Summary of Contents for AG Neovo SX-Series
-
Page 2: Table Of Contents
Table of Contents Precautions ....................2 Warning on installation ................. 2 Warning on power connection.............. 2 Warning on tilt ..................3 Warning on Maintenance ..............3 Warning on transportation ..............3 Getting Started ....................4 Package Contents ................4 Identify the Parts and Controls............. 5 How to Use the On-Screen Display Menu ........... -
Page 3: Precautions
Precautions Warning on installation Do not cover or block the ventilation holes in the case. Do not install the monitor near heat sources such as radiators or air ducts, or in a place subject to direct sunlight, excessive dust, mechanical vibration or shock. Optional Video adaptor installation Turn off the power switch and unplug the monitor before installation to avoid electric shock or damage. -
Page 4: Warning On Tilt
Warning on tilt Use the monitor’s tilt capability to adjust its vertical orientation to an appropriate position. Grasp the top corners of the monitor with both hands and tilt to the desired angle. SX-19 / SX-17 SX-15 Warning on Maintenance Clean the cabinet, glass, and controls with a soft cloth lightly moistened with a mild detergent solution. -
Page 5: Getting Started
Getting Started Package Contents Before using this monitor, check the following items are included in your carton box: Monitor (*1) Power adapter (*1) Power cord (*1) D-sub 15-pin signal cable (*1) Digital DVI signal cable (*1) BNC cable (*1,) CD-ROM (containing Windows information file and user’s manual) Quick Guide... -
Page 6: Identify The Parts And Controls
Identify the Parts and Controls DC +12V Power inlet Provides +12V DC power to the monitor. Digital DVI-D connector for digital signal input Video-In / Video-Out BNC connector for Video signal. VGA-Input D-sub 15-pin connector for VGA signal. - Page 7 Up Button Activates the On-Screen Display menu. While the On-Screen Display menu appears, press to move the selected item clockwise or onward INPUT / Down Button While the On-Screen Display menu appears, press to move the selected item counterclockwise or backward Use as the Input Select Hot Key* when the On-Screen Display menu is inactivated INPUT Input Select Hot Key*...
-
Page 8: How To Use The On-Screen Display Menu
Auto Button Optimal Settings (available only when D-Sub input is connected): Press button to adjust the picture position and performance automatically when D-Sub input is connected. You are recommended to press the button the first time you use the monitor or every time you change the resolution and/or refresh rate of the input signal. -
Page 9: Setup
Setup Please follow the following instructions to setup monitor. Step 1: Remove all packing materials and wrapping from the monitor and then tear down the plastic dust cover from the screen surface. Step 2: With the computer or video equipment turned off, connect the enclosed VGA signal cable. -
Page 10: Software Configuration
You can find the Microsoft Windows data file (also called the driver program) on the included AG Neovo CD. To ensure smooth operation after initial installation, you can refer to the installation guide, which can also be found on the CD. -
Page 11: Customizing Your Monitor
Customizing Your Monitor Adjusting Your LCD Panel In the OSD menu, you will find all kinds of features to help you adjust your LCD panel to the optimal performance. Selecting OSD Features Push button to call out the OSD menu. The sixteen OSD icons are represented in the following menu. -
Page 12: Osd Menus
OSD Menus VGA-Input (D-Sub) Important! Though manual adjustment of the LCD panel is available, we strongly recommend you to use the auto adjustment function of the panel. It will automatically tune your LCD panel to the optimal performance. Simply push the AUTO button to enable the auto adjustment function. - Page 13 Phase Adjustment Clock Adjustment Horizontal OSD Position Adjustment Color Temperature Selection Vertical OSD Position Adjustment Tools Adjustment Language Selection Auto and Input Select Selection The color temperature of RGB can be adjusted in case of entering “ User ”sub menu. Suggest the user select“...
- Page 14 Exit Selection DVI-Input Important! When DVI-Input is selected, the following adjustments are not available: horizontal position adjustment, vertical position adjustment, sharpness, phase adjustment and clock adjustment. Brightness Adjustment Contrast Adjustment OSD Transparency Adjustment Color Temperature Selection...
- Page 15 Horizontal OSD Position Adjustment Vertical OSD Position Adjustment Language Selection Tools Selection Auto and Input Select Selection Exit Selection Suggest the user to use“ Recall ”icon, if the user doesn’t satisfy with the adjustment.
-
Page 16: Cvbs Input
CVBS Input Brightness Adjustment MASK Contrast Adjustment Color Adjustment Hue Adjustment Sharpness Adjustment OSD Transparency Adjustment Color Temperature Selection OFF：Default to turn “Mask” function off to present native image reproduction MODE1：Activate “Mask” to keep noise blanking and support VCR Forward / Backward MODE2：Activated “Mask”... - Page 17 Horizontal Position Adjustment Vertical Position Adjustment Tools Selection Language Selection Auto and Input Select Selection Exit Selection...
-
Page 18: Warning Messages And Troubleshooting
Warning Messages and Troubleshooting Warning Messages If the message appears on the screen Check the items CAN NOT DISPLAY THIS INPUT SIGNAL The input signal is not acceptable by the monitor. • Please check the video resolution and frequency range is within that specified for the monitor. -
Page 19: Troubleshooting
Troubleshooting Symptom Check Items Check that the power switch of monitor is turned No picture Power LED is off. Check that the power adapter is properly connected to the monitor. Check that the power cord is properly connected to the power adapter. •... -
Page 20: Technical Specifications
Technical Specifications Specifications SX-19 Electrical characteristics Screen size 19.0” (48.2 cm) diagonal Pixel format 1280 x 1024 vertical stripe Horizontal frequency 30kHz ~ 80kHz Vertical frequency 56Hz ~ 75Hz Connections Power: 3-Pin AC Plug Physical characteristics Weight Net: 7.4Kg (16.3 lb) Tilt angle 0º... - Page 21 SX-15 Electrical characteristics Screen size 15.0” (38.1 cm) diagonal Pixel format 1024 x 768 vertical stripe Horizontal frequency 30kHz – 60kHz Vertical frequency 56Hz – 75Hz Connections Power: 3-Pin AC Plug Physical characteristics Weight Net: 4.7 Kg (10.34 lb) Tilt angle 0º...
-
Page 22: Regulation
Regulation FCC compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 23: Weee
WEEE Information for users applicable in European Union countries The symbol on the product or its packaging signifies that this product has to be disposed separately from ordinary household wastes at its end of life. Please kindly be aware that this is your responsibility to dispose electronic equipment at recycling centers so as to help conserve natural resources.
