the spare tire 1. Insert the jack handle into the rear bumper opening. The handle will stop moving and forward resistance to turning will be felt when properly engaged. 2. Turn the handle counterclockwise until tire is lowered to the ground, the tire can be slid rearward and the cable is slightly slack.
Page 159 Roadside emergencies Refer to the instruction sheet (located under the passenger front seat with the jack) for detailed tire change instructions. 1. Park on a level surface, activate hazard flashers and set the parking brake. 2. Place gearshift lever in P (Park) (automatic transmission) or in the reverse gear (manual transmission) and turn engine OFF.
Page 160 Roadside emergencies 7. Turn OFF the air suspension switch (if equipped). 8. Position the jack according to the following guides and turn the jack handle clockwise until the wheel is completely off the ground. When one of the rear wheels is off the ground, the transmission alone will not prevent the vehicle from moving or slipping off the jack, even if the...
Page 161 Roadside emergencies • Front (4x4) • Rear To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire.
Page 162 Roadside emergencies 12. Remove the jack and fully tighten the lug nuts in the order shown. 13. Stow the flat tire. Refer to Stowing the spare . 14. Stow the jack and lug wrench. Make sure the jack is fastened so it does not rattle when you drive.
Page 163 Roadside emergencies 5. Turn the heater fan on in both vehicles to protect any electrical surges. Turn all other accessories off. Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery.
Page 164 Roadside emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor.
Page 165 Roadside emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for a further three minutes before disconnecting the jumper cables.
Page 166 Roadside emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 167 It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 168: Maintenance And Care
Maintenance and care SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a Scheduled Maintenance Guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide necessary parts and service.
Page 169 Maintenance and care 3. Turn off the engine and remove the key. 4. Block the wheels to prevent the vehicle from moving unexpectedly. Working with the engine on • Automatic transmission: 1. Set the parking brake and ensure the gearshift is securely latched in P (Park).
Page 170 Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.2L V6 engine 1. Battery 2. Engine oil filler cap 3. Engine oil dipstick 4. Clutch fluid reservoir (manual transmission) 5. Brake fluid reservoir 6. Engine coolant reservoir 7. Air filter assembly 8.
Page 171 Maintenance and care 4.6L V8/5.4L V8 engines 10 11 1. Engine oil dipstick 2. Clutch fluid reservoir (manual transmission) 3. Power steering fluid reservoir 4. Brake fluid reservoir 5. Power distribution box 6. Air filter assembly 7. Engine coolant reservoir 8.
Page 172 Maintenance and care ENGINE OIL Checking the engine oil Refer to the Scheduled Maintenance Guide for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
Page 173 Maintenance and care • If the oil level is below the MIN mark, add enough oil to raise the level within the MIN-MAX range. • Oil levels above the MAX mark may cause engine damage. Some oil must be removed from the engine by a service technician. 7.
Page 174 Change your engine oil and filter according to the appropriate schedule listed in the Scheduled Maintenance Guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, startup engine noises or knock may be experienced.
Page 175 During normal operation, the fluid level in the clutch reservoir should remain constant. If the fluid level drops, maintain the fluid level at the step in the reservoir. Use only a DOT 3 brake fluid designed to meet Ford specifications. Refer to Capacities and specifications.
Page 176 Maintenance and care 1. Clean the reservoir cap before removal to prevent dirt and water from entering the reservoir. 2. Remove cap and rubber diaphragm from reservoir. 3. Add fluid until the level reaches the step in the reservoir. 4. Reinstall rubber diaphragm and cap onto reservoir.
Page 177 Maintenance and care ENGINE COOLANT Check the level of the engine coolant in the reservoir. Refer to the Scheduled Maintenance Guide for service interval schedules. Be sure to read and understand Precautions when servicing your vehicle in this chapter. COLD FILL RANGE If the engine coolant has not been checked at the recommended interval, the engine coolant reservoir may become empty.
Page 178 Change your engine coolant according to the appropriate schedule listed in the Scheduled Maintenance Guide. Use Ford Premium Engine Coolant E2FZ-19549–AA (in Oregon, F5FZ-19549–CC, in Canada, Motorcraft CXC-10) or an equivalent premium engine coolant that meets Ford specification ESE-M97B44–A.
