About the Adaptec RAID 71605/71605Q

The Adaptec RAID 71605/71605Q is a SAS RAID controller with these features:
4 internal mini-SAS HD connectors
Form Factor
Bus compatibility
PCIe bus width
Data transfer rate
Phys (Unified Serial Ports)
Standard cache
Connectors, internal
Maximum number of disk drives
maxCache SSD support
Enclosure Support
Onboard speaker
Zero Maintenance Cache Protection
Module
Proprietary and Confidential to PMC-Sierra, Inc.
Document No.: CDP-00277-01-A Rev. A, Issue:
Serial Attached SCSI RAID Controllers Installation and User's Guide
PCIe x8 connector
Mounting bracket
Low-profile MD2 SFF card size
PCIe Gen3
x8
6 Gb/s per port
16
1024 MB DDR3
4 mini-SAS HD x4 (SFF-8643)
16 direct-attached (or up to 256 with expanders)
71605Q: Up to 16 solid state drives, 2TB capacity, max. See the
maxCache compatibility list at www.adaptec.com/compatibility.
IBPI and SGPIO (Serial General Purpose Input/Output)
Yes
Adaptec Flash Backup Module AFM-700 (71605: optional, sold
separately; 71605Q: standard, pre-installed)
Ext. Alarm connector
HDA mode connector
Daughterboard
connector
