Note. Air flows in the direction shown (back to front)
or in reverse direction (front to back)
Hinweis. Luftstrom in der angezeigten Richtung
(von vorne nach hinten) oder in umgekehrter
Richtung (von hinten nach vorne)
Note. Air flows in the direction shown or
in reverse direction (side to side)
Hinweis. Luftstrom in der angezeigten Richtung oder in
umgekehrter Richtung (von Seite zu Seite)
Figure 4.
Suggested air flow
Abbildung 4. Empfohlener Luftstromverlauf
Hawk 4XL Installation Guide, Rev. A
Above unit
Über der Einheit
Under unit
Unter der Einheit
Above unit
Über der Einheit
Under unit
Unter der Einheit