Page 179 Maintenance and care Not all coolant recycling processes produce coolant which meets Ford specification ESE-M97B44–A, and use of such coolant may harm engine and cooling system components. Always dispose of used automotive fluids in a responsible manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids.
Page 180 Maintenance and care If the engine reaches a preset over-temperature condition, the engine will automatically switch to alternating cylinder operation. Each disabled cylinder acts as an air pump and cools the engine. When this occurs the vehicle will still operate, however: •...
Page 181 Maintenance and care CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the Scheduled Maintenance Guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C).
Page 182 Maintenance and care TRANSMISSION FLUID Checking automatic transmission fluid Refer to your Scheduled Maintenance Guide for scheduled intervals for fluid checks and changes. Your transmission does not consume fluid. However, the fluid level should be checked if the transmission is not working properly, i.e., if the transmission slips or shifts slowly or if you notice some sign of fluid leakage.
Page 183 Maintenance and care Correct fluid level The transmission fluid should be checked at normal operating temperature 66°C-77°C (150°F-170°F) on a level surface. The normal operating temperature can be reached after approximately 30 km (20 miles) of driving. You can check the fluid without driving if the ambient temperature is above 10°C (50°F).
Page 184 Maintenance and care Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used. The type of fluid used is normally indicated on the dipstick and/or dipstick handle and also in the Lubricant specifications section in the Capacities and specifications chapter.
Page 185 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to the Capacities and specifications chapter. Checking and adding transfer case fluid 1. Clean the filler plug.
Page 186 Use only fluid that meets Ford specifications. Refer to the Capacities and specifications chapter. DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication.
Page 187 Maintenance and care cells with distilled water. If the battery needs water often, have the charging system checked. If your battery has a cover/shield, make sure it is reinstalled after the battery has been cleaned or replaced. For longer, trouble-free operation, keep the top of the battery clean and dry.
Page 188 Maintenance and care 2. Put the gearshift in P (Park) (automatic transmission) or the neutral position (manual transmission), turn off all accessories and start the engine. 3. Let the engine idle for at least one minute. 4. The relearning process will automatically complete as you drive the vehicle.
Page 189 Maintenance and care Changing the air filter element 1. Loosen the clamp that secures the air filter element in place. 2. Carefully separate the two halves of the air filter housing. 3. Remove the air filter element from the open end of the air filter housing.
Page 190 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it.
Page 191 Maintenance and care Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 192 Maintenance and care SERVICING YOUR TIRES Checking the tire pressure • Use an accurate tire pressure gauge. • Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 5 km (3 miles).
Page 193 If you do not follow these precautions, your vehicle may not drive properly and safely. Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design (e.g., “All Terrain”, etc.), as originally offered by Ford.
Page 194 Maintenance and care Do not replace your tires with “high performance” tires or larger size tires. Failure to follow these precautions may adversely affect the handling of the vehicle and make it easier for the driver to lose control and roll over. Tires that are larger or smaller than your vehicle’s original tires may also affect the accuracy of your speedometer.
Page 195 Maintenance and care WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. If you do not use the proper fuel cap, the pressure in the fuel tank can damage the fuel system or cause it to work improperly in a collision.
Page 196 Maintenance and care • Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention. Failure to seek proper medical attention could lead to permanent injury.
Page 197 It should not be necessary to add any aftermarket products to your fuel tank if you continue to use a high-quality fuel. Cleaner air Ford approves the use of gasolines to improve air quality, including reformulated gasolines that contain oxygenates up to 10% ethanol or 15% MTBE.
Page 198 If you must replace the fuel filler cap, replace it with a genuine Ford or Motorcraft part. The customer warranty may be void for any damage to the fuel tank or fuel system if a genuine Ford or Motorcraft fuel filler cap is not used.
Page 199 Maintenance and care For fuel filter replacement, see your dealer or a qualified service technician. Refer to the Scheduled Maintenance Guide for the appropriate intervals for changing the fuel filter. If you replace the fuel filter, replace it with an authorized Motorcraft part.
