Introduction

Thank you for choosing a member of the AdderView
PRO family of professional switches from Adder
Technology. This compact unit allows a single operator
to control up to eight computer systems and share
peripherals among them in a very flexible manner.
The AV8PRO-DVI model benefits greatly from our
long history of success in KVM (Keyboard, Video and
Mouse) switching. As a result, it can reliably switch
multiple signals (including dual link digital video at up
to 330Mpixels per second) in a manner that is totally
transparent during operation. However, this unit
offers more than just straight switching between eight
USB Remote wakeup
The USB Remote Wakeup feature
is fully supported. Any connected
computer can go into sleep mode
and be awakened (when its channel
is selected) as soon as you press a key
or move the mouse. The computer
and peripherals must support the USB
Remote Wakeup feature.
Digital and analogue video
Each of the eight computer channels
has a DVI-I video connector which
allows either DVI digital or VGA
analogue signals to be input. At the
console connections, the AdderView
Pro 8 uses separate DVI-D and
VGA connectors to allow the easy
attachment of either type of monitor,
or to permit dual connections to auto-
switching monitors that can operate
with either type of input.
systems. The KVM, speakers and two separate USB
devices attached to the AV8PRO-DVI can be switched
in unison between any of the connected systems, as
normal. However, you also have the option to mix your
peripherals between any of the systems, to suit your
current tasks. For instance, you could be creating emails
on one system, listening to a soundtrack from another
while a third is sending documents to your printer and
a fourth performing another task with a different USB
peripheral. The on-screen menu or the AV8PRO-DVI
front panel make it straightforward to control which
peripherals should connect to each system.
SPK
KVM
COMPUTER KVM SPK USB1 USB2 PWR
KB MS OSD UPG LCK
The AV8PRO-DVI also marks the debut of a significant
advance in USB keyboard and mouse switching. This
is the first product to feature
ensures that the full characteristics of the connected
keyboard and mouse are passed to every system.
This supersedes the previous method of presenting
default identities to the systems, which did not allow
for specialised features present on either the keyboard
or mouse. With
subject to the correct drivers being used on each
system, the AV8PRO-DVI will faithfully represent the
special characteristics of your keyboard and mouse.
1 2
MODE
www.adder.com
True Emulation which
True Emulation, you will find that,
Multiple switching
The attached peripheral devices can be
switched collectively to any computer
system, or can be linked to separate
systems to achieve multiple tasks in
parallel. Multiple switching can be
controlled from the on-screen menu
or using the front panel buttons.
True Emulation
Earlier USB KVM switches relied
upon standard keyboard and mouse
templates to inform each computer
system how to deal with the
connected peripherals. The AdderView
PRO succeeds in harvesting the true
identities of the connected keyboard
and mouse and presents those 'real'
profiles concurrently to every system.
Thus, specialist keyboards and mice
can be fully supported.
