Thank you for choosing the Sanus Systems LAS1A. The LAS1A is designed to mount speakers on each side of a
large VisionMount full motion TV mount. The LAS1A will support speakers weighing up to 11 kg (25 lbs.) each.
Do not use this product for any purpose not explicitly specified by Sanus Systems. Improper installation may
cause property damage or personal injury. If you do not understand these directions, or have doubts about
the safety of the installation, contact Sanus Systems Customer Service or call a qualified contractor. Sanus
Systems is not liable for damage or injury caused by incorrect mounting, assembly, or use.
This product contains small items that could be a choking hazard if swallowed. Keep these items away
from young children!
Sanus Systems 2221 Hwy 36 West, Saint Paul, MN 55113 USA
Customer Service: 1-800-359-5520 • info@sanus.com • www.sanus.com
LAS1A
(6901-100147 <01>)
CauTION
warNINg
Advertisement
Table of Contents
Related Manuals for Sanus Systems LAS1A
Summary of Contents for Sanus Systems LAS1A
- Page 1 (6901-100147 <01>) Thank you for choosing the Sanus Systems LAS1A. The LAS1A is designed to mount speakers on each side of a large VisionMount full motion TV mount. The LAS1A will support speakers weighing up to 11 kg (25 lbs.) each.
- Page 2 Supplied Parts and Hardware Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the item to your dealer; contact Sanus Systems Customer Service. Never use damaged parts! [02] x 2...
- Page 3 1- 1: New Installations If you have purchased a Sanus Systems large VisionMount™ Full Motion Mount, but have not installed it, begin by following the large VisionMount™ Full Motion Mount instructions. Replace Cross Tube Installation with Step 2: Cross Tube Installation of the LAS1A instructions.
- Page 4 HEAVY! You will need assistance with this step. NOTE If you no longer have your VisionMount™ Installation Manual, download one from www.Sanus.com or call Sanus Systems Customer Service. 3: Install Extension Tubes [02] [03] Slide the four extension tubes [03] (felt end first) into the cross tubes [02].
- Page 5 4: Install Threaded Tube Clamp & Clamp Knob Slide the threaded tube clamps [05] onto the extension tubes [03], aligning the notches in the threaded tube clamp and cross tubes [02]. Snap the threaded tube clamps onto the cross tubes. Thread a clamp knob [04] onto each threaded tube clamp [05].
- Page 6 6: attach Speaker Brackets [25] NOTE Slide the speaker brackets [01] into the extension tubes [03]. Maximum extension of the cross tubes is 145cm Use the Allen key to tighten the four vise assemblies [04] until (57 in.). Do not exceed the maximum extension. the speaker brackets do not slide on the extension tubes.
- Page 7 7: attach Speakers 7 - 1: attach Speakers using Threaded Fasteners Determine the thread of the fastener required by threading each size fastener into the back of the speaker. Stop immediately if you encounter any resistance. Choose the correct thread size and [03] fastener length for your speakers.
- Page 8 7 - 2: attach Speakers using Hex Studs Choose the correct fastener length, [14] or [15] for your speakers. [14], [15] [03] [23] The speaker wires may be routed to the speaker terminals through the extension tubes [03]. Refer to the instructions provided with the large VisionMount™...
