34
[3]
C
[1]
J
[2]
H
K
N
[4]
Figure 6.
Mounting configuration dimensions
G
D
F
A
Notes:
[1] Mounting holes three on each side, 6-32 UNC.
[2] Mounting holes four on bottom, 6-32 UNC.
B
[3] Power and interface connectors can extend
[4] Decorative front panel (optional).
[5] Although the illustration shows the 50 pin I/O
P
M
Hawk 4XL Installation Guide, Rev. A
[4]
L
E
Max screw length into side of drive 0.15 in.
(3.81 mm). Screw tightening torque 6.0 in-lb
(.675 NM) max with minimum thread
engagement of 0.12 in. (3.05 mm).
Max screw length into bottom of drive 0.15 in.
(5.08 mm). Screw tightening torque 6.0 in-lb
(.675 NM) max with minimum thread
engagement of 0.12 in. (3.05 mm).
past the "A" dimension by 0.040 in. (1.02 mm).
connector drive model, mounting hole locations
are the same for all Hawk 4XL models.
Inches
A
5.74
.010
B
4.00
.010
C
1.00
+ .021
– .009
D
2.362
.010
E
.620
.020
4.000
F
.010
G
.250
+ .010
– .005
H
1.750
.010
J
3.750
.010
K
2.370
.020
L
1.00
.010
M
4.000
.010
N
0.19
.010
P
0.015
max
Millimeters
145.80
.25
101.60
.25
25.40
+ .53
– .22
60.00
.25
15.75
.50
101.60
.25
6.35
+ .25
– .12
44.45
.25
95.25
.25
60.20
.50
25.4
.25
101.6
.25
4.83
.25
0.381
max
