Summary of Contents for AG Neovo SX-15

  • Page 2: Table Of Contents

    Table of Contents Precautions ... 2 Warning on installation...2 Warning on power connection ...2 Warning on tilt...3 Warning on Maintenance...3 Warning on transportation...3 Package Contents ...4 Identify the Parts and Controls ...5 Setup...7 Install information (.inf) file for Microsoft Windows 95/98/2000/ME/XP...8 Customizing Your Monitor ...

  • Page 3: Precautions

    Warning on installation Do not cover or block the ventilation holes in the case. Do not install the monitor near heat sources such as radiators or air ducts, or in a place subject to direct sunlight, excessive dust, mechanical vibration or shock.

  • Page 4: Warning On Tilt

    Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage potentials or other risks. Warning on transportation When you transport this monitor for repair or shipment, use the original carton and packing materials. SX-15...

  • Page 5: Package Contents

    Package Contents Before using this monitor, check the following items are included in your carton box: Monitor (*1) Power adapter (*1) Power cord (*1) D-sub 15-pin signal cable (*1) Digital DVI signal cable (*1) BNC cable (*1,) CD-ROM (containing Windows information file and user’s manual) Quick Guide Cleaning Clothing...

  • Page 6: Identify The Parts And Controls

    Identify the Parts and Controls UP button Activates the On-Screen Display menu. Move the selected item upward while the On-Screen Display sub-menu appears. INPUT / DOWN button Hot key for input source select / Activates the OSD and navigates within the display.
  • Page 7 DC +12V Power inlet Provides +12V DC power to the monitor. VGA-In D-sub 15-pin connector for VGA signal. VIDEO-IN / VIDEO-OUT BNC connector for Video signal. Digital DVI-D connector for digital signal input...

  • Page 8: Setup

    Setup Please follow the following instructions to setup monitor. Step 1: Remove all packing materials and wrapping from the monitor and then tear down the plastic dust cover from the screen surface. Step 2: With the computer or video equipment turned off, connect the enclosed VGA signal cable.

  • Page 9: Install Information (.Inf) File For Microsoft Windows 95/98/2000/Me/Xp

    Step 3: With the monitor turned off, connect the monitor end power plug of adaptor to the power jack of the monitor. Then connect the power cord to the adapter and the power plug to the power source. Step 4: Turn on your computer or video equipment. Press turn on monitor.

  • Page 10: Customizing Your Monitor

    Adjusting Your LCD Panel In the OSD menu, you will find all kinds of features to help you adjust your LCD panel to the optimal performance. Important! Though manual adjustment of the LCD panel is available, we strongly recommend you to use the auto adjustment function of the panel. It will automatically tune your LCD panel to the optimal performance.

  • Page 11: Osd Menus

    OSD Menus VGA-Input Brightness Adjustment Contrast Adjustment Horizontal Position Adjustment Vertical Position Adjustment...
  • Page 12 Sharpness Adjustment OSD Transparency Adjustment Phase Adjustment Clock Adjustment...
  • Page 13 Color Temperature Selection P.S. The color temperature of RGB can be adjusted in case of entering “ User ”sub menu. Horizontal OSD Position Adjustment Vertical OSD Position Adjustment Graphic/Text Selection P.S. Suggest the user select“ Text ”sub menu in case of the resolution being 640×350 or 640×400.
  • Page 14 Recall Selection P.S. Suggest the user to use“ Recall ”icon, if the user doesn’t satisfy with the adjustment. Language Selection Input Select Selection Exit Selection...

  • Page 15: Dvi-Input

    DVI-Input Brightness Adjustment Contrast Adjustment OSD Transparency Adjustment Color Temperature Selection P.S. The color temperature of RGB can be adjusted in case of entering “ User ”sub menu.
  • Page 16 Horizontal OSD Position Adjustment Vertical OSD Position Adjustment Recall Selection P.S. Suggest the user to use“ Recall ”icon, if the user doesn’t satisfy with the adjustment. Language Selection...
  • Page 17 Input Select Selection Exit Selection...

  • Page 18: Video Input

    VIDEO Input Brightness Adjustment Contrast Adjustment Color Adjustment Hue Adjustment...
  • Page 19 Sharpness Adjustment OSD Transparency Adjustment Color Temperature Selection P.S. The color temperature of RGB can be adjusted in case of entering “ USER ”sub menu. Horizontal Position Adjustment...
  • Page 20 Vertical OSD Position Adjustment Recall Selection P.S. Suggest the user to use“ Recall ”icon, if the user doesn’t satisfy with the adjustment. Language Selection Input Select Selection...
  • Page 21 Exit Selection...

  • Page 22: Warning Messages And Troubleshooting

    Warning Messages and Troubleshooting Warning Messages If the message appears on the screen CAN NOT DISPLAY THIS INPUT SIGNAL The input signal is not acceptable by the NO SIGNAL INPUT WAIT FOR AUTOMATIC ADJUSTMENT The monitor is detecting the input signal and MAIN CONTROL MENU LOCKED/ UNLOCKED Check the items...

  • Page 23: Troubleshooting

    Troubleshooting Symptom No picture Power LED is off. The texts are not solid • Screen image is not centered properly. • Some lines are missing • There are red, green, blue or black tiny dots on the screen. Check Items Check that the power switch of monitor is turned on.

  • Page 24: Technical Specifications

    Specifications SX-19 Electrical characteristics Screen size Pixel format Horizontal frequency Vertical frequency Maximum pixel clock Connections Physical characteristics Weight Tilt angle SX-17 Electrical characteristics Screen size Pixel format Horizontal frequency Vertical frequency Maximum pixel clock Connections Physical characteristics Weight Tilt angle Technical Specifications 19.0”...
  • Page 25 SX-15 Electrical characteristics Screen size Pixel format Horizontal frequency Vertical frequency Maximum pixel clock Connections Physical characteristics Weight Tilt angle 15.0” (38.1 cm) diagonal 1024 x 768 vertical stripe 30kHz – 80kHz 50Hz – 75Hz 80MHz Power: 3-Pin AC Plug Net: 4.7 Kg (10.34 lb)

  • Page 26: Regulation

    FCC compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 27: Information For Users Applicable In European Union Countries

    Information for users applicable in European Union countries The symbol on the product or its packaging signifies that this product has to be disposed separately from ordinary household wastes at its end of life. Please kindly be aware that this is your responsibility to dispose electronic equipment at recycling centers so as to help conserve natural resources.
