The drive Active LED indicator connections are shown below.
Jumper Plug
(enlarged to
show detail)
Reserved
Activity LED
Reserved
The shaded pins are shipped
with a cover installed. Do not
install jumpers on these pins.
Retain the cover unless you
install a 20-pin plug.
Note: On some LEDs the flat
Figure 17. Drive Active LED indicator connections
Cheetah 4LP Installation Guide, Rev. B
All drives (LED connections)
J2
J6
side of indicator is cathode.
Pin 1
J6
End
Pin 1
CATH
