28
Cheetah 4LP Installation Guide, Rev. B
80-pin
SCSI I/O
Connector
Pin 1
J2
J6
Note. This drive model plugs directly into a backplane connec-
tor and therefore uses no cables.
Figure 3e. Drive model "WC" or "DC" with single 80-pin I/O
and power connector
