Help

Displays a summary of
AFU
For example:
A:\> AFU HELP
A:\> AFU /?

Updating the Flash Using the AFU Command Line

1. Create the firmware update disks (see
2. Shut down your operating system and reboot to DOS from a bootable DOS floppy disk or from a DOS
partition on a bootable drive. (You can use a disk connected to the controller you're updating.) If
your computer isn't set up to boot from the bootable floppy disk or a bootable device other than a
disk drive, enter the system setup utility to change the setting.
3. Insert the firmware update disk containing AFU.exe
4. At the DOS command, if you have multiple controllers and you don't know the number of the
controller you want to update, type
5. At the DOS command, type AFU followed by a command (see
switches you want.
6. Update the flash using the instructions suitable for your requirements:
• To update a single RAID controller:
AFU UPDATE /C <cont_number>
Where <cont_number> is the number of the RAID controller whose firmware you are updating.
For example, to upgrade Controller 0, type
• To update multiple RAID controllers:
AFU UPDATE /C <cont_number_a>,<cont_number_b>
Where <controller_number_a> and <controller_number_b> are the numbers of the Adaptec RAID
controllers whose firmware you are updating. For example, to upgrade controllers 0, 2, and 3,
type
AFU UPDATE /C 0, 2, 3
• To update all RAID controllers simultaneously:
AFU UPDATE /C all
Note: The UFI file identifies the RAID controllers, so you don't have to worry
about flashing the wrong controller.
7. When prompted, insert the first firmware disk into your floppy disk drive.
The AFU reads the first disk.
8. When prompted, remove the first firmware disk and insert the second firmware disk into your floppy
disk drive.
9. Repeat Step 8 as required.
Proprietary and Confidential to PMC-Sierra, Inc.
Document No.: CDP-00277-01-A Rev. A, Issue:
Serial Attached SCSI RAID Controllers Installation and User's Guide
functions and command switches.
Creating the Firmware Update Disks
, then press
AFU LIST
AFU UPDATE /C 0
on page 79).
. Otherwise, skip to the next step.
Enter
AFU Commands on page 81) and any
