AG Neovo X-19P Plus Specifications

AG Neovo X-19P Plus Specifications

A durable, hard glass-protected 19” professional display
Hide thumbs Also See for X-19P Plus:

Advertisement

Quick Links

NeoV™ Optical Glass - The most
trusted hard glass protection available.
Only on AG Neovo displays
www.agneovo.com
SX-19P
A durable, hard glass-protected
19" professional display featuring
Advanced Image Platform and Anti-
Burn-in™ technology vital for 24/7
surveillance environments
For high efficiency surveillance performance, top security
environments choose the SX-19P. The Built-in Image Enhancer of
AG Neovo's Advanced Image Platform flawlessly reproduces CCTV
images at high resolutions of 625/PAL (620/NTSC) TV Lines.
Coming with an EcoSmart sensor, the eco-friendly design slashs
power consumption by up to 1/3 (versus conventional security
monitors). Combined with stylish yet functional durable metal
casing and edge-to-edge protective NeoV™ Optical Glass, the
SX-19P transforms any surveillance room onto a security command
centre.
> High 1280 x 1024 SXGA resolution
> NeoV™ Optical Glass
> Anti-Burn-in™ technology
> Quick signal-switching time ( ≤ 0.8 sec.)
> Horizontal resolution up to 620TVL(NTSC), 625TVL(PAL)
> Smart Omni Viewer: PIP/PBP, Freeze & 180° Image Rotation
> Built-in Image Enhancer: 3D Comb Filter/Deinterlace/Noise Reduction
> EcoSmart sensor auto adjusts brightness for ultra low power consumption
> Versatile connectivity (BNC in/out x2, S-Video, VGA, DVI, Audio in/out)
> BNC video out passive looping
> Power DC-out design to power connected peripherals
> Selectable aspect ratio for ultimate image: Native, Overscan, Underscan
> NTSC/PAL/SECAM video system support
> Durable metal casing design
> IP22 Compliant (IEC 60529 Standard)
> VESA standard wall mount
> Rigorous screening of the components for mission-critical 24/7 applications

Advertisement

loading
Need help?

Need help?

Do you have a question about the X-19P Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AG Neovo X-19P Plus

  • Page 1 For high efficiency surveillance performance, top security environments choose the SX-19P. The Built-in Image Enhancer of AG Neovo’s Advanced Image Platform flawlessly reproduces CCTV images at high resolutions of 625/PAL (620/NTSC) TV Lines. Coming with an EcoSmart sensor, the eco-friendly design slashs power consumption by up to 1/3 (versus conventional security monitors).
  • Page 2 15-Pin D-Sub cable, wire hook All specifications are subject to change without prior notice. Copyright © 2013 AG Neovo. All rights reserved. The name AG Neovo is a trademark of AIC. All other trademarks are the property of their respective owners.

This manual is also suitable for:

Sx-19pSx-19p plus
