- Page 1 SX-15E, SX-17E & SX-19E LED-Backlit Display User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information Federal Communications Commission (FCC) Notice (U.S. Only) ............4 WEEE ............................... 5 Precautions Notice ............................... 6 Cautions When Setting Up ........................6 Cautions When Using ..........................7 Cleaning and Maintenance ........................7 Notice for the LCD Display ........................8 Chapter 1: Product Description 1.1 Package Contents .......................... - Page 3 6.1 Warning Messages ..........................41 6.2 Troubleshooting ..........................42 6.3 Transporting the LCD Display ......................43 Chapter 7: Specifications 7.1 Display Specifications ........................44 7.2 Display Dimensions ..........................45 7.2.1 SX-15E Dimensions ........................45 7.2.2 SX-17E Dimensions ........................46 7.2.3 SX-19E Dimensions ........................46...
-
Page 4: Safety Information
SAFETY INFORMATION Safety Information Federal Communications Commission (FCC) Notice (U.S. Only) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Weee
SAFETY INFORMATION WEEE Information for users applicable in European Union countries. The symbol on the product or its packaging signifies that this product has to be disposed separately from ordinary household wastes at its end of life. Please kindly be aware that this is your responsibility to dispose electronic equipment at recycling centers so as to help conserve natural resources. -
Page 6: Precautions
PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Symbols used in this manual This icon indicates the existence of a potential hazard that could result in personal injury or damage to the product. This icon indicates important operating and servicing information. Notice •... -
Page 7: Cautions When Using
AG Neovo for consultations and solutions to help ensure a most pleasurable and fulfilling display experience. -
Page 8: Notice For The Lcd Display
PRECAUTIONS Notice for the LCD Display In order to maintain the stable luminous performance, it is recommended to use low brightness setting. Due to the lifespan of the lamp, it is normal that the brightness quality of the LCD display may decrease with time. -
Page 9: Chapter 1: Product Description
Must use only the supplied power adapter: ♦ Lite-on Technology Corporation SX-15E, SX-17E & SX-19E Model no.: PA-1041-81 Quick Start Guide Rating: 12V/3.33A SX-15E, SX-17E & SX-19E LED-Backlit Display SX-15E/SX-17E/SX-19E_Quick Guide_V010 www.agneovo.com Power cord VGA cable Audio cable Warranty card Note: ♦... -
Page 10: Wall Mounting Installation Preparation
75mm display on the ceiling or any other horizontal surface overhead are strongly advised to contact AG Neovo for consultations and solutions to help ensure a most 1.2.2 Removing the Base Stand pleasurable and fulfilling display experience. -
Page 11: Lcd Display Overview
PRODUCT DESCRIPTION 1.3 LCD Display Overview 1.3.1 Front View and Keypad Buttons Display screen RIGHT: Hot Key: Aspect Ratio Change The LCD display screen is protected by • Press to increase the volume. NeoV Optical Glass. • During OSD menu selection, press to select an option, adjust the settings, or enter the SOURCE: Press to select the input signal submenu. -
Page 12: Rear View
PRODUCT DESCRIPTION 1.3.2 Rear View S-VIDEO CVBS-1 CVBS-2 AUDIO AUDIO DC IN HDMI DisplayPort AUDIO IN RS-232 DC power input COMPOSITE Video input/output connectors (1) Use to connect the power adapter. Use to connect composite cables for CVBS DVI connector input/output signal. -
Page 13: Chapter 2: Making Connections
CHAPTER 2: MAKING CONNECTIONS 2.1 Connecting the Power Connect the power cord to the power adapter. Connect the power adapter to the DC power input at the rear of the LCD display. Connect the power cord plug to a power outlet or a power supply. DC IN Caution: ♦... -
Page 14: Connecting Input Source Signals
MAKING CONNECTIONS 2.2 Connecting Input Source Signals 2.2.1 Connecting a Computer Using VGA Cables Connect one end of a VGA cable to the VGA connector of the LCD display and the other end to the VGA connector of the computer. Using DVI Cables Connect one end of a DVI cable to the DVI connector of the LCD display and the other end to the DVI connector of the computer. -
Page 15: Using Rs-232 Cables