Page 200 Maintenance and care • Use the same side of the same pump and have the vehicle facing the same direction each time you fill up. • Have the vehicle loading and distribution the same every time. Your results will be most accurate if your filling method is consistent. Calculating fuel economy 1.
Page 201 Maintenance and care • Drive at reasonable speeds (traveling at 105 km /h [65 mph] uses 15% more fuel than traveling at 88 km/h [55 mph]). • Revving the engine before turning it off may reduce fuel economy. • Use of the air conditioner or defroster may reduce fuel economy. •...
Page 202 Guide are essential to the life and performance of your vehicle and to its emissions system. If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine...
Page 203 Maintenance and care Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Illumination of the charging system warning light, Check Engine indicator light or the temperature warning light, fluid leaks, strange odors, smoke or loss of oil pressure, could indicate that the emission control system is not working properly.
Page 204 Maintenance and care EXTERIOR BULBS Replacing exterior bulbs Check the operation of the following lamps frequently: • Headlamps • Foglamps (if equipped) • High-mount brakelamp • Brakelamps • Turn signals • License plate lamp • Tail lamps • Back-up lamps Do not remove lamp bulbs unless they can be replaced immediately with new ones.
Page 205 Maintenance and care 5. Release clip and disconnect the electrical connector from the bulb. 6. Remove bulb retainer ring by turning it counterclockwise about ⁄ turn, then slide the ring off the plastic base. 7. Without turning, carefully pull bulb assembly out of headlamp assembly and replace.
Page 206 Maintenance and care Replacing front parking lamp/turn signal bulbs 1. Remove screw from the lamp assembly. 2. Disengage lamp assembly (it has a snap fit). 3. Remove bulb socket from the parking lamp assembly by turning it counterclockwise about ⁄ turn.
Page 207 Maintenance and care Replacing tail lamp/backup lamp bulbs The tail lamp/backup lamp bulbs are located in the same portion of the tail lamp assembly, one just below the other. Follow the same steps to replace either bulb: 1. Open the liftgate to expose the lamp assemblies.
Page 208 Maintenance and care Replacing foglamp bulbs 1. Remove the bulb socket from the foglamp by turning counterclockwise. 2. Disconnect the electrical connector from the foglamp bulb. 3. Connect the electrical connector to the new foglamp bulb. 4. Install the bulb socket in the foglamp turning clockwise. Replacing license plate lamp bulbs The license plate bulbs are located behind the rear bumper.
Page 209 • The headlamp beams are pointed substantially away from a slightly down and to the right position. CLEANING AND CARING FOR YOUR VEHICLE Refer to the “Customer Assistance Guide” for a list of Ford-approved cleaners, polishes and waxes. Washing your vehicle Wash your vehicle regularly with cold or lukewarm water.
Page 210 Repairing paint chips Minor scratches or paint damage from road debris may be repaired with touch-up paint, repair foil or aerosol paint spray from the Ford accessory line. Observe the application instructions on the products. Remove particles such as bird droppings, tree sap, insect remains, tar spots, road salt and industrial fallout immediately.
Page 211 Maintenance and care Cleaning the engine Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high pressure fluid could penetrate the sealed parts and cause damage.
Page 212 Maintenance and care Cleaning the wiper blades and windshield If the wiper blades do not wipe properly, clean the wiper blade rubber element with undiluted windshield washer solution or a mild detergent. To avoid damaging the blades, do not use fuel, kerosene, paint thinner or other solvents.
Page 213 For tougher soiling concerns, Ford recommends using the leather cleaning kit F8AJ-19G253–AA, which is available from your Ford Dealer. This mild cleaner and special pad, cleans the leather and maintains its natural beauty. Follow the instructions on the cleaner label.
Page 214: Capacities And Specifications
Capacities and specifications MOTORCRAFT PART NUMBERS Component 4.2L V6 engine 4.6L V8 engine 5.4L V8 engine Air filter FA-1634 FA-1634 FA-1634 element Fuel filter FG-986B FG-986B FG-986B Oil filter FL-400-S FL-820-S FL-820-S PCV valve EV-152 EV-233 EV-233 Battery BXT-59 BXT-59 BXT-59 (standard) Battery...
