Setup Options
Setup options consist of key settings
that are normally made only during the
initial installation stage.
Security
Settings: ENABLED, DISABLED
Allows you to set a password with which you can lock access to the connected
computers and AdderView PRO menus. When you change this option to
ENABLED, you will be asked to enter and confirm a password that will be
used when locking and unlocking access to the menus. For more details, see
Enabling
security.
Language
Settings: ENGLISH, FRENCH, GERMAN, SWEDISH
This option specifies the language that is used for the on-screen menu and the
keyboard layout that is assumed for the keyboard. When the French option is
selected the keyboard is assumed to have an AZERTY format. When the English,
German and Swedish options are selected the keyboard is assumed to have a
QWERTY format. The new language settings are enabled when you quit from
the SETUP OPTIONS menu. The language option only affects the way that the
AdderView PRO interprets the keyboard keys, it does not affect the way that the
computers interpret the keyboard. It is advisable to avoid setting a language that
you do not understand as all the menus will change to use the new language
and you may have difficulty reselecting your original language.
ADDERVIEW PRO
Setup Options
Security:
ENABLED
Language:
ENGLISH
Hotkeys:
CTRL+ALT
Default Channel:
OSD
Baud Rate:
1200
Space–Toggle
–Up
–Down
Esc–Quit
To get here
1 Press
(hotkeys can change).
2 Press
to select 'More menus'.
3 Select 'Setup Options'.
Hotkeys
Settings: CRTL+ALT, CTRL+SHIFT, ALT+SHIFT, ALT GR, L+R ALT, L CTRL+ALT,
R CTRL+ALT
The keyboard hotkeys are special combinations of keys that, when used
together with certain keyboard "command keys", perform special AdderView
PRO functions. For example, pressing the hotkeys together with the "M" key
will cause the on-screen menu to be displayed on your monitor. Other hotkey
combinations allow you to query which computer you are connected to and
to move the on-screen menu around the screen. You can also use the hotkeys
together with the channel number to select a particular connected computer.
Default Channel
Settings: OSD, CHANNEL 1, 2, 3, 4, 5, 6, 7, 8
Determines what should occur immediately after the unit is first powered on.
The choices allow you to either choose the on-screen menu or switch to any of
the eight computer channels.
Baud Rate
Settings: 1200, 2400, 9600, 19200, 38400, 57600, 115200
Determines the speed of communication through the OPTIONS serial port on
the rear panel. You may need to change the speed if you are connecting to
another device that needs to synchronise its operation and either control, or be
controlled by, the AdderView PRO unit.
