Seagate Cheetah 4LP Installation Manual page 39

Cheetah 4LP Installation Guide, Rev. B
[1]
L
F
D
.050 in. (1.27mm)
minimum clearance
[2]
J2
K
J
J6
[4]
Figure 6. Mounting configuration dimensions
A
G
E
B
LED
H
M
Notes:
[1] Mounting holes three on each side, 6-32 UNC.
Max screw length into side of drive 0.15 in.
(3.81 mm). Screw tightening torque 6.0 in-lb
(.675 NM) max with minimum thread
engagement of 0.12 in. (3.05 mm).
[2] Mounting holes four on bottom, 6-32 UNC.
Max screw length into bottom of drive 0.15 in.
(3.81 mm). Screw tightening torque 6.0 in-lb
(.675 NM) max with minimum thread
engagement of 0.12 in. (3.05 mm).
[3] Power and interface connectors can extend
past the "A" dimension by 0.040 in (1.02mm).
[4] Decorative front panel.
Inches
A 5.750
B 4.000
C 1.000 +
–
D 0.625
E 4.000
F 0.250
G 2.375
H 3.750
J 2.370
K 1.750
L 1.100
M 4.100
[3]
C
Millimeters
0.010 146.05 .25
0.010 101.60 .25
0.026 25.40 .38
0.010
0.020 15.87 .50
0.005 101.60 .13
0.005 6.35
.13
0.010 60.32 .25
0.010 95.25 .25
0.010 60.20 .25
0.020 44.45 .50
0.010 27.94 .25
0.010 104.14 .25
37