Page 215 Capacities and specifications REFILL CAPACITIES Ford Part Fluid Application Capacity Name High Fill to line on Performance reservoir DOT 3 Brake fluid Motor Vehicle Brake Fluid 4.2L V6 engine with 19.0L (20.1 quarts) 1 row radiator 4.2L V6 engine with 20.4L (21.6 quarts)
Page 216: Capacities And Specifications
Washer Concentrate Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in the Maintenance and Care chapter. Fill to bottom of filler hole.
Page 217 Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546-A, Ford specification EST-M2C118–A, for complete fill of 8.8 inch and 9.75 inch Traction-Lok axles.
Page 218 Capacities and specifications Ford part Ford part Ford Item name or number specification equivalent Engine coolant Ford Premium E2FZ-19549-AA ESE-M97B44-A Engine Coolant (in Oregon, F5FZ-19549-CC, in Canada, Motorcraft CXC-10) Motorcraft 5W30 XO-5W30-QSP WSS-M2C153-G Super Premium and API Engine oil Motor Oil...
Page 219 Capacities and specifications Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546–A, Ford specification EST-M2C118–A for complete refill of 8.8 inch and 9.75 inch Traction-Lok axles. Add 236 ml (8 oz.) of additive friction modifier C8AZ-19B546–A, Ford specification EST-M2C118–A for complete refill of 10.25 and 10.5 inch Traction-Lok axles.
Page 220 Capacities and specifications VEHICLE DIMENSIONS Styleside Body Style Dimension Regular Regular Cab Super Cab Super Cab Cab 4x2 5 205 mm 5 250 mm 5 607 mm 5 722 mm (204.9 in) (206.7 in) (220.7 in) (225.3 in) (1) Overall (SWB) (SWB) (SWB)
Page 221 Capacities and specifications Flareside Body Style Dimension Regular Regular Super Cab Super Cab Cab 4x2 Cab 4x4 (1) Overall 5 212 mm 5 250 mm 5 684 mm 5 722 mm length (205.2 in) (206.7 in) (223.8 in) (225.3 in) (2) Overall 2 014 mm 2 028 mm...
Page 222 Capacities and specifications...
Page 223: Vehicle Identification Number
Capacities and specifications IDENTIFYING YOUR VEHICLE Safety compliance label The National Highway Traffic Safety MFD. BY FORD MOTOR CO. IN U.S.A. Administration Regulations require DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG that a Safety Compliance FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL...
Page 224: Reporting Safety Defects
However, NHTSA cannot become involved in individual problems between you, your dealer or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (202–366–0123 in the Washington D.C.
Page 225: Index
Index Accessory delay ......70 wheels ........210 Air bag supplemental restraint wiper blades ......212 system ..........95 Clutch and child safety seats ....96 fluid ..........175 description ........95 operation while driving ..123 disposal ........98 recommended indicator light ......98 shift speeds ......125,126 passenger air bag .....96 Controls passenger deactivation power seat .........86...
Page 226 Index detergent in fuel .....197 headlamps .........16 filling your vehicle headlamps, flash to pass ..68 with fuel ......195,198 instrument panel, dimming ..17 quality ........197 interior lamps ......69 running out of fuel ....197 replacing bulbs ..204,206,207,208 safety information relating to Lane change indicator automotive fuels .....195 (see Turn signal) ......62 Fuses ........150,151...
Page 227 Index illuminated entry ......83 changing ......157,158 locking/unlocking doors ...79 checking the pressure ....192 replacement/additional replacing ........193 transmitters .......82 rotating ........192 replacing the batteries .....81 snow tires and chains ....194 Safety belts (see Safety tire grades .......191 restraints) ........11 treadwear ........191 Safety Compliance Towing Certification Label ....223...
Page 232: Filling Station Information
Refer to Refill capacities in the Capacities and specifications chapter. Use Ford Premium Cooling System Fluid (green in color). DO NOT USE Ford Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in the Maintenance and Care chapter.

Ford 1999 F150 Owner's Manual

Quick Links

Before driving

Related Manuals for Ford 1999 F150

Summary of Contents for Ford 1999 F150

Table of Contents