MAKING CONNECTIONS Using RS-232 Cables Connect one end of a RS-232 cable to the RS-232 connector of the LCD display and the other end to the RS-232 connector of the computer. RS-232 Connecting an Audio Device Connect one end of an audio cable to the audio port of the LCD display and the other end to the audio out port of the computer. -
Page 16: Connecting A Camera Or Video Device
MAKING CONNECTIONS 2.2.2 Connecting a Camera or Video Device Using CVBS Cables Connect one end of a CVBS cable CVBS-1 to the COMPOSITE connectors of the LCD display and the other end to CVBS-2 the COMPOSITE connectors of your device. AUDIO For audio input, connect an RCA cable to the audio in connector of... -
Page 17: Using Hdmi Cables
MAKING CONNECTIONS Using HDMI Cables Connect one end of an HDMI cable to the HDMI connector of the LCD display and the other end to the HDMI connector of your device. HDMI Using DisplayPort Cables Connect one end of a DisplayPort cable to the DisplayPort connector of the LCD display and the other end to the DisplayPort connector of your device. -
Page 18: Connecting A Usb Storage Device (For Firmware Update)
MAKING CONNECTIONS 2.3 Connecting a USB Storage Device (For Firmware Update) Do any of the following to connect a USB storage device to the USB connector of the LCD: • Connect the USB storage device directly to the USB connector of the LCD (as illustrated below). •... -
Page 19: Chapter 3: Using The Lcd Display
CHAPTER 3: USING THE LCD DISPLAY 3.1 Turning on the Power Plug the power cord to a power outlet or power supply. Note: Touch the POWER button to turn the ♦ The LCD display still consumes LCD display on. power as long as the power cord is connected to the power The LED indicator turns GREEN. -
Page 20: Adjusting The Volume
USING THE LCD DISPLAY 3.3 Adjusting the Volume Adjusting the Volume Touch either the buttons to call out the volume bar. Touch the button to increase volume or the button to decrease volume. VOLUME buttons 3.3.1 Muting the Audio Touch the and the buttons simultaneously to mute or unmute the audio. -
Page 21: Using Freeze Function
USING THE LCD DISPLAY 3.5 Using FREEZE Function The FREEZE function allows you to freeze the screen image but still continues real-time playback until the image is unfreeze. Touch the button to activate screen freeze, the screen freeze message is displayed on the screen. Note: ♦... -
Page 22: Chapter 4: On Screen Display Menu
CHAPTER 4: ON SCREEN DISPLAY MENU 4.1 Using the OSD Menu Operation Display the main menu screen. Touch N T S C 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R T E M P . - Page 23 ON SCREEN DISPLAY MENU Operation Select the submenu item. Touch the buttons. 6 0 H z B R I G H T N E S S T N E S S C O N T R A S T T E M P . B A C K L I G H T S E T T I N G B L A C K L E V E L...
-
Page 24: Osd Menu Tree
ON SCREEN DISPLAY MENU 4.2 OSD Menu Tree N T S C 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R T E M P . - Page 25 ON SCREEN DISPLAY MENU Main Menu Submenu Remarks 3. IMAGE SETTING • SHARPNESS Refer to pages 30-32 • SATURATION • TINT • GAMMA • COLOR RANGE • NOISE REDUCTION • PICTURE MODE • H. POSITION • V. POSITION • PHASE •...
- Page 26 ON SCREEN DISPLAY MENU Main Menu Submenu Remarks 9. ECO SMART • ENABLE Refer to page 39 • MODE • LEVEL 10. INPUT SELECT • VGA Refer to page 40 • DVI • HDMI • DP • CVBS1 • CVBS2 •...
-
Page 27: Chapter 5: Adjusting The Lcd Display
CHAPTER 5: ADJUSTING THE LCD DISPLAY 5.1 BRIGHTNESS 1. Touch to call out the OSD window. N T S C 6 0 H z B R I G H T N E S S B R I G H T N E S S 2. - Page 28 ADJUSTING THE LCD DISPLAY Original Setting High Setting Low Setting BRIGHTNESS CONTRAST BLACK LEVEL...
-
Page 29: Colour Temp
ADJUSTING THE LCD DISPLAY 5.2 COLOUR TEMP. 1. Touch to call out the OSD window. N T S C 6 0 H z N E U T R A L W A R M B R I G H T N E S S 2. -
Page 30: Image Setting
ADJUSTING THE LCD DISPLAY 5.3 IMAGE SETTING 1. Touch to call out the OSD window. N T S C 6 0 H z S H A R P N E S S B R I G H T N E S S 2. - Page 31 ADJUSTING THE LCD DISPLAY Item Function Operation Range Adjusts black and white levels for video. FULL Touch the button to Note: This menu option is only LIMIT select the setting. available if the input source is HDMI or DP. Signal source from PC - PC signal at a full range (Grayscale 0-255) state: COLOUR RANGE Monitor OSD colour range: Full Monitor OSD colour range: Limit...
