About Your RAID Controller

This chapter provides an overview of the features of your Adaptec RAID controller.

Standard RAID Controller Features

• Support for SAS disk drives, SATA/SATA II disk drives, and SATA and SAS Solid State Drives (SSDs)
• Flash ROM for updates to controller firmware, BIOS, and the Adaptec RAID Configuration utility
• Disk drive hot-swapping
• Event logging and broadcasting, including email notification messages
• Multiple options for creating and managing RAID arrays—A browser-based software application
(maxView Storage Manager), a BIOS-based utility (ARC), a command line utility (ARCCONF) (see
Managing Your Storage Space
• Native command queuing (NCQ), which lets disk drives arrange commands into the most efficient
order for optimum performance
• Support for disk drive enclosures with SES2 enclosure management hardware
• Support for a flash backup module (see
• Support for Adaptec maxCache™ SSD read and write caching (see
73)
Note: Adaptec maxCache is supported on Adaptec Series Q controllers only.
• Power-management of disk drives in your storage space to reduce cooling and electricity costs (see
Modifying Power Management Settings
• Audible alarm
• I/O statistics logging

Array-level Features

• Support for RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, and simple volumes
• Support for hybrid RAID 1 and RAID 10 arrays comprised of hard drives and Solid State Drives (SSDs)
• Support for hot spares (global and dedicated)
• Support for automatic failover, so arrays are automatically rebuilt when a failed drive is replaced
(applies to redundant arrays in SES2- or SAF-TE-enabled disk drive enclosures only)
• Optimized disk utilization, which ensures that the full capacity of all disk drives can be used, even if
the disk drives vary in size
• Online capacity expansion, so you can increase the capacity of an array without recreating it
• Support for array migration from one RAID level to another

Advanced Data Protection Suite

• Copyback Hot Spare—You can use this feature to move data from a hot spare back to its original
location after a failed disk drive is replaced.
• Striped Mirror (RAID 1E)—A RAID 1 Enhanced array is similar to a RAID 1 array except that data is
both mirrored and striped, and more disk drives can be included.
• Dual Drive Failure Protection (RAID 6)—A RAID 6 array is similar to a RAID 5 array except that it
includes two independent sets of parity data instead of one.
• Dual Drive Failure Protection (RAID 60)—A RAID 60 array is similar to a RAID 50 array except that it
includes four independent sets of parity data instead of two.

Adding a Flash Backup Module

This table shows the flash backup module (or "zero maintenance cache protection") supported by your
Adaptec RAID controller. To purchase a flash backup module, refer to the Adaptec Web site at
www.adaptec.com.
Proprietary and Confidential to PMC-Sierra, Inc.
Document No.: CDP-00277-01-A Rev. A, Issue:
Serial Attached SCSI RAID Controllers Installation and User's Guide
on page 54)
Adding a Flash Backup Module
on page 73)
on page 16)
Modifying Cache Settings on page
