Programming Speed Dial Keys - Telematrix Spectrum Plus SP750 Programming Manual

Spectrum PLUS
1. Speed Dial Feature Keys .........
2. Disconnect Key ...........................
3. Store Key .....................................
4. Pause Key ...........................
5. Redial Key ............................
6. Flash Key ...............................
7. Mute Key .....................................
8. Conference Call Key ..................
9. Numeric Dial Pad .......................
10. Line 1 and Line 2 .......................
11. Hold Key ......................................
12. Headset ON/OFF Key ................
13. Speaker Key ............................
14. Volume Bar .................................
15. Handset .......................................
16. Dial Key .................................
17. Delete Key ...................................
18. Up and Down Scroll Key .........
19. Touchlite Key .........................
TM
20. LCD Display ..........................
21. Phonebook (PhBook) Key ........
Programming Procedure for Spectrum PLUS
The Spectrum PLUS TM SP750 has eleven (11) one-touch speed dial locations used for dialing frequently called numbers.
•
Speed dial programming must be done with the telephone plugged into the telephone line.
•
Programming is performed with the telephone on-hook only.
•
A maximum of 32 digits can be entered into ENTER NUMBER and 12-characters into ENTER NAME.
To Program Speed Dial Locations
1. Press and hold the "STORE" key quickly. The words "SET UP MONTH: 01" appear (figure 1).
2. Next, press the speed dial location key where the desired location will be. The display will read "Mxx NO CONTENT". If the
display shows a record, then there is a stored name and number in that location (figure 2).
3. Press the "STORE" key again and the display will read "ENTER NUMBER" (figure 3).
4. Using the dial pad, enter the number. Note that the local area code is not required if AREA CODE is pre-programmed into memory.
5. After entering the number, press the "STORE" key. The display will read "ENTER NAME" (figure 4).
6. Using the keypad, enter the name associated with the number being programmed and include the Flash, and/or Pause, when needed.
7. Press the "STORE" key to store the entry.
8. Program other speed dial locations, repeat 2 to 7.
9. To exit the program mode, press "DISC".
12/01 12:00
PM
SET UP MONTH: 01
Figure 1
SP750 Telephone Key Features
TM
Eleven (11) one-touch keys used for speed dialing.
Used to disconnect the line or place a new call.
Used to program user features.
Used to place a timing delay when dialing.
Redials the last number dialed.
Provides a timed line break
Disables the handset and speaker phone microphones.
Used for conference calls.
Used for dialing.
Used to select line 1 or line 2.
Lighted key used for placing callers on hold.
Lighted key used to turn the headset ON or OFF.
Used to turn the speakerphone ON or OFF.
Adjusts the loudness of the handset receiver, the headset, and/or the speaker.
Hearing-aid compatible handset.
Used to automatically dial the number displayed on the LCD.
Deletes stored Caller ID records and Phonebook (PhBook) records.
Used to scroll Caller ID and Phonebook (PhBook) records.
Message Waiting Lamp (LED indicator) that blinks to indicate a new message in the
user's voice mail box (user must be subscribed to a messaging system).
Large adjustable back-lit display that shows Caller ID, number of calls received, date
and time, and call log.
Used to access names and numbers in the Phonebook (PhBook) directory.

Programming Speed Dial Keys

Speed Dial Features
tm
12/01 12:00
PM
M01 NO CONTENT
Figure 2
12/01 12:00
PM
ENTER NUMBER
Figure 3
12/01 12:00
PM
ENTER NAME
Figure 4