- Page 32 ADJUSTING THE LCD DISPLAY Item Function Operation Range H. POSITION Moves the screen image to the left (Horizontal Position) or right. V. POSITION Moves the screen image up or down. (Vertical Position) Adjusts the phase timing to Touch the button to synchronise with the video signal.
-
Page 33: Aspect Ratio
ADJUSTING THE LCD DISPLAY 5.4 ASPECT RATIO 1. Touch to call out the OSD window. N T S C 6 0 H z F U L L R E A L B R I G H T N E S S 2. -
Page 34: Anti-Burn-In
ADJUSTING THE LCD DISPLAY 5.5 ANTI-BURN-IN 1. Touch to call out the OSD window. N T S C 6 0 H z E N A B L E O F F B R I G H T N E S S 2. -
Page 35: Osd Setting
ADJUSTING THE LCD DISPLAY 5.6 OSD SETTING 1. Touch to call out the OSD window. N T S C 6 0 H z T R A N S P A R E N C Y B R I G H T N E S S 2. -
Page 36: Audio Setting
ADJUSTING THE LCD DISPLAY 5.7 AUDIO SETTING 1. Touch to call out the OSD window. N T S C 6 0 H z V O L U M E B R I G H T N E S S 2. Select AUDIO SETTING menu, then A U D I O C O L O U R T E M P . -
Page 37: System
ADJUSTING THE LCD DISPLAY 5.8 SYSTEM 1. Touch to call out the OSD window. N T S C 6 0 H z P O W E R S A V I N G O F F B R I G H T N E S S 2. - Page 38 Note: This menu option is only available if the input source is HDMI or DP. Enables or disables the logo feature. If the setting is set to ON, the AG Neovo logo is LOGO briefly displayed after the display is powered Turns the LED indicator on or off while using the LCD monitor.
-
Page 39: Eco Smart
ADJUSTING THE LCD DISPLAY 5.9 ECO SMART With the built-in EcoSmart sensor, users can enable the Eco Smart feature to automatically adjust the LCD screen brightness according to the ambient light. This feature comforts the eyes and helps optimise energy efficiency. -
Page 40: Input Select
ADJUSTING THE LCD DISPLAY 5.10 INPUT SELECT 1. Touch to call out the OSD window. N T S C 6 0 H z V G A P R E S S B R I G H T N E S S 2. -
Page 41: Chapter 6: Appendix
CHAPTER 6: APPENDIX 6.1 Warning Messages Warning Messages Cause Solution The resolution or the refresh rate of • Change the resolution or the the graphics card of the computer refresh rate of the graphics I N P U T S I G N A L O U T O F R A N G E is set too high. -
Page 42: Troubleshooting
APPENDIX 6.2 Troubleshooting Problem Possible Cause and Solution No picture. • Check if the LCD display is turned ON. • Check if the power adapter is properly connected to the LCD display. • LED indicator is OFF. • Check if the power cord is plugged into the power outlet. •... -
Page 43: Transporting The Lcd Display
APPENDIX 6.3 Transporting the LCD Display To transport the LCD display for repair or shipment, place the display in its original packaging carton. Place the two foam cushions on each side of the LCD display for protection. Place the LCD display down in the box. Place the accessories in the designated area (if necessary). -
Page 44: Chapter 7: Specifications
CHAPTER 7: SPECIFICATIONS 7.1 Display Specifications SX-15E SX-17E SX-19E Panel Panel Type LED-Backlit TFT LCD (VA LED-Backlit TFT LCD (TN LED-Backlit TFT LCD (TN Technology) Technology) Technology) Panel Size 15.0” 17.0” 19.0” Max. Resolution XGA 1024 x 768 SXGA 1280 x 1024... -
Page 45: Display Dimensions
Packaging 6.7 kg (14.8 lb) 7.8 kg (17.2 lb) 8.7 kg (19.2 lb) Note: ♦ All specifications are subject to change without prior notice. 7.2 Display Dimensions 7.2.1 SX-15E Dimensions 380(outline dimension) 53.5 306(opening dimension) (M4xL10) x8 44.8 282.4 44.8... -
Page 46: Sx-17E Dimensions
340(opening dimension) (M4xL10) x8 7.2.3 SX-19E Dimensions 64.5 (outline dimension) 445.4 0-20° (opening dimension) 27.8 378.5 27.8 AG Neovo Company Address: 5F-1, No. 3-1, Park Street, Nangang District, Taipei, 11503, Taiwan. Copyright © 2018 AG Neovo. All rights reserved. SX-15E/SX-17E/SX-19E_UM_V011...
