Hawk 4XL Installation Guide, Rev. A
23
HDA
Pin 1
Figure 3a.
Fifty pin I/O connection to drive ("N" model)
HDA
Pin 1
Figure 3b. Sixty-eight pin connection to drive ("W" model)
